  • Page 1 50-670C User Manual PCI Very High Density Multiplexer Card pickeringtest.com Issue 1.2 May 2023...
  • Page 2 © COPYRIGHT (2023) PICKERING INTERFACES. ALL RIGHTS RESERVED. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
  • Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

  • Page 4: Product Safety

    If this product is heavy reference should be made to the safety instructions for provisions of lifting and moving. STATIC SENSITIVE To indicate that static sensitive devices are present and handling precautions should be followed. REED RELAY MODULE 40-110/115/120/125 VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page (IV) Page (IV)

  • Page 5: Table Of Contents

    Pre Operation Checks ............3.1 Hardware Installation ............3.2 Software Installation .............3.2 Testing Operation ..............3.3 Section 4 Programming Guide ..............4.1 Programming Options For Pickering PCI Cards ....4.1 50-670C Card Architecture ...........4.2 Card Sub-Units ..............4.3 Programming The Card ............4.15 Section 5 Connector Information ..............5.1 Section 6 Trouble Shooting .................6.1...
  • Page 6 THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page (VI)

  • Page 7: Warnings And Cautions

    Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale. This card must not be used for the switching of Mains Circuits. For the switching of voltages up to the card’s full specification, Secondary Circuit power supplies and the Device Under Test must be...
  • Page 8 • For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on the front of the unit. VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page (VIII) PCI REED RELAY CARD 50-110 / 115 / 120 / 125...

  • Page 9: Technical Specification

    Model 50-670C channel selection configurations have been revised y 3 Year Warranty from model 50-670A. The 50-670C family defaults to single channel selection with multiple channel selection variants defined by use of The 50-670C series of very high density multiplexer a suffix.
  • Page 10 10.4 10.5 10.6 10.7 10.8 5.25 10.9 5.26 10.10 5.27 10.11 5.28 10.12 5.29 10.13 5.30 10.14 5.31 10.15 5.32 10.16 50-670C-022 10-Channel 16-Pole Multiplexer 50-670C-022 5-Channel 32-Pole Multiplexer pickeringtest.com Page 2 VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 1.2...
  • Page 11 † Bandwidth is configuration dependent (please consult sales office for further information). Relay Type Power Requirements The 50-670C is fitted with ruthenium sputtered reed relays, these offer very long life with good low level switching +3.3 V +5 V +12 V -12 V performance and excellent contact resistance stability.
  • Page 12 Note: The above cards are available in multiple channel selection mode by adding the “-M” suffix to the part number. For connection accessories for the 50-670C card range please For example, the 99-channel 1-pole MUX with multiple refer to the...
  • Page 13 1200+ products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules. These accessories are detailed in Connector Accessories data sheets, where a complete list and documentation can be found for each accessory.
  • Page 14 Supporting Products & Software 50-670C Programming Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of Windows and popular older versions. For more information go to pickeringtest.com/os The VISA driver support is provided for LabVIEW Real Time Operating Systems (Pharlap and Linux-RT). For other RTOS support contact Pickering.
  • Page 15 To view, download or request any of our product resources go to pickeringtest.com/resources © Copyright (2023) Pickering Interfaces. All Rights Reserved. Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet. pickeringtest.com Page 7 VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 1.7...
  • Page 16 SECTION 1 - TECHNICAL SPECIFICATION pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 1.8...

  • Page 17: Technical Description

    PCI VERY HIGH DENSITY MUX CARD 50-670A PCI Bridge Configuration Relays RL1-101 Relay Drivers U8-15 One of 11 Different +3.3V Card MUX Configurations Configuration Figure 2.1 - Very High Density Multiplexer Card 50-670C: Functional Block Diagram VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 2.1...
  • Page 18 SECTION 2 - TECHNICAL DESCRIPTION pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 2.2...

  • Page 19: Installation

    Modular products require installation in a suitable chassis. The card is designed for indoor use only. PREOPERATION CHECKS (UNPACKING) 1. Check the card for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident.

  • Page 20: Hardware Installation

    8. Power-up the host system. SOFTWARE INSTALLATION First install the appropriate Pickering PCI switch card drivers by running the installer program Setup.exe (provided in a compressed zip file), either from the CD-ROM supplied, or by downloading the latest version from our website pickeringtest.com...

  • Page 21: Testing Operation

    Figure 3.2 - General Soft Front Panel Icon A selector panel will appear, listing all installed Pickering PCI, PXI or LXI switch cards and resistor cards. Click on the card you wish to control, and a graphical control panel is presented allowing operation of the card.
  • Page 22 SECTION 3 - INSTALLATION pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 3.4...

  • Page 23: Programming Guide

    SECTION 4 - PROGRAMMING GUIDE PROGRAMMING OPTIONS FOR PICKERING INTERFACES PCI CARDS For information on the installation and use of drivers and the programming of Pickering’s products in various software environments, please refer to the Software User Manual. This is available as a download from: https://www.pickeringtest.com/support/software-drivers-and-downloads...

