AVANT 23" ROUND GAS FIRE COLUMN
Sku#
2595243
Item# 52285
Model# HYFP50085-36
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property
damage, personal injury or loss of life. Refer to the owner's information manual provided
with this appliance. Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
INSTALLER: Leave this
manual with the appliance.
CONSUMER: Retain this
manual for future reference.
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier
or fire department.
Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury, or death.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected
for use shall not be stored in the vicinity of
this or any other appliance.
Installation and service must be performed
by a qualified installer, service agency,
or the gas supplier.
DANGER
Owner's Manual
DANGER
WARNING
For outdoor use only.
WARNING
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVANT HYFP50085-36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Backyard Creations AVANT HYFP50085-36

  • Page 1 AVANT 23" ROUND GAS FIRE COLUMN Sku# 2595243 Item# 52285 DANGER Model# HYFP50085-36 FIRE OR EXPLOSION HAZARD If you smell gas: Shut off gas to the appliance. • Extinguish any open flame. • If odor continues, leave the area immediately. •...
  • Page 2: Safety Information

    SAFETY INFORMATION Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so may r WARNING • The installation of this unit must adhere to local codes or Propane Storage and Handling Code, CSA B149.2. •...
  • Page 3 • Combustible material should not be within 60 inches of the top of the unit, or within 48 inches around the entire unit. • Keep the appliance area clear and free fr vapors and liquids. • • Do not add water into the unit. •...
  • Page 4 SAFETY INFORMATION Only use the regulator and hose assembly provided with this unit. Replacement parts must be supplied directly by manufacturer. Inspect the burner before use of this unit. If the burner shows any kind of damage, do not operate the appliance.
  • Page 5: Item Description

    CONTENTS Item Description Lava Rocks 2 boxes (4 kg) Battery (AA) Body PVC Cover Door Control Knob (preassembled) Electronic Igniter (within firebowl insert body) Burner (preassembled) Guard (preassembled) Page 5...
  • Page 6 ASSEMBLY INSTRUCTIONS 1. Check that the control knob (F) for the gas supply system is turned to the 'OFF' position before starting any assembly. Remove door (E) from body (C) . Remove the cap on the electronic igniter (G) by unscrewing and slide battery (B) into the battery slot.
  • Page 7 4 4 . Turn the cylinder valve on the tank clockwise to PRESSURE RELIEF VALVE close the propane tank. Attach the preassembled CYLINDER VALVE regulator from the body (C) to the cylinder valve BLACK COUPLING NUT BLEED-OFF by turning the regulator coupling nut clockwise. turn clockwise to connect VALVE Make sure it is fastened securely and tighten...
  • Page 8 7. Pour the box of lava rocks (A) into the body (C). WARNING To ensure proper function, the guard (I) on this burner (H) should be free of lava rocks at all times. Keep away from the unit and allow the unit to burn 20 minutes for the first time use.
  • Page 9: Operation

    OPERATION Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor area. Connect the propane gas tank to the regulator and turn the valve on the unit to the 'OFF' position. Brush a soap and water mixture on all connections. Turn the gas supply on; if bubbles occur on any connection there may be a leak.
  • Page 10: Troubleshooting

    TROUBLESHOOTING • Before performing any maintenance always disconnect propane gas tank. • Store your product indoors during winter months. Avoiding extreme cold temperatures will prevent from exposure damage. • Keep the heating item free and clear from combustible materials. • Visually inspect burner for obstructions and keep tank enclosure free and clear from debris. •...
  • Page 11 TROUBLESHOOTING Problem Cause Solution Igniter pin and burner are wet Dry off with a soft cloth Igniter battery is incorrectly inserted Check which direction the battery is inserted Igniter pin is broken Contact Manufacturer for a replacement Heating unit won’t light part Electrode wire is loose or disconnected Reconnect wire to the igniter box located...
  • Page 12: Warranty

    WARRANTY This product has a one-year warranty against manufacturing defects in workmanship, or materials. The manufacturer warranty will be voided by, and manufacturer disclaims any responsibility for, the following actions: • • Use of any component part not manufactured or approved by Manufacturer.
