Summary of Contents for Hytera HM652
- Page 1 HM652 Digital Mobile Radio User Manual Hytera US Inc 8 Whatney, Irvine, CA 92816...
- Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid bodily injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use.
- Page 3 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited and retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.
-
Page 4: Table Of Contents
3.3 Parts ..............................5 3.4 Procedure ............................. 6 4. Basic Operations ............................7 4.1 Turn On or Off the HM652 ........................7 4.2 Adjust the Volume ..........................7 4.3 Switch Between Day and Night Modes ....................7 4.4 Set the Backlight to Always On ......................7 4.5 Lock or Unlock the Key ........................ - Page 5 Contents User Manual 7.4.3 Quick GPS ..........................15 7.5 BT ............................... 15 7.5.1 Enable BT ..........................16 7.5.2 Connect to a BT Device ......................16 7.5.3 Switch the Audio Output Path ....................16 8. Safety and Security ..........................17 8.1 Horn & Lights ............................17 8.2 Emergency ............................
-
Page 6: Documentation Conventions
User Manual Documentation Conventions Documentation Conventions Icon Conventions Icon Description Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage. Indicates situations that could cause major personal injury or even death. Notation Conventions Item Description... -
Page 7: Packing List
Self-tapping Screw (4 mm x 16 mm) Palm Microphone Documentation Kit Microphone Hanger Figures in this manual are only for reference. Check whether the frequency band marked on the antenna label matches that on the HM652 label. If not, contact your dealer. -
Page 8: Product Layout
2. Product Layout HM652 The GNSS antenna is available only for the HM652 with the Location feature. Palm Microphone You can request your dealer to program the Top Key (TK), P1 key, and P2 key as shortcuts to assignable features. -
Page 9: Installation
When replacing the fuse for the DC power cord, ensure the new fuse shares the same specification with the old one. If any other communication devices such as repeaters are near the HM652, keep the antenna of these devices at least 10 meters away from that of the HM652. -
Page 10: Parts
Microphone Hanger Mounting Bracket GNSS Antenna Self-tapping Screw (4.8 mm x 20 mm) Power Cord (with fuse) Palm Microphone RF Antenna The RF antenna is optional. The GNSS antenna is available only for the HM652 with the Location feature. ... -
Page 11: Procedure
Use the screws (4 mm x 16 mm) to secure the microphone hanger. Align the triangle index on the Palm Microphone with the installation index on the HM652. Plug the aviation connector on the Palm Microphone into the aviation port on the HM652, and then rotate the connector clockwise to secure it. -
Page 12: Basic Operations
Basic Operations 4. Basic Operations 4.1 Turn On or Off the HM652 On the HM652 or the Palm Microphone, long press the On-Off key. Upon connection to the power supply, the HM652 automatically turns on. 4.2 Adjust the Volume You can adjust the volume through the Palm Microphone. -
Page 13: Select The Zone
Basic Operations User Manual 4.6 Select the Zone You can select a zone through the Palm Microphone. On the home screen, press key to locate the cursor to the zone No., and then press the key. Press the preprogrammed Zone Up or Zone Down key. 4.7 Select the Channel You can select a channel through the Palm Microphone. -
Page 14: Status Indications
The HM652 is making or receiving a private call. The HM652 is on a group call. The HM652 is making or receiving a group call. The HM652 is on an emergency group call. The HM652 is making or receiving an emergency group call. -
Page 15: Led Indicator
The HM652 is on an all call. The HM652 is making or receiving an all call. 5.2 LED Indicator You can learn about the operating status through the LED indicators on the HM652 and the Palm Microphone. LED Indicator Radio Status The HM652 is being turned on. -
Page 16: Call Services
User Manual Call Services 6. Call Services To ensure optimal voice quality on the receiving radio, keep the microphone 2.5 cm to 5 cm away from your mouth during speaking. 6.1 Calls on Digital Channel On the digital channel, you can make the following calls to the preset contacts. Call Type Description Group Call... -
Page 17: Calls On Analog Channels
Call Services User Manual 6.2 Calls on Analog Channels 6.2.1 Make a Call Without Signaling On an analog channel without signaling, you can make a call to all the other users on the channel. Select an analog channel according to 4.7 Select the Channel. -
