Summary of Contents for mundoclima CL25620
- Page 1 MINI CHILLER INVERTER H6 Installation & Owner's manual and information requirements MUENR-H6 / MUENR-H6T CL25620 to CL25628 English www.mundoclima.com...
-
Page 3: Table Of Contents
1. INTRODUCTION CONTENTS PAGE 1.1 General information ■ These units are used for both heating and cooling applications. 1. INTRODUCTION..............They can be combined with fan coil units, floor heating 2. ACCESSORIES..............1 applications (connect the mixed station), low temperature high efficiency radiators (field supply). -
Page 4: Safety Considerations
3. SAFETY CONSIDERATIONS manual using a separate circuit. Insufficient capacity of the power supply circuit or improper electrical construction may lead to electric shocks or fire. The precautions listed here are divided into the following types. They are quite important, so be sure to follow them carefully. ■... -
Page 5: Overview Of The Unit
c) Where there is machinery which emits electromagnetic waves. Electromagnetic waves can disturb the control system and cause equipment malfunction. d) Where flammable gases may leak, where carbon fiber or ignitable dust is suspended in the air or where volatile flammables such as paint thinner or gasoline are handled. - Page 6 Refrigerant cycle i l o i t a Compressor 10 Differential Pressure Switch (only 10~16kW) 18 Thermistor For Water Inlet 4-Way Valve 11 Flow Switch (only 5/7kW) 19 Air purge Valve Gas-liquid Separator 12 Thermistor For Discharge Temperature 20 Expansion Tank Air Side Heat Exchanger (condenser) 13 Thermistor For Outdoor Temperature 21 Circulating Pump...
- Page 7 1. ELECTRICAL PANEL LAYOUT (The picture below shows the position of the diagram, please participate in the concrete photos) ⑤ ⑥ ④ ③ ② ① ⑦ ① Main control board ④ FC inductance ⑦ Customer connection terminal ② DC filter board ⑤...
- Page 8 4. Main control board (The picture is for reference only) 1.Power L 17.Electronic expansion valve 2.Power N 18.DC fan power supply port 3.Preliminary charging relay (rectifier bridge input port 1) 19.DC fan port 4.Input rectifier bridge line (rectifier bridge input port 2) 20.Remote control port 5.5A fuse 21.Force cooling switch...
- Page 9 2. Main control board (The picture is for reference only) 1.Transformer output port 16. Rectifier bridge input port L 2.Tin/Tb1/Tout/Tb2 temperature sensor port 17. 8A fuse tube Note: Tin: water inlet temp. Tout: water outlet temp. 18. Solenoid valve port (Reserved) Tb1: Temp.
- Page 10 3. PFC&IPM module board (The picture is for reference only) 1. +18V output port 2. Input Port P for IPM 3. Power supply port W of the compressor 4. Power supply port V of the compressor 5. Power supply port W of the compressor 6.
- Page 11 2. Main control board (The picture is for reference only) 1. Input port for switching power supply 14. Remote control port 2. Debugging port 15. Electronic expansion valve port 3. Connection port for operation and display panel 16. AC 220V power supply port 4.
- Page 12 3. IPM module board (The picture is for reference only) 1. +15V output port 5. Compressor connection port V 2. communication port to main 6. Compressor connection port U control board 7. IPM input P 3. IPM input port N 8.
-
Page 13: Unit Installation
5. UNIT INSTALLATION 5.1 Before installation Before installation Be sure to confirm the model name and the serial number of the unit. Handling Due to relatively large dimensions and heavy weight, the unit should only be handled using lifting tools with slings. The slings can be fitted into foreseen sleeves at the base frame that are made specifically for this purpose. - Page 14 ■ To prevent exposure to wind, install the unit with its suction side facing the wall. ■ Never install the unit at a site where the suction side may be exposed directly to wind. ■ To prevent exposure to wind, install a baffle plate on the air discharge side of the unit.
- Page 15 5.3.1 Moving and installation 5.3.2 Water Outlet Since the gravity center of the unit is not at its physical center, The condensed water outlets on the chassis for selection display so please be careful when lifting it with a sling. as the follow figure: 5/7kW Never hold the inlet of the outdoor unit to prevent it from...
