  • Page 1 User guide Multifunction pyrolytic oven OB90S9MEPX1 models...

  • Page 3: Table Of Contents

    Contents Introduction Safety and warnings The control panel Setting the clock and first use Using your oven Oven functions Using the rotisserie Using the timer Automatic cooking Baking chart User preference settings Sabbath setting Care and cleaning Using the Self Clean function Troubleshooting Alert codes Warranty and service...

  • Page 4: Introduction

    Introduction Congratulations on your new purchase. Your Fisher & Paykel oven has a number of features to make cooking a great experience for you: a choice of eight oven functions, including Rotisserie a convenient, no-mess, pyrolytic Self Clean function – see ‘Using the Self Clean function’ intuitive electronic controls and displays illuminated halos around the dials for visual feedback preference settings –...

  • Page 5: Safety And Warnings

    Safety and warnings Operation Your oven has been carefully designed to operate safely during normal cooking procedures. Please keep the following safety instructions in mind when you are using it: WARNING! Electrical Shock Hazard Disconnect the oven from the power supply before replacing the oven lamp. Failure to follow this advice may result in death or electrical shock.
  • Page 6 Safety and warnings Important safety instructions To reduce the risk of fire, electrical shock, injury to persons, or damage when using the oven, follow the important safety instructions listed below: Read all the instructions before using the oven. Use the oven only for its intended purpose as described in these instructions.
  • Page 7 Safety and warnings Important safety instructions Caution. Hot air can blow from the vent at the top of the oven as part of the oven’s cooling system. Placement of oven shelves: always position shelves in the desired location while the oven is cool (before preheating).

  • Page 8: The Control Panel

    The control panel Timer indicator (see ‘Using the timer’) Clock indicator (see ‘Setting the clock and first use’) Cooking time indicator (see ‘Automatic cooking’) Display Stop time indicator (see ‘Automatic cooking’) Select Cancel Scroll Function indicators (see ‘Oven functions’) Function dial halo Function dial (see ‘Using your oven’) Temperature indicator (see ‘Using your oven’)

  • Page 9: Setting The Clock And First Use

    Setting the clock and fi rst use Setting the clock You will need to set the clock to make full use of your oven. Ensure the power supply to Press the select button Select the clock the oven is on. to confirm.

  • Page 10: Using Your Oven

    Using your oven Guard rail Shelf positions Safety stop notch Slide in the shelves you will need, making Select a function. sure that: The halo will glow white. they are between the two wires of a shelf position the safety stop notches point down the guard rail is at the back.

  • Page 11: Oven Functions

    Oven functions Selecting this will turn the oven off. Bake This is the traditional method of baking. It is best to bake on only one shelf at a time in this function. Ideal for large cakes and dishes that bake for several hours. Fan Bake Ideal for dishes like lasagne that need to brown on top and also single trays of small cakes or biscuits that bake in less than an hour.

  • Page 12: Using The Rotisserie

    Using the rotisserie Rotate the fork screws to loosen and tighten Fork Lock stud Skewer Prepare the rotisserie supports. Secure the meat. Place the grill tray on the Important! benchtop. Take care, the forks are sharp! Insert the supports into the lock When securing the meat, ensure that: studs.
  • Page 13 Using the rotisserie Select the Rotisserie function. Set the temperature. The skewer will start rotating. We recommend around 210 °C. Check that the meat does not touch the grill tray or the grill element at the top of the oven. When you have finished using the rotisserie Turn the oven off.

  • Page 14: Using The Timer

    Using the timer You can use the timer at any time, even if you are not using the oven. If the time is more than an hour, the display will count down in minutes (hr:min). If it is less than an hour, it will count down in seconds (min:sec).

  • Page 15: Automatic Cooking

    Automatic cooking You can set the oven to automatically turn on later, cook for a preset time (cooking time), then automatically turn off at a preset stop time. See the example and instructions below (steps 1 to 7). If you start cooking manually and only want the oven to turn off automatically after a set cooking time: simply set the cooking time following steps 1 to 3 below.
  • Page 16 Automatic cooking Select function and temperature Select a function. Set the temperature. When automatic cooking is set The oven and the lights will stay off, the halos will be unlit, but your oven is now set for automatic cooking. It will automatically turn on at the required time. In a few seconds, the display will show the time of day with the cooking time and stop time indicators lit.

  • Page 17: Baking Chart

    Baking chart Please note: The settings in the following chart are guidelines only. Follow the instructions in your recipe or on food packaging and be prepared to adjust the oven settings and baking times to achieve the best possible results for you. Shelf positions are counted from the base up (1 is the lowest, 4 the highest).

  • Page 18: User Preference Settings

    User preference settings You can set your oven to: display the temperature in degrees Celsius or Fahrenheit give audio feedback (tones and beeps) or operate quietly display time as 12-hr or 24-hr operate with the display off have its lights on or off during cooking operate in Sabbath setting (see ‘Sabbath setting’...
  • Page 19 User preference settings Press the right scroll button to scroll Press the select button to save the new through the options for that particular option . setting. Refer to the table below. For all options except ‘Display off’ : press the cancel button to quit the user preference menu.

  • Page 20: Sabbath Setting

    Sabbath setting This setting is designed for religious faiths that observe a ‘no work’ requirement on the Sabbath. While your oven is in Sabbath setting The display, dial halos and indicators will be unlit, the buttons will be unresponsive. No tones or beeps will sound. No alert codes or temperature changes will be displayed.
  • Page 21 Sabbath setting Press the right scroll button to scroll to Press the right scroll button to scroll to the Sabbath setting. the ‘Sabbath on’ option. Press the select button to select the Press the select button to activate the Sabbath setting. The default option is new option.

