Toa D-901 Specifications

Partner: TOA
Model: D-901
Device Type: Digital Mixer

GENERAL INFORMATION

SIMPLWINDOWS NAME:
CATEGORY:
VERSION:
SUMMARY:
GENERAL NOTES:

CRESTRON HARDWARE REQUIRED:

SETUP OF CRESTRON HARDWARE:

VENDOR FIRMWARE:

VENDOR SETUP:

CABLE DIAGRAM:

TOA D-901 Digital Mixer Crosspoint.umc
Mixer
1.0
This module controls one of many possible crosspoints within the Toa D-901 Digital
Mixer.
This module controls one of many possible crosspoints within the Toa D-901 Digital
Mixer. It allows the control of crosspoint level and crosspoint on/off activation. It will
also provide true feedback indicating current level and channel on/off activation.
By using the SCA (Source Channel Attribute), SCN (Source Channel Number), DCA
(Destination Channel Attribute), DCN (Destination Channel Number) parameter pull
down menus, a crosspoint is selected and can be controlled. Multiple instances of
this module may be used. It is recommended to trigger the Polling option on all used
modules by routing the "Poll_Finished" signal from the first module to the next
module's Poll_Enable input. This allows all D-901 Mixer Modules to poll sequentially.
Please refer to the DEMO PRO2 file for an example of this procedure.
CNCOMH-2, CNXCOM-2, ST-COM, C2-COM
RS232
Baud: 115200
Parity: N
Data Bits: 8
Stop Bits: 1
2.0
Set RS232 Mode to REMOTE
CNSP-121
