- Page 1 Black Clamp-on 24” Cable Management Desk Organizer SKU: DESK-SKIRT-24P Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/desk-skirt-60p...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) C (x2) Panel Side Bar Mounting Clip D (x2) E (x2) F (x4) T Joiner Clamp Upper/Lower G (x1) H (x4) Middle Bar Joiner Included Hardware & Tools S-A (x2) S-B (x2) M4x6mm Screw ST4.8x19 Screw Tools Needed: 6/50”... - Page 4 **Optional Preassembly** Adjusting Clamps for <1.5” (40mm) Desktops If your desktop is <1.5” (40mm), follow the steps below for a Clamp assembly that will fit your desk. Use a Phillips screwdriver to separate Use a Phillips screwdriver to separate the Upper Clamp (E1) from the Lower the Thumb Screw from the Lower Clamp (E2).
-
Page 5: Assembly Steps
ASSEMBLY STEPS STEP 1 Connect the centers of the T Joiners (D) to the ends of the Middle Bar (G). Connect the Upper/Lower Bars (F) to the sides of the T Joiners (D), then connect the Joiners (H) and Side Bars (B) to the sides to complete the frame assembly. Lighty tap each joint against a hard surface to ensure all bars and joiners are full pressed in. - Page 6 STEP 2 Open the flap and straps of the Panel (A) and insert the frame, making sure the frame is fully inserted and the material is tightly stretched around it. Snug Fit: Fabric on panel has a tight fit around the frame and may need to be stretched before inserting the frame.
- Page 7 STEP 4 Place Mounting Clips (C) in the center of each exposed portion of Upper/Lower Bars (F). Make sure the wire management flap on Panel (A) is facing upward. STEP 5 Secure Mounting Clips (C) to Clamps (E) in one of two mounting locations using M4x6mm Screws (S-A).
- Page 8 STEP 6 Mount the assembled panel to the desktop and tighten Clamps (E) to secure the assembly in place. STEP 7 Route and organize the cables and secure them using the flap on the panel (A).
- Page 9 Optional: Under Desk Mounting STEP 1 Place Mounting Clips (C) in the center of each exposed portion of Upper/Lower Bars (F). Make sure the wire management flap on Panel (A) is facing the inside of the desktop. STEP 2 Center the assembled panel under the desktop and use a pencil to mark the locations of Mounting Clips (C).
- Page 10 STEP 3 Mount the assembled panel to the underside of the desk using ST4.8x19mm Screws (S-B). Pre-Drilling Instructions Drill mounting holes using illustration below. 6/50” (3mm) Drill Bit 0.63” (16mm) Hole Depth Desktop must be at least 1” thick to prevent screws from poking through the top and damaging the surface.
- Page 11 STEP 4 Route and organize the cables and secure them using the flap on Panel (A).
-
Page 12: Last Updated
LAST UPDATED: 6/28/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
