10.1.2 Wire feed rollers for aluminium wire

Type
AL 4R 0.8 MM/0.03 INCH
WHITE
AL 4R 1.0 MM/0.04 INCH
BLUE
AL 4R 1.2 MM/0.045 INCH
RED
AL 4R 1.6 MM/0.06 INCH
BLACK
AL 4R 2.0 MM/0.08 INCH
GREY/YELLOW
AL 4R 2.4 MM/0.095 INCH
BROWN/YELLOW
AL 4R 2.8 MM/0.110 INCH
LIGHT GREEN/YELLOW
AL 4R 3.2 MM/0.125 INCH
VIOLET/YELLOW

10.1.3 Wire feed rollers for cored wire

Type
FUEL 4R 0.8 MM/0.03 INCH
WHITE/ORANGE
FUEL 4R 1.0 MM/0.04 INCH
BLUE/ORANGE
FUEL 4R 1.2 MM/0.045 INCH
RED/ORANGE
FUEL 4R 1.4 MM/0.052 INCH
GREEN/ORANGE
FUEL 4R 1.6 MM/0.06 INCH
BLACK/ORANGE
FUEL 4R 2.0 MM/0.08 INCH
GREY/ORANGE
FUEL 4R 2.4 MM/0.095 INCH
BROWN/ORANGE

10.1.4 Wire guide

Type
SET DRAHTFUERUNG
ON WF 2,0-3,2MM EFEED
SET IG 4x4 1.6mm BL
GUIDE TUBE L105
CAPTUB L108 D1,6
CAPTUB L105 D2,0/2,4
099-005508-EW501
04.04.2016
Designation
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Drive roll set, 37 mm, for aluminium
Designation
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Designation
Wire guide set
Retrofitting option, wire guide for 2.0–3.2 mm wires,
eFeed drive
Inlet guide set
Guide tube
Capillary tube
Capillary tube
Replaceable parts
Wire feed rollers
Item no.
092-002771-00008
092-002771-00010
092-002771-00012
092-002771-00016
092-002771-00020
092-002771-00024
092-002771-00028
092-002771-00032
Item no.
092-002848-00008
092-002848-00010
092-002848-00012
092-002848-00014
092-002848-00016
092-002848-00020
092-002848-00024
Item no.
092-002774-00000
092-019404-00000
092-002780-00000
094-006051-00000
094-006634-00000
094-021470-00000