- Page 16 5.4 TYPICAL APPLICATION EXAMPLES The application examples given below are for illustration purposes only. 5.4.1 Application 1 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. FCU1 FCU2 FCUn outdoor unit balance tank (field supply) Y-shape filter 9.1 air purge valve shut-off valve (field supply)
- Page 17 5.4.2 Application 2 Space heating only application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops..FHL1 FHL2 FHLn outdoor unit balance tank (field supply) Y-shape filter 9.1 air purge valve shut-off valve (field supply) 9.2 drain valve wired controller (optional)
- Page 18 5.4.3 Application 3 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops and fan coil units. Cooling is provided through the fan coil units only. FCU1 FCU2 FCUn...
- Page 19 5.4.4 Application 4 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops . Cooling is provided through the fan coil units only. The 3-way valve is used to change the direction of water flow when the operation mode changed.
- Page 20 5.4.5 Application 5 Space heating with an auxiliary boiler (alternating operation). Space heating application by either the unit or by an auxiliary boiler connected in the system. ■ The unit controlled contact (also called "permission signal for the auxiliary boiler") is required on-site, and it is recommended that the signal be determined by the outdoor temperature (thermistor located at the outdoor unit).
- Page 21 Application B If application B is selected, the control cable connect to the boiler should also connect to the 3-way valve (16) FCU1 FCU2 FCUn outdoor unit balance tank (field supply) Y-shape filter 9.1 air purge valve 9.2 drain valve shut-off valve (field supply) expansion vessel (field supply) wired controller (optional)
- Page 22 Before continuing installation of the unit, check the following: 5.5 Water pipe installation ■ The maximum water pressure can not exceed 3 bar. ■ The maximum water temperature is 60°C according to safety NOTE device setting. ■ Always use materials that are compatible with the water used in the system and with the materials used in the unit.
- Page 23 2. Check that the total water volume in the entire water circuit is ■ Because brass is a soft material, use lower than this value. appropriate tools for connecting the water If this is not the case, the expansion vessel inside the unit is too small circuit.
- Page 24 5.5.7 Fouling factors WARNING The performance data given refer to conditions with clean evaporator plates (fouling factor=1). For different fouling factors, multiply the ETHYLENE GLYCOL AND PROPYLENE GLYCOL ARE TOXIC figures in the performance tables by the coefficient given in the following table.
- Page 25 5.6.3 Electrical connection ■ Never squeeze bundled cables and make sure they do not come in contact with the piping and sharp edges. Make sure no external pressure is applied to the terminal connections. The unitary mini chillers leave the factory already wired, and require ■...
- Page 26 Electrical Power Connection Remote cooling/heating 1-phase 3-phase SWITCH 2 If switch2 is closed, the unit will shift to heating mode forcibly; If switch2 breaks the unit will shift to cooling mode forcibly. Residual Current Residual Current Circuit-breaker Circuit-breaker NOTE AC 380-415V 50Hz AC 220-240V 50Hz ●...
-
Page 27: Start-Up And Configuration
4. The Specification of Power TYPE 10kW/12kW 12kW/14kW/16kW Phase 1-Phase 1-Phase 1-Phase 3-Phase Power Frequency and Volt 220-240V~, 50Hz 220-240V~, 50Hz 220-240V~, 50Hz 380-415V~, 50Hz 25/20 Circuit Breaker / /Fuse ( A) 40/35 30/25 30/25 3x4.0 3x4.0 3x6.0 5x4.0 Power Wiring (mm Ground Wiring (mm WARNING The power cord type designation is H07RN-F. - Page 28 6.2.1 Hydraulic operational area constant speed Ⅰ,Ⅱ,Ⅲ Constant speed ⅠⅡⅢ Constant speed ⅠⅡⅢ p/kPa 4300 /min RS 15/6 RKC RS25/7.5 RKC 1~230V-Rp1 1~230V-Rp1 1/4 4640 /min p/kPa 3400 /min 2970 /min 2390 /min 1270 /min /min Q/l/s Q/l/s 16 Q/lgpm Q/lgpm 10~16kW 5/7 kW...
