INSTALLATION MANUAL
DI-100
DIRECT SELECT INTERFACE
DI-110
Please follow the instructins in this manual to obtain the optimum results from these units.
We also recommend that you keep this manual handy for future reference.
TOA Electronics, Inc.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DI-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa DI-100

Summary of Contents for Toa DI-100

  • Page 1 INSTALLATION MANUAL DI-100 DIRECT SELECT INTERFACE DI-110 Please follow the instructins in this manual to obtain the optimum results from these units. We also recommend that you keep this manual handy for future reference. TOA Electronics, Inc.

  • Page 2: Table Of Contents

    WARNING : (For USA only) This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subject J of Part 15 of FCC Rules, which are designed to provide reasonable protection from such interference when operated in a commercial environment.

  • Page 3: General Description

    LEDÕs on the control panel or numerically in the associated ASÐ100A or ASÐ110. 3. SYSTEM CONFIGURATION IC-100 MU-110 LU-100 LU-200 POWER SUPPLY (24V DC) 2 x Twisted pair cable DI-100 DI-110 DI-110 DI-110 DIRECT SELECT CONTROL STATION 2 x Twisted pair cable + 3 conductors AS-100A AS-110 SWITCH &...

  • Page 4: Principle Of Operation And Block Diagram

    100 also transmits a flashing or steady LED signal, relay control signal, etc. to the DIÐ110, and can periodically scan the control panel switches. 4.2 Block Diagram (Z80) OUTPUT PORT DI-100 CALL-IN BUSY CCTV RELAY DI-110 5. SYSTEM DESIGNING PROCEDURE (1) Determine number of ports needed in the system.

  • Page 5: Installation

    6. INSTALLATION WARNING : TURN OFF ALL POWER TO THE SYSTEM BEFORE UNPLUGGING OR PLUGGING IN CONNECTORS TO THE CARDS. THESE CARDS CONTAIN CMOS ICÕS AND MAY BE DAMAGED BY STATIC DISCHARGE. IT IS ADVISABLE TO WEAR AN EARTH GROUNDED WRIST STRAP WHEN HANDLING THE CARDS.
  • Page 6 Install the DIÐ100/DIÐ110Õs inside the control panel shown in Fig. 5 with stand-offs or use the CKÐ100 and install at the equipment rack. Connect the cards with the ribbon cables as shown below. DI-110 (4) DI-110 (3) DI-110 (2) DI-110 (1) DI-100 DI-110 SW 1 SW 2 DI-110 (8) DI-110 (7)

  • Page 7: Wiring The Ledõs

    Wire switches (PTT, indication reset to the DIÐ100 and direct call, response, etc. to the DIÐ110) as shown in Fig 7 and Tables 5 and 6. Use an alternate (locked) type switch for the INHIBIT switch. DI-100/110 1 mA COMMON (Fig.

  • Page 8: Wiring Of Relay Outputs

    CN5-1 CN5-2 CN5-3 CN5-4 CN5-5 CN5-6 CN5-7 CN5-8 CN5-9 CN5-10 COMMON CN5-31~50 6.6 Wiring to the ASÐ110 Wire as shown in Fig. 9 DI-100 SELECT SW No. CONNECTOR PIN CN4-25 CN4-26 CN4-27 CN4-28 CN4-29 CN4-30 CN4-31 CN4-32 CN4-33 CN4-34 CCTV EQUIPMENT (Fig.

  • Page 9: Wiring To The Asð100A

    6.7 Wiring TO THE ASÐ100A Wire as shown in Fig. 10 DI-100 TWISTED PAIR CABLE 6.8 Wiring to the LU Cards Wire between the DIÐ100 and the LU card as shown in Fig. 11 DI-100 TWISTED PAIR CABLE 6.9 Power Supply Connection 24V + –...

  • Page 10: Testing Contents

    LU-100 LU-200 PERSONAL COMPUTER (IBM PC) (XX) XX : Register No. POWER SUPPLY (24V DC) 2 x Twisted pair cable DI-100 DI-110 DI-110 DI-110 DIRECT SELECT CONTROL STATION 2 x Twisted pair cable + 3 conductors AS-100A AS-110 SWITCH &...

  • Page 11: Programming With The Ibm Personal Computer

    ¥ Registration 1) Station digit number registration 2) Relay output mode setting 3) Registration of number of DI 11- cards to be connected to the DI-100 Whenever programming each DI-100, register number of DI-110 cards to be connected to the DI-100 4) Switch/station number assignment (individual registration) ¥...

  • Page 12: Operation

    9. OPERATION 9.1 Calling (1) Dial the desired station number with dial keys, or (2) Press the corresponding SELECT switch on the control panel (instantaneous call). 9.2 Being Called (When in Continuous Call Tone Mode) (1) The corresponding CALL-IN LED flashes simultaneously with a call tone. Flashing speed differs depending on the priority level assigned to each station.

  • Page 13: Programming Sheet

    10. PROGRAMMING SHEET DIÐ110 (1) SW No. SUBSTATION No. DIÐ110 (4) SW No. SUBSTATION No. DIÐ110 (2) SW No. SUBSTATION No. DIÐ110 (5) SW No. SUBSTATION No. DIÐ110 (3) SW No. SUBSTATION No. DIÐ110 (6) SW No. SUBSTATION No.
  • Page 14 DIÐ110 (7) SW No. SUBSTATION No. DIÐ110 (10) SW No. SUBSTATION No. DIÐ110 (8) SW No. SUBSTATION No. DIÐ110 (11) SW No. SUBSTATION No. DIÐ110 (9) SW No. SUBSTATION No. DIÐ110 (12) SW No. SUBSTATION No.
  • Page 15 DIÐ110 (13) SW No. SUBSTATION No. DIÐ110 (16) SW No. SUBSTATION No. DIÐ110 (14) SW No. SUBSTATION No. DIÐ110 (17) SW No. SUBSTATION No. DIÐ110 (15) SW No. SUBSTATION No. DIÐ110 (18) SW No. SUBSTATION No.
  • Page 16 DIÐ110 (19) SW No. SUBSTATION No. DIÐ110 (22) SW No. SUBSTATION No. DIÐ110 (20) SW No. SUBSTATION No. DIÐ110 (23) SW No. SUBSTATION No. DIÐ110 (21) SW No. SUBSTATION No. DIÐ110 (24) SW No. SUBSTATION No.
  • Page 17 DIÐ110 (25) SW No. SUBSTATION No. DIÐ110 (28) SW No. SUBSTATION No. DIÐ110 (26) SW No. SUBSTATION No. DIÐ110 (29) SW No. SUBSTATION No. DIÐ110 (27) SW No. SUBSTATION No. DIÐ110 (30) SW No. SUBSTATION No.
  • Page 18 DIÐ110 (31) SW No. SUBSTATION No. DIÐ110 (34) SW No. SUBSTATION No. 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 1020 DIÐ110 (32) SW No. SUBSTATION No. DIÐ110 (35) SW No.

  • Page 19: Specifications

    11. SPECIFICATIONS Master stations Maximum number of interface cards Maximum number of ports per DI–110 Maximum number of ports per system Maximum distance, exchange to DI–100/DI–110 and to AS–100A/AS–110 DI–100 inputs DI–100 outputs DI–110 inputs DI–110 outputs Power requirement Custom or off-the-street control panel switch rating Functions Terminations * Specifications are subject to change without notice.
