Polygroup TG76P4751D18 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
up your tree in less than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
3. Each tree section is numbered with a sticker.
4. Assemble the tree from bottom to the top. Start with the bottom section and remove the protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Just plug the adaptor (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree should now be lit. If
some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in
order to maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to
the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG76P4751D18
1-888-919-0070
OR
Polygroup®!
Tree Top
Section 2
Section 1
Please identify all sections before assembling.
Side view
This tree comes with Quick Set
Do Not Tamper
Internal Parts
Open the
protective
cap
Do Not Tamper
Internal Parts
Control box
Insert Green
Label Extension
Cord into Adaptor
1
®
technology-Set up and light
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120VAC, 60Hz, 0.16A Max.
Output: 29V DC 0.28A
Open the
protective
cap
Adaptor
To Be Plugged
Into Wall
Outlet
