INVERTER SERIE H6
Installation and owner's
manual
MUPR-H6
Thank you very much for purchasing our products.
CL20015 to CL20018
Please read this manual carefully before installing
English
and using the unit.
www.mundoclima.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUPR-H6 and is the answer not in the manual?

Questions and answers

Related Manuals for mundoclima MUPR-H6

Summary of Contents for mundoclima MUPR-H6

  • Page 1 INVERTER SERIE H6 Installation and owner's manual MUPR-H6 Thank you very much for purchasing our products. CL20015 to CL20018 Please read this manual carefully before installing English and using the unit. www.mundoclima.com...
  • Page 2 MUPR-H6 All Easy IMPORTANCE NOTICE IMPORTANT Thank you for selectiong super quality Air Conditiones. To ensure satisfactory operation for many ears to come, this manual should be read carefully before the installation and before using the air conditioner. After reading, store it a safe place.
  • Page 3 MUPR-H6 All Easy CONTENTS Installation manual ..........4 Owner's manual ..........36 Remote controller manual ......... 54...

  • Page 4: Table Of Contents

    Installation Manual Safety Precautions ......6 Accessories ........8 Installation Summary - Indoor Unit ..Unit Parts ........12 Indoor Unit Installation ..13 1. Select installation location ......13 2. Attach mounting plate to wall ....14 3. Drill wall hole for connective piping ..14 4.
  • Page 5 Refrigerant Piping Connection ..27 A. Pipe Length and additional charge ........27 B. Connection Instructions –Refrigerant Piping ....27 1. Cut pipe ................27 2. Remove burrs ..............28 3. Flare pipe ends ..............4. Connect pipes ..............29 Air Evacuation .......

  • Page 6: Safety Precautions

    Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. This symbol indicates that ignoring instructions may cause death or serious injury.
  • Page 7 WARNING 6. For all electrical work, follow all local and national wiring standards, regulations, and the Installation Manual. You must use an independent circuit and single outlet to supply power. Do not connect other appliances to the same outlet. Insufficient electrical capacity or defects in electrical work can cause electrical shock or fire.

  • Page 8: Accessories

    ACCESORIES The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and fire, or cause the equipment to fail. Name Shape Quantity...
  • Page 9 Name Shape Quantity INVERTER SERIE H6 - ALL EASY Installation and owner's manual MUPR-H6 Installation and Owner's manual CL20015 to CL20018 www.mundoclima.com English...

  • Page 10: Installation Summary - Indoor Unit

    INSTALLATION SUMMARY - INDOOR UNIT 150 mm 120 mm 120 mm 2300 mm Select Installation Location Determine Wall Hole Position (Page 11) (Page 12) Attach Mounting Plate Drill Wall Hole (Page 12) (Page 12)
  • Page 11 Connect Piping Connect Wiring Prepare Drain Hose (Page 25) (Page 17) (Page 14) Wrap Piping and Cable (Page 18) STEP Mount Indoor Unit (Page 18)

  • Page 12: Unit Parts

    UNITS PARTS Wall Mounting Plate Front Panel Louver Drainage Pipe Air filter (pull it out) Signal Cable Refrigerant Piping Remote Control Remote Holder Power Cable Fig.3.1 NOTE ON ILLUSTRATIONS Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly different.

  • Page 13: Indoor Unit Installation

    INDOOR UNIT INSTALLATION DO NOT install unit in the following Installation Instructions – Indoor locations: Unit Near any source of heat, steam, or combustible gas PRIOR TO INSTALLATION Near flammable items such as curtains or Before installing the indoor unit, refer to the clothing label on the product box to make sure that the model number of the indoor unit matches the...

  • Page 14: Attach Mounting Plate To Wall

    Refer to the following diagram to ensure proper distance from walls and ceiling: 150 mm or more 120 mm or more 120 mm or more 2300 mm Fig. 4.1 Step 2: Attach mounting plate to wall Step 3: Drill wall hole for connective piping The mounting plate is the device on which you You must drill a hole in the wall for refrigerant will mount the indoor unit.
  • Page 15 717 mm Wall 412 mm 128 mm 237 mm Indoor Outdoor Indoor unit outline Left rear wall Right rear wall hole 65 mm hole 65 mm 117 mm 107 mm 137 mm 39 mm MUPR-09-H6 805 mm 427.9 mm 224.6 mm 163 mm Indoor unit outline Fig.3.2...