Page 18: Basic Settings
7.2.1 Microphone and Speaker The HM652 features no microphone or speaker, so you need to connect an audio accessory to the HM65X. You can switch the audio modes of the microphone and speaker only when you connect the following accessories... -
Page 19: Mic Agc
To enable or disable AI-based Noise Cancellation, press the preprogrammed AI-based Noise Cancellation key. To configure AI-based Noise Cancellation, contact your dealer. 7.3 USB Path You can select a USB path for communication between the HM652 and peripheral devices. For details, see the following table: Option... -
Page 20: Voice With Location
To send voice with location, press the PTT key. To enable Voice with Location, contact your dealer. You can ask your dealer to set the HM652 to send the position information only once or periodically in a preset interval. -
Page 21: Enable Bt
User Manual 7.5.1 Enable BT Press the preprogrammed BT key. If your dealer enable both BT and BT Visibility, the HM652 automatically enables BT and is always discoverable by other BT devices upon power-on. 7.5.2 Connect to a BT Device Only after the connection between the HM652 and the BT device is established, the HM652 can automatically search and connect to the BT device. -
Page 22: Safety And Security
To remind you to respond an emergency alarm, call alert, or private call in time, Horn & Lights triggers the HM652 to alarm through the external alarm devices (speaker or light) if you have no operations within the preset duration. -
Page 23: Make An Emergency Call
Turn off the HM652. 8.3 Lone Worker Lone Worker allows the HM652 to automatically send an emergency alarm to your companion or the control center in either of the following scenarios: You do not operate the HM652 within the preset time. -
Page 24: Encryption
Emergency Erase Data allows the HM652 to erase encrypted data in emergencies, so as to prevent unauthorized access. When erasing the data, the HM652 stops voice and data services and the Palm Microphone returns to the home screen. The data can be erased in the following scenarios: ... -
Page 25: Advanced Pmr Features
Roam allows the HM652 to select base stations according to signal strength. This ensures seamless communication across sites or networks. To enable or disable Roam, press the preprogrammed Roam key. 9.4 Talk Around Talk Around allows you to continue communication in direct mode when the repeater malfunctions or the HM652 is... -
Page 26: Squelch Level
9.8 Ignition Sense Ignition Sense controls the HM652 on or off and the PTT key enabled or disabled by starting or stopping your vehicle. Four types of ignition sense are listed in the following table. The default type is Disable Ignition Off, and other types... -
Page 27: Public Address
To enable or disable Public Address, press the preprogrammed Public Address key. 9.10 XPT In the Extended Pseudo Trunk (XPT) system, the HM652 can communicate with each other on the logic channels of all repeaters, no longer limited to a dedicated control channel. This improves the channel usage and ensures... -
Page 28: Troubleshooting
There are unknown voices or noises on the Set signaling for all member radios channel. The HM652 may be set with no signaling. to avoid interference at the same frequency. There is too much Make sure that call participants are The signal may be weak. - Page 29 Troubleshooting User Manual Phenomena Analysis Solution The HM652 may be in an unfavorable position. For Move to an open and flat area. example, the signal may be blocked by high-rise Restart the HM652. buildings or frustrated in the underground areas.
-
Page 30: Care And Cleaning
User Manual Care and Cleaning 11. Care and Cleaning To guarantee optimum performance as well as a long service life of the product, please follow the tips below. 11.1 Product Care Do not pierce or scrape the product. Keep the product away from substances that can corrode the circuitry. ... -
Page 31: Optional Accessories
12. Optional Accessories Use the accessories approved by the Company only. Otherwise, we will not be liable for any loss or damage arising out of the use of unauthorized accessories. Contact your local dealer for the optional accessories used with the HM652. -
Page 32: Abbreviations
User Manual Abbreviations 13. Abbreviations Abbreviation Full Name E2EE End-to-End Encryption Global Positioning System GNSS Global Navigation Satellite System Liquid-Crystal Display Light-Emitting Diode Push-To-Talk Radio Registration Services Top Key Extended Pseudo Trunk... - Page 33 © 2023 Hytera US Inc. All Rights Reserved. 8 Whatney, Irvine, CA 92840 support@hytera.us https://www.hytera.us...
