PAV250BIP Power Amplifier User Manual
PAV250Bip
POWER AMPLIFIER USER MANUAL
PAV250Bip-AE-1.30
FEB., 2018
1
Advertisement
Table of Contents
Related Manuals for Ponovo PAV250Bip
Summary of Contents for Ponovo PAV250Bip
- Page 1 PAV250Bip-AE-1.30 DATE: FEB., 2018 This manual is the publication of PONOVO POWER CO.,LTD. Any form of copy should obtain the consent of it. The manual represents the technology status at publication time. The product information, directions and all technical specifications do not have contract binding. The company subjects to changing the technical and configuration information without notice.
-
Page 2: Table Of Contents
PAV250BIP Power Amplifier User Manual Content 1. Safety Precaution.........................3 2. General Description ......................9 3. Main Technical Specifications ....................10 2.1 Power Supply ......................10 2.2 Environment Conditions ...................10 2.3 Dimension and Weight .....................11 2.4 Technical Specifications...................11 4. Functions and Features .....................12 4.1 Basic Principle ......................12 4.2 Functions and Features ...................12... -
Page 3: Safety Precaution
PAV250BIP Power Amplifier User Manual 1. Safety Precaution Read User Manual before operation. 1. Check carefully all buttons are positioned correctly before startup. 1) Pause button in correct position in pressed state. 2) ON/OFF in OFF state. 3) Not press high power button (High power indicator in OFF state) 2. - Page 4 PAV250BIP Power Amplifier User Manual 12. Avoid the equipment to be wet by rain 13. Do not switch-on and operate the equipment in the place having explosive gas or water vapor. 14. The 500V dangerous voltage can be in the equipment and please don’t remove the cover by yourself 15.
- Page 5 PAV250BIP Power Amplifier User Manual For Your Safety Please Note This symbol indicates potential hazards by electrical voltages/currents caused by, for example, wrong connections, short-circuits, technically inadequate or faulty equipment or by disregarding the safety notes of the following sections.
- Page 6 PAV250BIP Power Amplifier User Manual manual. Do not Move or Maintain the Instrument When it is Powered On To avoid personnel injuries, any position adjustment, maintenance or parts replacement are forbidden when instrument is on. Use Proper Fuse Please use the specified fuses.
- Page 7 PAV250BIP Power Amplifier User Manual Do Not Operate in an Explosive Atmosphere In order to avoid damages to the device or personal injuries, it is important to operate the device away from an explosive atmosphere. Keep Product Surfaces Clean and Dry To avoid the influence of dust and/or moisture in air, please keep the surface of device clean and dry.
- Page 8 PAV250BIP Power Amplifier User Manual Handling Safety Please handle with care during transporting to avoid damages to surface, panel and parts resulting from the falling from your hand. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
-
Page 9: General Description
DC offset, drift, transient response, load driving capability aspects, which are very difficult to fix. PAV250Bip is specially designed for R&D of power system simulation. It is adapt to various capacitive and inductive load. There are 6-phase voltage outputs with max. 250VRms per... -
Page 10: Main Technical Specifications
PAV250BIP Power Amplifier User Manual 3. Main Technical Specifications 2.1 Power Supply Single phase 110/220V AC Power supply Max Current: 15A Frequency: 50/60Hz Power capacity 750VA 2.2 Environment Conditions 25 ° C±10 ° C Operating temperature Storage temperature -25-+70°C Related humidity: 20%RH—85%RH Pressure: 86 kPa—106kPa... -
Page 11: Dimension And Weight
PAV250BIP Power Amplifier User Manual 2.3 Dimension and Weight 3U standard chassis H×W×D(mm): 364×155.5×415 Weight:15kg 2.4 Technical Specifications Voltage output 6 X 0~250V RMS Max. output power >75VA(250V output) 0~5V RMS(±7.07/16Vpek) Input signal Voltage accuracy <0.2%(5V-250V) Voltage typical accuracy <0.1%... -
Page 12: Functions And Features
PAV250BIP Power Amplifier User Manual 4. Functions and Features 4.1 Basic Principle PAV250Bip consists of the below parts mainly: High-speed differential input circuit for amplifier; Voltage power amplifier module; Detection and alarm circuit: each amplifier has an output distortion detection circuit. - Page 13 PAV250BIP Power Amplifier User Manual 4.2.2 Over-load alarm function The output voltage distortion and overload auto-detection circuit will protect the voltage amplifier output overload or short-circuit automatically. It automatically closes amplifier input/output, and the overload alarm in rear panel lights. After overload and short-circuit disappear, it restores to working status.
- Page 14 PAV250BIP Power Amplifier User Manual 2. Exit the high power function after finishing the function. Working in high power output status in long time is not permitted. 3. Don’t switch high power control button while there is output.
- Page 15 PAV250BIP Power Amplifier User Manual 3.3 PAV250Bip Front Panel Ground protection Current output Voltage output Status indicators Amplifier input for the low level, for example, the output of RTDS, etc. Please refer to definition below with the internal pins.
- Page 16 PAV250BIP Power Amplifier User Manual Definition Lead definition 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 High power control button Pause...
- Page 17 PAV250BIP Power Amplifier User Manual 3.4 PAV250Bip Rear Panel Ventilation Ventilation Power switch Power socket...
-
Page 18: How To Use Amplifier
PAV250BIP Power Amplifier User Manual 5. How to Use Amplifier 5.1 Wiring Connect digital simulator system’s D/A output signals to corresponding signal channels of voltage input (Refer to the Definition of terminal leads). Pay attention that the shielded layer of the signal wire at simulator side should be grounded. -
Page 19: Amplifier Off
PAV250BIP Power Amplifier User Manual 5.4 Amplifier Off Stop simulation signal input firstly if users stop using amplifier. Press “Pause” buttons, and cut off all connections of amplifier and load, lastly turn off power. 5.5 Amplifier Test Items Before putting into market, the amplifier is required to have strictly inspections. The test items are: function inspection, linearity, load stability, THD, max output power, amplitude-frequency characteristic, input/output delay and step response, etc. -
Page 20: Standard Accessories
PAV250BIP Power Amplifier User Manual 6. Standard Accessories Note: All the accessories used must be provided by PONOVO. For replacement or damage part, please contact the manufacturer or agent for assistance. Users should take the consequence without prior notice to manufacturer or agent. - Page 21 D03 Power code QP3D Power code Amount: 1 piece Power cord connects the amplifier with power supply socket. PONOVO will provide relevant plug socket according to different countries. NOTE: D03: Adapter is mainly used in German, Finland, France, Norway, Sweden, Poland, South Korean, Austria, Spain, Hungary, Czech, Ukraine, Turkey, Brazil and Russia etc.
- Page 22 PAV250BIP Power Amplifier User Manual Earthing Lead SAW0018 Earthing lead Specification: 2.5mm²×4m Amount: 1 piece Earthing lead connects the amplifier with ground to ensure kit safety. Notes: In order to avoid static induction, users should connect the equipment with ground...
-
Page 23: Transportation Case
PAV250BIP Power Amplifier User Manual 6.2 Transportation Case The large-size case with wheels is designed for heavy transport stress with folding hand it is made of fireproof materials and smooth rolling rubber tires. SAC0105 Transportation case Dimension: 465x250x525mm (WxHxD) Weight: 10kg... -
Page 24: Parameter Definition
PAV250BIP Power Amplifier User Manual 7. Parameter definition Notes: The voltage/current values are valid if not specified. Output calculation value: input signal RMS x gain value For example: 1.0V×50.0V/V=50.0V Measured output value: the effective value of actual output − Measuredou...