  • Page 16: Prepare Refrigerant Piping

    Step 4: Prepare refrigerant piping If refrigerant piping is already embedded in the wall, do the following: The refrigerant piping is inside an insulating sleeve attached to the back of the unit. You must Step 4.1:Hook the indoor unit on the mounting prepare the piping before passing it through the plate: hole in the wall.
  • Page 17 Step 4.3. Connect drain hose and refrigerant piping (refer to Refrigerant Piping Connection section of this manual for instructions). Step 4.4. Keep pipe connection point exposed to perform the leak test (refer to Electrical Checks and Leak Checks section of this manual). Step 4.5.

  • Page 18: Connect Drain Hose

    PLUG THE UNUSED DRAIN HOLE 4. Connect the indoor unit’ s refrigerant piping to the connective piping that will join the To prevent unwanted leaks you must plug indoor and outdoor units. Refer to the the unused drain hole with the rubber plug Refrigerant Piping Connection section provided.

  • Page 19: Connect Signal Cable

    BEFORE PERFORMING WARNING ELECTRICAL WORK, BEFORE PERFORMING ANY ELECTRICAL READ THESE REGULATIONS OR WIRING WORK, TURN OFF THE MAIN 1. All wiring must comply with local and POWER TO THE SYSTEM. national electrical codes, and must be installed by a licensed electrician. Step 6: Connect signal cable 2.
  • Page 20 TAKE NOTE OF FUSE SPECIFICATIONS WARNING The air conditioner’ s circuit board (PCB) is ALL WIRING MUST PERRFORMED STRICTLY designed with a fuse to provide overcurrent IN ACCORDANCE WITH THE WIRING protection. The specifications of the fuse DIAGRAM LOCATED ON THE INSIDE OF THE are printed on the circuit board, such as: ’...

  • Page 21: Wrap Piping And Cables

    Step 7: Wrap piping and cables DO NOT WRAP ENDS OF PIPING Before passing the piping, drain hose, and the When wrapping the bundle, keep the ends signal cable through the wall hole, you must of the piping unwrapped. You need to access bundle them together to save space, protect them to test for leaks at the end of the them, and insulate them.

  • Page 22: Outdoor Unit Installation

    OUTDOOR UNIT INSTALLATION Installation Instructions – Outdoor Unit Step 1: Select installation location Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: ...

  • Page 23: Install Drain Joint

    If the drain joint comes with a rubber seal SPECIAL CONSIDERATIONS FOR EXTREME (see Fig. 4.4 - A), do the following: WEATHER 1. Fit the rubber seal on the end of the drain joint If the unit is exposed to heavy wind: that will connect to the outdoor unit.

  • Page 24: Anchor Outdoor Unit

    Step 3: Anchor outdoor unit The outdoor unit can be anchored to the ground or to a wall-mounted bracket. Air inlet UNIT MOUNTING DIMENSIONS Air inlet The following is a list of different outdoor unit sizes and the distance between their mounting feet. Air outlet Prepare the installation base of the Fig.

  • Page 25: Connect Signal And Power Cables

    If you will install the unit on a wall-mounted BEFORE PERFORMING bracket, do the following: ELECTRICAL WORK, READ THESE REGULATIONS CAUTION 1. All wiring must comply with local and national electrical codes, and must be Before installing a wall-mounted unit, make installed by a licensed electrician.
  • Page 26 PA Y ATTENTION TO LIVE WIRE WARNING While crimping wires, make sure you clearly BEFORE PERFORMING ANY ELECTRICAL distinguish the Live (“L”) Wire from other wires. OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. WARNING 1. Prepare the cable for connection: ALL WIRING MUST PERFORMED STRICTLY USE THE RIGHT CABLE IN ACCORDANCE WITH THE WIRING...

  • Page 27: Refrigerant Piping Connection

    REFRIGERANT PIPING CONNECTION Pipe Length and Additional Charge The length of refrigerant piping will affect the performance and energy efficiency of the unit. Nominal efficiency is tested on units with a pipe length of 5 meters. Refer to the table below for pipes requirements: Pipes requirements Pipes Max.

  • Page 28: Remove Burrs

    DO NOT DEFORM PIPE WHILE CUTTING Flare nut Be extra careful not to damage, dent, or deform the pipe while cutting. This will drastically reduce the heating efficiency of the unit. Copper pipe Step 2: Remove burrs Burrs can affect the air-tight seal of refrigerant piping connection.

