- Page 1 Black Clamp-on 30” Cable Management Desk Organizer SKU: DESK-SKIRT-30P Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/desk-skirt-30p...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) C (x2) Panel Side Bar Mounting Clip D (x2) E (x2) F (x4) T Joiner Clamp Upper/Lower G (x1) H (x4) Middle Bar Joiner Included Hardware S-A (x2) S-B (x2) M4x6mm Screw ST4.8x19 Screw Tools Needed: Phillips Pencil... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Connect the centers of the T Joiners (D) to the ends of the Middle Bar (G). Connect the Upper/Lower Bars (F) to the sides of the T Joiners (D), then connect the Joiners (H) and Side Bars (B) to the sides to complete the frame assembly. - Page 5 STEP 3 Fasten the straps on Panel (A) to around the assembled frame to secure. STEP 4 Place Mounting Clips (C) in the center of each exposed portion of Upper/Lower Bars (F). Make sure the wire management flap on Panel (A) is facing upward. NOTE: To screw mount under your desktop instead of clamping, please skip to Step 4-Option 2 on page 6.
- Page 6 STEP 5 For thinner desktops (<1.5”/40mm), adjust Clamp (E) by disassembling and separating Upper Clamp (E1) from Lower Clamp (E2). Flip Lower Clamp (E2) and reassemble using a Phillips screwdriver. STEP 6 Secure Mounting Clips (C) to Clamps (E) in one of two mounting locations using M4x6mm Screws (S-A).
- Page 7 STEP 7 Mount the assembled panel to the desktop and tighten Clamps (E) to secure the assembly in place. STEP 8 Route and organize the cables and secure them using the flap on the panel (A).
- Page 8 STEP 4 (Option 2) Screw Mounting: Place Mounting Clips (C) in the center of each exposed portion of Upper/Lower Bars (F). NOTE: Make sure the wire management flap on Panel (A) is facing the inside of the desktop. STEP 5 (Option 2) Screw Mounting Center the assembled panel under the desktop.
- Page 9 STEP 6 (Option 2) Screw Mounting Mark the locations of Mounting Clips (C) using a pencil. Drill pilot holes using a 1/8” (3mm) bit and mount the assembled panel to the underside of the desk using ST4.8x21mm Screws (S-B) as shown. NOTE: Desktop must be at least 1”...
- Page 10 [PAGE LEFT INTENTIONALLY BLANK]...
- Page 11 [PAGE LEFT INTENTIONALLY BLANK]...
-
Page 12: Last Updated
LAST UPDATED: 01/08/24 REV2 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
