TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set® and Simple Shape
and light up your tree in less than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker . Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Just plug the adapter (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree should now be lit. If
some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in
order to maintain the performance and life expectancy of your pre-lit tree. * The lights will remain lit even if one bulb burns out.
MODEL #: TG76P4724D03
1-888-919-0070
OR
Tree top
Section 2
Click
Do Not Tamper
Internal Parts
Open the
protective
cap
Open the
protective
cap
Control box
1
TM
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.25A
Output: 29V DC 0.45A
Do Not Tamper
Internal Parts
Plug Adapter
Into Wall
Outlet
Insert Green
Label Extension
Cord into Adapter
technology-Set up

Advertisement

loading
Need help?

Need help?

Do you have a question about the TG76P4724D03 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polygroup TG76P4724D03

  • Page 1 1-888-919-0070 TREE ASSEMBLY INSTRUCTIONS Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set® and Simple Shape technology-Set up and light up your tree in less than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your new tree.
  • Page 2 8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to the right, one to the left and one at the center of the main stem. (see Fig. C) 9.
  • Page 3 BATTERY REPLACEMENT 1. Loosen the screw of the battery cover with a screwdriver (not included). 2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed with the correct polarity (+ and -). 3.
  • Page 4 LAMP REPLACEMENT Step 1 Grasp the power adapter or power cord plug, and than unplug from the power outlet. Do not pull the power cord. Step 2 Lift up lamp lock tab, then Step 3 Replace with a new spare pull the lamp and plastic lamp base lamp provided with this product.
