- Page 1 HM65X Digital Mobile Radio User Manual Hytera Communications Corporation Limited...
- Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid bodily injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use.
- Page 3 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.
-
Page 4: Table Of Contents
User Manual Contents Contents Documentation Conventions ........................1 1. Packing List .............................. 2 2. Product Layout ............................3 3. Installation ..............................4 3.1 Precautions ............................4 3.2 Tools ..............................4 3.3 Parts ..............................5 3.4 Procedure ............................. 6 4. Basic Operations ............................7 4.1 Turn On or Off the HM65X ........................ - Page 5 Contents User Manual 7.4.3 Quick GPS ..........................15 7.5 BT ............................... 15 7.5.1 Enable BT ..........................16 7.5.2 Connect to a BT Device ......................16 7.5.3 Switch the Audio Output Path ....................16 8. Safety and Security ..........................17 8.1 Horn & Lights ............................17 8.2 Emergency ............................
-
Page 6: Documentation Conventions
User Manual Documentation Conventions Documentation Conventions Icon Conventions Icon Description Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage. Indicates situations that could cause major personal injury or even death. Notation Conventions Item Description... -
Page 7: Packing List
Packing List User Manual 1. Packing List Unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Quantity (PCS) Item Quantity (PCS) HM65X Power Cord (with fuse) Mounting Bracket Self-tapping Screw (4.8 mm x 20 mm) Locking Knobs Self-tapping Screw (4 mm x 16 mm) -
Page 8: Product Layout
User Manual Product Layout 2. Product Layout HM65X The GNSS antenna is available only for the HM65X with the Location feature. Palm Microphone You can request your dealer to program the Top Key (TK), P1 key, and P2 key as shortcuts to assignable features. -
Page 9: Installation
Installation User Manual 3. Installation 3.1 Precautions Before installation, read the following guidelines carefully: Before installation, ensure that the vehicle power supply has a negative ground with the voltage of 13.6±15% V. Before installation, measure the length of screws protruding from the HM65X surface. During installation, drill the holes on the vehicle according to the screw length to avoid damaging the vehicle wires or other components. -
Page 10: Parts
User Manual Installation 3.3 Parts Part Name Part Name HM65X Self-tapping Screw (4 mm x 16 mm) Locking Knobs Microphone Hanger Mounting Bracket GNSS Antenna Self-tapping Screw (4.8 mm x 20 mm) Power Cord (with fuse) Palm Microphone RF Antenna ... -
Page 11: Procedure
Installation User Manual 3.4 Procedure Install the HM65X. Select a location on the vehicle. Hold the mounting bracket to the location, and then mark the mounting holes. Drill holes at the marks. Use the screws (4.8 mm x 20 mm) to secure the mounting bracket. Connect the RF antenna, GNSS antenna, and power cord to the HM65X. -
Page 12: Basic Operations
User Manual Basic Operations 4. Basic Operations 4.1 Turn On or Off the HM65X On the HM65X or the Palm Microphone, long press the On-Off key. Upon connection to the power supply, the HM65X automatically turns on. 4.2 Adjust the Volume You can adjust the volume through the Palm Microphone. -
Page 13: Select The Zone
Basic Operations User Manual 4.6 Select the Zone You can select a zone through the Palm Microphone. On the home screen, press key to locate the cursor to the zone No., and then press the key. Press the preprogrammed Zone Up or Zone Down key. 4.7 Select the Channel You can select a channel through the Palm Microphone. -
Page 14: Status Indications
User Manual Status Indications 5. Status Indications 5.1 LCD Icons You can learn about the operating status through the LCD display on the Palm Microphone. Icon Description The HM65X detects no signal. More bars indicate stronger signal. The HM65X operates in low power mode. The HM65X operates in high power mode. -
Page 15: Led Indicator
Status Indications User Manual Icon Description The HM65X is on an all call. The HM65X is making or receiving an all call. 5.2 LED Indicator You can learn about the operating status through the LED indicators on the HM65X and the Palm Microphone. LED Indicator Radio Status Flashes green... -
Page 16: Call Services
User Manual Call Services 6. Call Services To ensure optimal voice quality on the receiving radio, keep the microphone 2.5 cm to 5 cm away from your mouth during speaking. 6.1 Calls on Digital Channel On the digital channel, you can make the following calls to the preset contacts. Call Type Description Group Call... -
Page 17: Calls On Analog Channels
Call Services User Manual 6.2 Calls on Analog Channels 6.2.1 Make a Call Without Signaling On an analog channel without signaling, you can make a call to all the other users on the channel. Select an analog channel according to 4.7 Select the Channel. -
Page 18: Basic Settings