  • Page 24: 50-670C Card Architecture

    50-670C CARD ARCHITECTURE The 50-670C card is an array of up to 101 reed relays factory configured into one of eleven different multiplexer configurations. In the default state, all multiplexer channels are open circuit. Energising a particular channel creates a signal path between the common terminal and the corresponding channel terminal.
  • Page 25 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.1 - Multiplexer 50-670C-022-198/1 (198-Channel, 1-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.3...
  • Page 26 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.2 - Multiplexer 50-670C-021-99/1 (99-Channel, 1-Pole): Sub-Units Chan. Pole Chan. Pole Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.4...
  • Page 27 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.3 - Multiplexer 50-670C-022-99/2 (99-Channel, 2-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.5...
  • Page 28 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.4 - Multiplexer 50-670C-021-49/2 (49-Channel, 2-Pole): Sub-Units Chan. Pole Chan. Pole Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.6...
  • Page 29 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.5 - Multiplexer 50-670C-022-49/4 (49-Channel, 4-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.7...
  • Page 30 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.6 - Multiplexer 50-670C-021-24/4 (24-Channel, 4-Pole): Sub-Units Chan. Pole Chan. Pole Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.8...
  • Page 31 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.7 - Multiplexer 50-670C-022-24/8 (24-Channel, 8-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.9...
  • Page 32 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.8 - Multiplexer 50-670C-021-10/8 (10-Channel, 8-Pole): Sub-Units Chan. Pole Chan. Pole Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.10...
  • Page 33 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.9 - Multiplexer 50-670C-022-10/16 (10-Channel, 16-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.11...
  • Page 34 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.10 - Multiplexer 50-670C-021-5/16 (5-Channel, 16-Pole): Sub-Units Chan. Pole Chan. Pole Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.12...
  • Page 35 SECTION 4 - PROGRAMMING GUIDE pickering Table 4.11 - Multiplexer 50-670C-022-5/32 (5-Channel, 32-Pole): Sub-Units Chan. Pole Chan. Pole Chan. Pole Chan. Pole Unit Unit Unit Unit VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 4.13...

  • Page 36: Programming The Card

    SECTION 4 - PROGRAMMING GUIDE pickering PROGRAMMING THE CARD Here are some simple examples of using the drivers with the 50-670C-021-10/8 (10 Channel 8 Pole) multiplexer card. Other modules in the range are controlled in a similar way. Using PILPXI...

  • Page 37: Connector Information

    SECTION 5 - CONNECTOR INFORMATION pickering SECTION 5 - CONNECTOR INFORMATION Isolation Switch 99-Channel, 1-Pole Multiplexer Figure 5.1 - 50-670C-021-99/1 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.1...
  • Page 38 42.2 42.1 41.2 41.1 44.2 44.1 43.2 43.1 46.2 46.1 45.2 45.1 48.2 48.1 47.2 47.1 49.2 49.1 Figure 5.2 - 50-670C-021-49/2 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.2...
  • Page 39 20.2 20.1 21.4 21.3 21.2 21.1 22.4 22.3 22.2 22.1 23.4 23.3 23.2 23.1 24.4 24.3 24.2 24.1 Figure 5.3 - 50-670C-021-24/4 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.3...
  • Page 40 10.2 10.3 10.4 10.3 10.2 10.1 10.4 10.5 10.8 10.7 10.6 10.5 10.6 10.7 10.8 10-Channel, 8-Pole Multiplexer Figure 5.4 - 50-670C-021-10/8 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.4...
  • Page 41 4.13 5.12 5.11 5.10 5.16 5.15 5.14 5.13 5.10 5.11 5.12 5.13 5.14 5.15 5.16 5-Channel, 16-Pole Multiplexer Figure 5.5 - 50-670C-021-5/16 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.5...
  • Page 42 SECTION 5 - CONNECTOR INFORMATION pickering Isolation Switch 198-Channel, 1-Pole Multiplexer Figure 5.6 - 50-670C-022-198/1 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.6...
  • Page 43 92.2 90.2 91.2 89.2 96.1 94.1 93.1 95.1 96.2 94.2 93.2 95.2 98.1 97.1 99.1 98.2 97.2 99.2 Figure 5.7 - 50-670C-022-99/2 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.7...
  • Page 44 46.1 45.3 45.2 46.4 46.2 45.4 47.1 48.3 48.1 47.3 47.2 48.4 48.2 47.4 49.1 49.3 49.2 49.4 Figure 5.8 - 50-670C-022-49/4 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.8...
  • Page 45 22.4 22.2 23.7 23.5 23.3 23.1 23.8 23.6 23.4 23.2 24.7 24.5 24.3 24.1 24.8 24.6 24.4 24.2 Figure 5.9 - 50-670C-022-24/8 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.9...
  • Page 46 10.10 10.15 10.13 10.11 10.9 10.11 10.16 10.14 10.12 10.10 10.12 10.13 10.14 10.15 10.16 10-Channel, 16-Pole Multiplexer Figure 5.10 - 50-670C-022-10/16 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.10...
  • Page 47 5.26 5.31 5.29 5.27 5.25 5.27 5.32 5.30 5.28 5.26 5.28 5.29 5.30 5.31 5.32 5-Channel, 32-Pole Multiplexer Figure 5.11 - 50-670C-022-5/32 Pinout (200-pin Female LFH Connector Viewed From Front of Card) VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.11...
  • Page 48 SECTION 5 - CONNECTOR INFORMATION pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 5.12...