  • Page 29: Connect Pipes

    6. Place flaring tool onto the form. Instructions for Connecting Piping to 7. Turn the handle of the flaring tool clockwise Indoor Unit until the pipe is fully flared. 1. Align the center of the two pipes that you will 8.
  • Page 30 Instructions for Connecting Piping to USE SPANNER TO GRIP MAIN Outdoor Unit BODY OF VALVE Torque from tightening the flare nut can snap 1. Unscrew the cover from the packed valve on off other parts of valve. the side of the outdoor unit. (See Fig. 5.9) Valve cover Fig.

  • Page 31: Air Evacuation

    AIR EVACUATION Preparations and Precautions Evacuation Instructions Air and foreign matter in the refrigerant circuit Before using the manifold gauge and vacuum can cause abnormal rises in pressure, which pump, read their operation manuals to familiarize can damage the air conditioner, reduce its yourself with how to use them properly.
  • Page 32 Open the Low Pressure side of the manifold gauge. Keep the High Pressure side closed. Flare nut Turn on the vacuum pump to evacuate the system. Run the vacuum for at least 15 minutes, or until the Compound Meter reads -76cmHG (-10 Pa).

  • Page 33: Electrical And Gas Leak Checks

    ELECTRICAL AND GAS LEAK CHECKS WARNING – RISK OF Electrical Safety Checks ELECTRIC SHOCK After installation, confirm that all electrical wiring ALL WIRING MUST COMPLY WITH LOCAL is installed in accordance with local and national AND NATIONAL ELECTRICAL CODES, regulations, and according to the Installation AND MUST BE INSTALLED BY A LICENSED Manual.

  • Page 34: Test Run

    TEST RUN Before Test Run List of Checks to Perform PASS/FAIL No electrical leakage Only perform test run after you have completed the following steps: Unit is properly grounded • Electrical Safety Checks – Confirm that the unit’ s electrical system is safe and All electrical terminals operating properly properly covered...
  • Page 35 DOUBLE-CHECK PIPE CONNECTIONS During operation, the pressure of the refrigerant circuit will increase. This may reveal leaks that were not present during your initial leak check. Take time during the Test Manual control button Run to double-check that all refrigerant pipe connection points do not have leaks.
  • Page 36 Owner’s Manual Safety Precautions ......Unit Specifications and Features ..SAFETY FIRST Manual Operation (Without Remote) ...
  • Page 37 Care and Maintenance ......Troubleshooting ........Disposal Guidelines .........
  • Page 38 Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. This symbol indicates that ignoring instructions may cause death or serious injury.
  • Page 39 ELECTRICAL WARNINGS • Only use the specified power cord. If the power cord is damaged, it must be replaced by the manufacturer or certified service agent. • Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty plugs can cause fire or electric shock.
  • Page 40 UNIT SPECIFICACTIONS AND FEATURES Unit Parts Air Filter (pull out) Front Panel Signal Cable Louver Remote Control Display window Remote Holder “ ” for 3 seconds when: • TIMER ON is set • FRESH, SWING, TURBO, or SILENCE features are turned on “...
  • Page 41 Achieving Optimal Performance Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature ranges. When your air conditioner is used outside of these ranges, certain safety protection features will activate and cause the unit to perform less than optimally. COOL mode HEAT mode DRY mode...
  • Page 42 • Wi-Fi Control For a detailed explanation of each function, (WIFI module is required CL9438) refer to the Remote Control Manual. Wi-Fi control allows you to control your air conditioner using your mobile phone and a Other Features Wi-Fi connection. •...
  • Page 43 Setting Angle of Air Flow • Setting horizontal angle of air flow While the unit is on, use the SWING /DIRECT button to set the direction (horizontal angle) of airflow. 1. Press the SWING /DIRECT button once to activate the louver. Each time you press the button, it will adjust the louver by 6°.
  • Page 44 Sleep Operation • The SLEEP function is used to decrease energy use while you sleep (and don' t need the same temperature settings to stay comfortable). This function can only be activated via remote control. Press the SLEEP button when you are ready to go to sleep. When in COOL mode, the unit will 1°C increase the temperature by 1°C after 1 hour, and will increase an additional after another hour.
  • Page 45 MANUAL OPERATION (Whitout remoto) How to operate your unit without CAUTION the remote control The manual button is intended for testing In the event that your remote control fails to purposes and emergency operation only. Please work, your unit can be operated manually with do not use this function unless the remote is the MANUAL CONTROL button located on lost and it is absolutely necessary.
  • Page 46 CARE AND MAINTENANCE Cleaning Your Indoor Unit BEFORE CLEANING OR MAINTENANCE ALWAYS TURN OFF YOUR AIR CONDITIONER SYSTEM AND DISCONNECT ITS POWER SUPPLY BEFORE CLEANING OR MAINTENANCE. Filter Tab CAUTION Only use a soft, dry cloth to wipe the unit clean. If the unit is especially dirty, you can use a cloth soaked in warm water to wipe it clean.
  • Page 47 Maintenance – CAUTION Long Periods of Non-Use • Before changing the filter or cleaning, If you plan not to use your air conditioner for an turn off the unit and disconnect its power extended period of time, do the following: supply.
  • Page 48 TROUBLESHOOTING SAFETY PRECAUTIONS If ANY of the following conditions occurs, turn off your unit immediately! • The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
  • Page 49 Issue Possible Causes A rushing air sound may occur when the louver resets its position. The indoor unit makes noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’ s plastic parts.
  • Page 50 Troubleshooting When troubles occur, please check the following points before contacting a repair company. Problem Possible Causes Solution Temperature setting may be higher than ambient Lower the temperature setting room temperature The heat exchanger on the indoor or outdoor unit is Clean the affected heat exchanger dirty Remove the filter and clean it...
  • Page 51 Problem Possible Causes Solution Wait for the power to be Power failure restored The power is turned off Turn on the power The fuse is burned out Replace the fuse The unit is not working Remote control batteries are Replace batteries dead The Unit’...
  • Page 52 Indoor Unit Error Display Display Operation lamp Timer lamp Description ☆ 1 time Indoor unit EEPROM parameter error ☆ 2 times Indoor / outdoor units communication error ☆ 4 times Indoor fan speed has been out of control ☆ 5 times Indoor room temperature sensor T1 open circuit or short circuit ☆...
  • Page 53 DISPOSAL GUIDELINES This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law requires special collection and treatment. Do not dispose of this product as household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: •...
  • Page 54 Remote Controller Manual Specifications ........55 2 Operation of the buttons ....56 3 Indicadors on the LCD ..... How to use the buttons ....Handling the remote controller ..