User Manual Basic Settings 7. Basic Settings 7.1 Power Level To adjust the power level to high or low, press the preprogrammed Power Level Adjust key. 7.2 Audio 7.2.1 Microphone and Speaker The HM65X features no microphone or speaker, so you need to connect an audio accessory to the HM65X. You can switch the audio modes of the microphone and speaker only when you connect the following accessories to the HM65X simultaneously: ... -
Page 19: Mic Agc
Basic Settings User Manual 7.2.2 Mic AGC Mic AGC allows the transmitting HM65X to control the voice output gain within a proper range during transmission, so as to provide improved voice with proper volume for the receiving party. This feature ensures stable voice even in noisy environment. -
Page 20: Voice With Location
User Manual Basic Settings 7.4.1 Voice with Location Voice with Location allows the HM65X to report its position information when making a private call, a group call, or an emergency call. To send voice with location, press the PTT key. ... -
Page 21: Enable Bt
Basic Settings User Manual 7.5.1 Enable BT Press the preprogrammed BT key. If your dealer enable both BT and BT Visibility, the HM65X automatically enables BT and is always discoverable by other BT devices upon power-on. 7.5.2 Connect to a BT Device Only after the connection between the HM65X and the BT device is established, the HM65X can automatically search and connect to the BT device. -
Page 22: Safety And Security
User Manual Safety and Security 8. Safety and Security 8.1 Horn & Lights To remind you to respond an emergency alarm, call alert, or private call in time, Horn & Lights triggers the HM65X to alarm through the external alarm devices (speaker or light) if you have no operations within the preset duration. You can request your dealer to configure any of the following types of Horn &... -
Page 23: Make An Emergency Call
Safety and Security User Manual Emergency Mode Description Note Allows you to send an emergency code and initiate an emergency emergency Alarm w/Call call. type is Siren Only or Alarm w/Siren, you do not need to set the Alarm Allows you to send an emergency code. emergency mode. -
Page 24: Encryption
User Manual Safety and Security To enable or disable Lone Worker, press the preprogrammed Lone Worker key. To configure Lone Worker, contact your dealer. 8.4 Encryption Encryption refers to end-to-end encryption (E2EE), which protects voice and data against eavesdropping. To enable or disable Encryption, press the preprogrammed Scrambler/Encrypt key. ... -
Page 25: Advanced Pmr Features
Advanced PMR Features User Manual 9. Advanced PMR Features To configure features in this chapter, contact your dealer. 9.1 One Touch Call One Touch Call allows you to initiate a preset service by pressing the preprogrammed One Touch Call key. You can choose any of the following preset services: Channel Type Services... -
Page 26: Squelch Level
User Manual Advanced PMR Features out of the repeater's coverage. To enable or disable Talk Around, press the preprogrammed Talk Around key. 9.5 Squelch Level Squelch Level refers to the squelch threshold required for the speaker of the Palm Microphone. The higher squelch level requires a stronger signal. -
Page 27: Public Address
Advanced PMR Features User Manual are configured by your dealer. Type Description Operation Allows you to turn on or off the HM65X To turn on the HM65X, start the engine or by the engine or the On-Off key. long press the On-Off key. Ignition or Switch ... -
Page 28: Troubleshooting
User Manual Troubleshooting 10. Troubleshooting Phenomena Analysis Solution The HM65X fails be The power cord may be disconnected. Connect the power cord properly. turned on. The voice is unclear. The signal may be weak. Make sure that call participants are within the communication range. - Page 29 Troubleshooting User Manual Phenomena Analysis Solution The HM65X may be in an unfavorable position. For Move to an open and flat area. example, the signal may be blocked by high-rise Restart the HM65X. buildings or frustrated in the underground areas. The HM65X may suffer from external disturbance Stay away from the equipment that (such as electromagnetic interference).
-
Page 30: Care And Cleaning
User Manual Care and Cleaning 11. Care and Cleaning To guarantee optimum performance as well as a long service life of the product, please follow the tips below. 11.1 Product Care Do not pierce or scrape the product. Keep the product away from substances that can corrode the circuitry. ... -
Page 31: Optional Accessories
Optional Accessories User Manual 12. Optional Accessories Use the accessories approved by the Company only. Otherwise, we will not be liable for any loss or damage arising out of the use of unauthorized accessories. Contact your local dealer for the optional accessories used with the HM65X. -
Page 32: Abbreviations
User Manual Abbreviations 13. Abbreviations Abbreviation Full Name E2EE End-to-End Encryption Global Positioning System GNSS Global Navigation Satellite System Liquid-Crystal Display Light-Emitting Diode Push-To-Talk Radio Registration Services Top Key Extended Pseudo Trunk... - Page 33 Hytera Communications Corporation Limited. © 2022 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