-
Page 29: The Host Unit Controller Elucidation
6.2.3 Static Pressure Drop Unit 6.2.4 Failure diagnosis at the moment of first installation 5/7kW ■ If nothing is displayed on the user interface, it is necessary to 70.0 check for any of the following abnormalities before diagnosing possible error codes. 60.0 ■... - Page 30 7.2 Activating and deactivating the unit 7.2.1 Icon Description The front panel of the device functions as the user interface and is used to perform all operations relating to the device. ① ② ③ ④ ⑤ ⑥ ⑧ ⑨ ⑩ Icon Description Outside heat source running icon(Reserved)
- Page 31 Icon Description Frequency unit icon It will be constantly light when the control panel displays frequency of the compressor. ON/OFF and OK button 1.Press “ ” to confirm the former operation when finishing the setting work. 2.Long press “ ” for 3S will recovers to factory default mode. Mode choice function/Function choice/Back function button 1.Mode choice function.
- Page 32 7.2.3 Functions of combination key 3.Auto-lock(unlock) function 1. Force cooling If don’t operate the controller in 60s, the keyboard will lock Press “ ” and “ ” simultaneously for 3s in the main automatically. Press “ ”and “ ” simultaneously for 3s interface to enter into force cooling mode.
-
Page 33: Trouble Shooting
7.3 Operating characteristics 5. Fan speed control For correct operation of the unit with different ambient 1. Set temperature in cooling temperatures, the microprocessor controls the fan speed based Range:10~20℃ （default：12℃） on the ambient temperature and the condensing or evaporation If the set temperature is between 10~13℃, the compressor start and temperature as well as compressor frequency, thus enabling heat shut down according to the difference between the inlet temperature... -
Page 34: Important Information For The Used Refrigerant
8.1 General guidelines 9. IMPORTANT INFORMATION FOR THE USED REFRIGERANT Before starting the troubleshooting procedure, carry out a thorough visual inspection of the unit and look for obvious defects such as This product has the fluorinated gas, it is forbidden to release to air. loose connections or defective wiring. -
Page 35: Main Parameters
10. MAIN PARAMETERS Model 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50 380-415, 3, 50 380-415, 3, 50 380-415, 3, 50 V-Ph-Hz Power supply 5.0(1.9~5.8) 7.0(2.1~7.8) 10.0(2.9~10.5) 11.2(3.1~12.0) 11.2(3.1~12.0) 12.5(3.3~14.0) 14.5(3.5~15.5) Capacity rated Input 1550 2250 2950 3500 3380... - Page 36 Product fiche 1 MUENR-05-H6 MUENR-07-H6 MUENR-10-H6 Outdoor MUENR-12-H6 Heat pump space heater Indoor Indoor unit sound power (*) [dB(A)] Outdoor unit sound power (*) 63.0 66.0 68.0 [dB(A)] 68.0 Space heating Energy efficiency class 35°C (Low temp. app.) Average climate (Design temperature = –10°C) Prated (declared heating capacity) @ –10°C 11.0 [kW]...
- Page 37 Product fiche 2 Outdoor MUENR-12-H6T MUENR-14-H6T MUENR-16-H6T Heat pump space heater Indoor Indoor unit sound power (*) [dB(A)] Outdoor unit sound power (*) [dB(A)] 68.0 70.0 72.0 Space heating Energy efficiency class 35°C (Low temp. app.) Average climate (Design temperature = –10°C) Prated (declared heating capacity) @ –10°C [kW] 12.3...
- Page 38 Heating - Information requirements for heat pump space heaters and heat pump combination heaters Model(s): MUENR-05-H6 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 39 Model(s): MUENR-07-H6 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 40 Model(s): MUENR-10-H6 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 41 Model(s): MUENR-12-H6 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 42 Model(s): MUENR-12-H6T Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 43 Model(s): MUENR-14-H6T Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 44 Model(s): MUENR-16-H6T Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application. Parameters shall be declared for average, colder and warmer climate conditions.
- Page 45 Cooling - Information requirements for comfort chillers MUENR-05-H6 Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling...
- Page 46 MUENR-07-H6 Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 47 MUENR-10-H6 Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 48 MUENR-12-H6 Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 49 MUENR-12-H6T Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 50 MUENR-14-H6T Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 51 MUENR-16-H6T Model(s): Outdoor side heat exchanger of chiller: Air to water Indoor side heat exchanger chiller: Water Type: Compressor driven vapour compression Driver of compressor: Electric motor Item Symbol Value Unit Item Symbol Value Unit Rated cooling Seasonal space cooling η...
- Page 52 16127400000001 V3.0...
- Page 54 C/ NÁPOLES 249 P1 08013 BARCELONA SPAIN (+34) 93 446 27 80 www.mundoclima.com...