  • Page 55: Specifications

    "Owner's manual" shall prevail. IMPORTANT NOTE: This remote controller is able to set different parameters, it has a function selection. For more information, please contact with Mundoclima after sales service or with your commercial sales.

  • Page 56: Operation Of The Buttons

    OPERATION OF BUTTONS ON/OFF Button This button turns the air conditioner ON and OFF. MODE Button Press this button to modify the air conditioner mode in a sequence of following: HEAT AUTO COOL FAN Button Used to select the fan speed in four steps: AUTO HIGH NOTE: You can not switch the fan speed in...
  • Page 57 SWING Button Used to stop or start horizontal louver auto swing feature. DIRECT Button Used to change the louver movement and set the desired up/down air flow direction. The louver changes 6 in angle for each press. NOTE: When the louver swing or move to a position which would affect the cooling or heating effect of the air conditioner, it would automatically change the...

  • Page 58: Indicadors On The Lcd

    INDICATORS ON LCD Mode display AUTO COOL HEAT Displayed when data transmitted. Displayed when remote controller is ON. Battery display(low battery detection) Not available for this unit Information are displayed when Displayed when TIMER ON time is set. the remote controller is powered Displayed when TIMER OFF time is set.

  • Page 59: How To Use The Buttons

    HOW TO USE THE BUTTONS Auto operation Ensure the unit is plugged in and power is available. The OPERATION indicator on the display panel of the indoor unit starts flashing. 1. Press the MODE button to select Auto. 2. Press the UP/DOWN button to set the desired temperature.
  • Page 60 Dehumidifying operation Ensure the unit is plugged in and power is available. The OPERATION indicator on the display panel of the indoor unit starts flashing. 1. Press the MODE button to select DRY mode. 2. Press the UP/DOWN buttons to set the desired temperature.
  • Page 61 To set the Auto-off time. 1. Press the TIMER OFF button. The remote controller shows TIMER OFF, the last Auto-off setting time and the signal "H" will be shown on the LCD display area. Now it is ready to reset the Auto-off time to stop the operation.
  • Page 62 (Auto-off Operation) TIMER OFF The TIMER OFF feature is useful when you want the unit to turn off automatically after you go to bed. The air conditioner will stop automatically at the set time. Example: To stop the air conditioner in 10 hours. 1.

  • Page 63: Handling The Remote Controller

    HANDLING THE REMOTE CONTROLLER Location of the remote controller Use the remote controller within a distance of 8 meters from the appliance, pointing it towards the receiver. Reception is confirmed by a beep. CAUTIONS The air conditioner will not operate if curtains, doors or other materials block the signals from the remote controller to the indoor unit.
  • Page 64 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 81 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
