Toa SR-A12L Specifications

TYPE A SERIES LINE ARRAY SPEAKER SYSTEM
SR-A12L/SR-A12LWP
Photo: SR-A12LWP
DESCRIPTION
Type A Series line array speakers deliver higher output and
wide bandwidth sound in a compact configuration that can be
combined with other units to provide high-fidelity sound
permanent installation solutions in environments exhibiting
severe acoustic problems. Two Type A Series speakers are
available, SR-A12L designed to transmit sound over
distance with a 5-degree taper, and SR-A12S with a 15-
degree taper optimized for effective short range coverage.
Each configuration incorporates a 30cm (12") low frequency
driver and a high frequency horn with 2 compression high
frequency drivers. A separate subwoofer unit SR-A18B is also
available for low frequency augmentation.
Line Array Speaker Standard Speaker
SR-A12S/SR-A12SWP
Photo: SR-A12S
SR-A18B
FEATURES
●
Designed for wide bandwidth response
These compact and powerful 2-way modular speaker units
can be used in multiple configurations as required to deliver
greater output power with a more extended frequency
response.
●
High-performance driver units
Each Type A Series speaker module contains a 30cm (12")
low frequency unit and a high-frequency horn attached to
two compression drivers for greater output.
●
Wavefront control
The horn incorporates a proprietary phase wavefront
control throat that functions to obtain the best possible
performance from the high frequency drivers.
●
Adjustable sound coverage
Type A Series provides two speaker configurations
designed for specific coverage characteristics, each having
a different taper. The 5-degree taper is for effectively
transmitting sound over distance while the 15-degree taper
is optimized for excellent short range coverage.
●
Simple maintenance
Maintenance and servicing are made easier on the Type A
Series to suit it for permanent installations. All driver
replacement is possible from the speaker's rear, a simple
and speedy procedure.