  • Page 49: Trouble Shooting

    PCI configuration, highlighting any potential configuration problems. Specific details of all installed Pickering switch cards are included. All the installed Pickering switch cards should be listed in the “Pilpxi information” section - if one or more cards is missing it may be possible to determine the reason by referring to the PCI configuration dump contained in the report, but interpretation of this information is far from straightforward, and the best course is to contact Pickering support: support@pickeringtest.com, if possible...
  • Page 50 SECTION 6 - TROUBLE SHOOTING pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 6.2...

  • Page 51: Maintenance Information

    PCB layout diagrams to identify the position of faulty relays. Users of eBIRST switching system test tools do not need to use this information to locate faulty relays. PCI REED RELAY CARD 50-110A /115A VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 7.1 Page 7.1...
  • Page 52 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.1 - Multiplexer 50-670C-022-198/1 (198 Channel, 1-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL74 RL35 RL28 RL82 RL75 RL36 RL29 RL83 RL76 RL37...
  • Page 53 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.2 - Multiplexer 50-670C-021-99/1 (99 Channel, 1-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay RL81 RL35 RL82 RL36 RL83 RL37 RL84 RL38 RL85 RL39 RL86 RL40 RL87 RL41 RL88 RL42 RL89...
  • Page 54 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.3 - Multiplexer 50-670C-022-99/2 (99 Channel, 2-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL74 RL35 RL28 RL82 RL75 RL36 RL29 RL83 RL76 RL37...
  • Page 55 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.4 - Multiplexer 50-670C-021-49/2 (49 Channel, 2-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay RL81 RL35 RL82 RL36 RL83 RL37 RL84 RL38 RL85 RL39 RL86 RL40 RL87 RL41 RL88 RL42 RL89...
  • Page 56 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.5 - Multiplexer 50-670C-022-49/4 (49 Channel, 4-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL73 RL33 RL27 RL82 RL74 RL34 RL28 RL83 RL75 RL35...
  • Page 57 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.6 - Multiplexer 50-670C-021-24/4 (24 Channel, 4-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay RL81 RL33 RL82 RL34 RL83 RL35 RL84 RL36 RL85 RL37 RL86 RL38 RL87 RL39 RL88 RL40 RL89...
  • Page 58 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.7 - Multiplexer 50-670C-022-24/8 (24 Channel, 8-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL73 RL33 RL25 RL82 RL74 RL34 RL26 RL83 RL75 RL35...
  • Page 59 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.8 - Multiplexer 50-670C-021-10/8 (10 Channel, 8-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay RL81 RL33 RL82 RL34 RL83 RL35 RL84 RL36 RL85 RL37 RL86 RL38 RL87 RL39 RL88 RL40 RL89...
  • Page 60 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.9 - Multiplexer 50-670C-022-10/16 (10 Channel, 16-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL73 RL33 RL25 RL82 RL74 RL34 RL26 RL83 RL75 RL35...
  • Page 61 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.10 - Multiplexer 50-670C-021-5/16 (5 Channel, 16-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay RL81 RL33 RL82 RL34 RL83 RL35 RL84 RL36 RL85 RL37 RL86 RL38 RL87 RL39 RL88 RL40 RL89...
  • Page 62 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.11 - Multiplexer 50-670C-022-5/32 (5 Channel, 32-Pole): Relay Cross Reference Channel Pole Relay Channel Pole Relay Channel Pole Relay Channel Pole Relay RL81 RL73 RL33 RL25 RL82 RL74 RL34 RL26 RL83 RL75 RL35...
  • Page 63 RL15 RL84 RL68 RL52 RL36 RL20 RL88 RL72 RL56 RL40 RL24 RL92 RL76 RL60 RL44 RL28 RL12 RL96 RL80 RL64 RL48 RL32 RL16 Spare Figure 7.1 - Multiplexer Card 50-670C: Component Layout VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 7.13...
  • Page 64 SECTION 7 - MAINTENANCE INFORMATION pickering THIS PAGE INTENTIONALLY BLANK VERY HIGH DENSITY MULTIPLEXER CARD 50-670C Page 7.14...