  • Page 22: Care And Cleaning

    Care and cleaning Manual cleaning DON’Ts Before any manual cleaning or Don’t use a steam cleaner. maintenance, first wait for the oven to cool Don’t keep flammable substances in the down to a safe temperature to touch, then oven. disconnect it from the power supply. Don’t use oven cleaners or any abrasive Read these cleaning instructions and the or harsh cleaners, cloths, scouring pads or...
  • Page 23 Care and cleaning Manual cleaning What? How? Important! Always read the label to make Stainless steel Clean with a solution of mild strip on the sure that your stainless steel detergent and hot water, then wipe front of the dry with a microfibre cloth. cleaner does not contain oven door If necessary, use a suitable stainless...
  • Page 24 Care and cleaning Removing and replacing the side racks Use a flat-head screwdriver or a small coin to loosen the fixing screws. When replacing the side racks, make sure that you tighten the fixing screws.
  • Page 25 Care and cleaning Removing and replacing the door glass panes for cleaning Make sure you follow the precautions and instructions below very carefully. Replacing the glass panes and the door incorrectly may result in damage to the oven and may void your warranty. Important! Door comprises a total of 4 glass panes inner...
  • Page 26 Care and cleaning Gently close the door until the left and Hold the door firmly, as shown. right hinge levers are hooked to the door. Lift the door and disengage the hinges. Rest the door on a soft surface. Ensure you lay it with the handle side down.
  • Page 27 Care and cleaning Slide the first middle pane (C) slightly Slide the second middle pane (B) slightly towards yourself (1), then lift (2) and slide towards yourself (1), then lift (2) and slide out (3). out (3). After cleaning, replace the glass panes When replacing the glass panes, make sure that: you replace all three panes correctly, as shown.
  • Page 28 Care and cleaning Take the other middle pane and hold it firmly. Insert it in the next pair of grooves (1), push it slightly towards yourself (2) and gently lower into place (3). Angle-cut corner Take the inner pane (D), holding it with the angle-cut corner orientated as shown. Insert it in the uppermost pair of grooves (1), push it slightly towards yourself (2) and gently lower into place (3).
  • Page 29 Care and cleaning Clamp Clamp Glass retainer Position the glass retainer, as shown. It should sit on the bottom edge of the outer glass (A). Check that the clamps of the glass retainer are not deformed or damaged. “Click” Glass retainer Gently push the glass retainer back into place.
  • Page 30 Care and cleaning Refit the door Notch Hold the door firmly. Insert the hinge tongues into the slots, making sure that the notches on both sides drop into place as shown. Open the door to its full extent. Fully close the levers on the left and right hinges, as shown.
  • Page 31 Care and cleaning Replacing the oven light bulbs The oven light bulbs (12V/20 W halogen) have a very long life, but if you should need to replace one, use only a replacement bulb purchased from your nearest Fisher & Paykel dealer and follow these steps.

  • Page 32: Using The Self Clean Function

    Using the Self Clean function This convenient pyrolytic Self Clean function takes care of the mess and grime that is traditionally associated with oven cleaning. The extremely high temperature during a Self Clean cycle burns off and breaks down stubborn soil and grease deposits. All that remains is a clean oven cavity with a little grey ash which you can easily remove.
  • Page 33 Using the Self Clean function Select the Self Clean function. The display will flash , indicating the duration of a Self Clean cycle (3 hours). The temperature indicator will be blank, as temperature cannot be adjusted. Once the display is flashing , press the select button to start the Self Clean cycle.
  • Page 34 Using the Self Clean function When a Self Clean cycle has finished The oven will: emit a long tone automatically turn off automatically unlock the door. In a few seconds, the display will show the time of day. You need to: wait for the oven to cool down completely remove the grey ash with a small brush or damp cloth wipe out the oven with a clean damp cloth...

  • Page 35: Troubleshooting

    Troubleshooting Troubleshooting chart If there is a problem, check the chart below to see if you can fix it. If the problem cannot be fixed or persists, call your Authorised Repairer or Customer Care. Problem Possible causes What to do General The oven does not work.
  • Page 36 Troubleshooting Problem Possible causes What to do General The oven has reached the This is normal: when heating Wait until a long tone sounds set temperature but the up from cold, your oven is and the temperature dial halo temperature dial halo is designed to initially heat to a turns white: the oven will then still red (indicating that...
  • Page 37 Troubleshooting Problem Possible causes What to do Self Clean function During a Self Clean This is normal: the oven’s cooling fans operate at their highest speed. cycle, the oven is louder than usual. The display shows The door has not been properly Make sure you close the door door closed.

  • Page 38: Alert Codes

    Alert codes If there is a problem, the oven will: automatically suspend all oven functions beep five times display an alert code. Important! Do not disconnect the oven from the power supply if you get an alert code, unless the instructions in the chart following specifically instruct you to.
  • Page 39 Alert codes Alert code Possible causes What to do The oven has overheated. Allow the oven to cool down. If the door is locked, wait until it automatically unlocks. Once the oven has cooled down and the door has unlocked, the alert code will disappear.

  • Page 40: Warranty And Service

    Warranty and service Before you call for service or assistance... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed. you are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &...
  • Page 44 Copyright © Fisher & Paykel 2009. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
