Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS Built-in Oven OB60NC & OB60SC models NZ AU GB IE www.fisherpaykel.com 590777A 04.15... -
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electrical shock hazard To avoid hazard, follow these Before carrying out any work on the ● ● instructions carefully before installing electrical section of the appliance, it or using this appliance. must be disconnected from the mains Please make this information available electricity supply. -
Page 3: Parts Supplied
PARTS SUPPLIED Screws (2) Metal side shelves fixing nut (2) PRIOR TO INSTALLATION the benchtop and oven cavity are square and level, and are the required dimensions. ● ● the installation will comply with all clearance requirements and applicable standards and regulations. ●... -
Page 4: Product Dimensions
(optional accessory. Purchased separately: Part no. 85083) If using the lower trim kit accessory, you will need to install this BEFORE installing the appliance. Refer to the instructions packed with the lower trim kit. OB60NC MODELS OB60SC MODELS PRODUCT DIMENSIONS Overall height of product... -
Page 5: Cabinetry Dimensions
CABINETRY DIMENSIONS Electrical supply 16-20 mm SIDE OB60NC MODELS OB60SC MODELS CABINETRY DIMENSIONS Minimum inside width of cavity Overall width of cabinetry Minimum inside height of cavity (with lower trim kit fitted) Overall height of cabinetry (with lower trim kit fitted) Minimum inside depth of cavity Note: If installing a cooktop above the oven, ensure adequate clearance is provided for the cooktop as per the cooktop manufacturer’s instructions. - Page 6 ● qualified person. This oven must be earthed. ● ● MODEL CODE MAX POWER (W) VOLTAGE (V) AMPS (A) OB60NC... 3000 50 Hz 220 - 240 V~ OB60SC... 3000 50 Hz 220 - 240 V~ Ensure cable clamp is tightened...
-
Page 7: Secure The Oven To The Cabinetry
SECURE THE OVEN TO THE CABINETRY 1 Position the oven in the prepared cavity. IMPORTANT! Do not lift the oven by the door handle. 2 Open the oven door fully. 3 Mark and pre-drill the screw holes. 4 Use the supplied screws to secure the oven to the cabinetry. IMPORTANT! Do not over-tighten the screws. -
Page 8: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. - Page 12 www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
