PAC60Cip-AE-1.40 DATE: JULY 2020 This manual is the publication of PONOVO POWER CO.,LTD. Any form of copy should obtain the consent of it. The manual represents the technology status at publication time. The product information, directions and all technical specifications do not have contract binding. The company subjects to changing the technical and configuration information without notice.
PAC60CIp Power Amplifier User Manual 1. Safety Precaution Read User Manual before operation. 1. Check carefully all buttons are positioned correctly before startup. 1) Pause button in correct position in pressed state. 2) ON/OFF in OFF state. 3) Not press high power button (High power indicator in OFF state) 2.
Page 5
PAC60CIp Power Amplifier User Manual 12. Avoid the equipment to be wet by rain 13. Do not switch-on and operate the equipment in the place having explosive gas or water vapor. 14. The 500V dangerous voltage can be in the equipment and please don’t remove the cover by yourself 15.
Page 6
PAC60CIp Power Amplifier User Manual For Your Safety Please Note This symbol indicates potential hazards by electrical voltages/currents caused by, for example, wrong connections, short-circuits, technically inadequate or faulty equipment or by disregarding the safety notes of the following sections.
Page 7
PAC60CIp Power Amplifier User Manual manual. Do not Move or Maintain the Instrument When it is Powered On To avoid personnel injuries, any position adjustment, maintenance or parts replacement are forbidden when instrument is on. Use Proper Fuse Please use the specified fuses.
Page 8
PAC60CIp Power Amplifier User Manual Do Not Operate in an Explosive Atmosphere In order to avoid damages to the device or personal injuries, it is important to operate the device away from an explosive atmosphere. Keep Product Surfaces Clean and Dry To avoid the influence of dust and/or moisture in air, please keep the surface of device clean and dry.
Page 9
PAC60CIp Power Amplifier User Manual Handling Safety Please handle with care during transporting to avoid damages to surface, panel and parts resulting from the falling from your hand. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
DC offset, drift, transient response, load driving capability aspects, which are very difficult to fix. PAC60Cip is specially designed for R&D of power system simulation. It solves the problems of high power of linear power amplifier and accuracy of high current output. It is adapt to...
PAC60CIp Power Amplifier User Manual 3. Main Technical Specifications 3.1 Power Supply Power supply Single phase 110/220V AC Max Current: 15A Frequency: 50/60Hz Power capacity 1500VA 3.2 Environment Conditions Operating temperature: 25 deg±10 deg Storage Temperature: -25 deg—+70 deg Related humidity: 20%RH—85%RH Pressure: 86 kPa—106kPa...
PAC60CIp Power Amplifier User Manual 4. Functions and Features 4.1 Basic Principle PAC60Cip consists of the below parts mainly: 1) High-speed differential input circuit for amplifier; 2) Current power amplifier module; 3) Detection and alarm circuit: each amplifier has output open-circuit and distortion circuit detection.
Page 14
PAC60CIp Power Amplifier User Manual 4.2.2 Open-circuit alarm function When one current output is open-circuit or wave distortion, the alarm “I1, I2, I3, I4, I5, and I6”in“Current Output” on front panel will light. 4.2.3 Pause control function The pause button on the front panel can cut off amplifier’s signal input and amplifier output.
PAC60CIp Power Amplifier User Manual 4.3 PAC60Cip Front Panels Ground protection Current output Voltage output Status indicators Amplifier input for the low level, for example, the output of RTDS, etc. Please refer to definition below with the internal pins.
Page 16
PAC60CIp Power Amplifier User Manual Definition Lead definition 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 High power control button Pause...
PAC60CIp Power Amplifier User Manual 5. How to Use Amplifier 5.1 Wiring Connect digital simulator system’s D/A output signals to corresponding signal channels of current input (Refer to the Definition of terminal leads). Pay attention that the shielded layer of the signal wire at simulator side should be grounded.
PAC60CIp Power Amplifier User Manual 5.5 Amplifier Test Items Before putting into market, the amplifier is required to have strictly inspections. The test items are: function inspection, linearity, load stability, THD, max output power, amplitude-frequency characteristic, input/output delay and step response, etc.
PAC60CIp Power Amplifier User Manual 6. Standard Accessories Note: All the accessories used must be provided by PONOVO. For replacement or damage part, please contact the manufacturer or agent for assistance. Users should take the consequence without prior notice to manufacturer or agent.
Page 21
D03 Power code QP3D Power code Amount: 1 piece Power cord connects the amplifier with power supply socket. PONOVO will provide relevant plug socket according to different countries. NOTE: D03: Adapter is mainly used in German, Finland, France, Norway, Sweden, Poland, South Korean, Austria, Spain, Hungary, Czech, Ukraine, Turkey, Brazil and Russia etc.
Page 22
PAC60CIp Power Amplifier User Manual Earthing Lead SAW0018 Earthing lead Amount: 1 piece Earthing lead connects the amplifier with ground to ensure kit safety. Notes: In order to avoid static induction, users should connect the equipment with ground reliably before testing...
Page 23
PAC60CIp Power Amplifier User Manual Crocodile clip SAW0208 Crocodile clips Amount: 8 pieces Crocodile clip is connected with the current cable.
PAC60CIp Power Amplifier User Manual 6.2 Transportation Case The large-size case with wheels is designed for heavy transport stress with folding hand it is made of fireproof materials and smooth rolling rubber tires. SAC0105 Transportation case Dimension: 465x250x525mm (WxHxD) Weight:...
Page 25
PAC60CIp Power Amplifier User Manual 7. Parameter definition Notes: The voltage/current values are valid if not specified. Output calculation value: input signal impedance x gain value For example:1.0V×8.0A/V=8.0A 1.0V×4.0A/V=4.0A 1.0V×20.0V/V=20.0V Measured output value: RMS of actual output Relative error: Measuredou tputvalue −...
