NAPLES NOOK RECT FIREPIT

ASSEMBLY INSTRUCTIONS

WARNING: It is UNSAFE to use this product

for cooking!

Installer: Leave these instructions with

consumer.

Consumer: Keep these instructions for future

reference

WARNING:

Improper installation, adjustment

alteration, service, or maintenance can

cause injury or property damage. Read the

installation, operating, and maintenance

instructions thoroughly before installing or

servicing this equipment.

WARNING

Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

An LP-cylinder not connected for use shall

not be stored in the vicinity of this or any

other appliance.

DANGER

CARBON MONOXIDE HAZARD

This appliance can produce carbon

monoxide which has no odor.

Using it in an enclosed space can kill

you.

Never use this appliance in an enclosed

space such as a camper, tent, car or

home.

Questions, Problems, Missing Parts? Before returning to

your retailer, call our customer service department in the

US and Canada at 1-800-416-3511, Monday-Friday, 9 a.m.

– 5 p.m. Eastern Time.

Jul-01-2021

CSA Model WT17IL SKU: 272-2189

Factory Model: BRW01200K01

DANGER

If you smell gas:

FIRE OR EXPLOSION HAZARD

If you smell gas:

•shut off gas to the appliance.

•Extinguish any open flame.

•if odor continues, leave the area

immediately.

•After leaving the area, call your gas

supplier or fire department.

Failure to follow these instructions could

result in fire or explosion, which could cause

property damage, personal injury, or death.

WARNING:

If the information in this manual is not

followed exactly, a fire or explosion may

result causing property damage, personal

injury, or loss of life.

WARNING：For Outdoor Use Only.

Installation and service must be performed

by a qualified installer, service agency, or

the gas supplier.

FOR USE WITH 9KG (20LB) PROPANE

CYLINDER WITH TYPE 1 CONNECTION OR

FOR USE WITH NATURAL GAS AFTER

CONVERSION KIT IS INSTALLED (MUST BE

PROFESSIONALLY INSTALLED).

WARNING:

USE FACTORY APPROVED

REPLACEMENT PARTS AND

ACCESSORIES ONLY. USE OF

UNAPPROVED PARTS OR

ACCESSORIES CAN VOID THE

WARRANTY ON THIS PRODUCT

AND RESULT IN A HAZARDOUS

CONDITION. PLEASE

INFORMATION REGARDING

REPLACEMENT HOSES,

THERMOCOUPLES,

ELECTRODES, IGNITION

MODULES, LAVA ROCKS, LOGS,

FIRE ICE, ETC.

Table of Contents

Need help?

Do you have a question about the WT17IL and is the answer not in the manual?

Questions and answers

Summary of Contents for Backyard Creations WT17IL

Page 1 NAPLES NOOK RECT FIREPIT ASSEMBLY INSTRUCTIONS CSA Model WT17IL SKU: 272-2189 Factory Model: BRW01200K01 DANGER If you smell gas: FIRE OR EXPLOSION HAZARD If you smell gas: •shut off gas to the appliance. •Extinguish any open flame. •if odor continues, leave the area WARNING: It is UNSAFE to use this product immediately.
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information ..............3 Important Information about Propane ............ 4 Specifications ..................4 Parts Identification List ..............5-6 Installation ..................7-9 Natural Gas Conversion ..............10-11 Maintenance ..................11 Batteries ....................12 Lighting Instructions ................12 Troubleshooting Guide ................
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa).
Page 4: Important Information About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A LP-gas cylinder for use with this appliance must have a capacity of 20 lbs / 9kg. and must be equipped with a Type 1 connector and an OPD (overfill protection device). Figure 1 The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S.
Page 5: Parts Identification List
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP2329 GAS VALVE FP2330 THERMOCOUPLE FP2331 FLEX CONNECTOR FP2332 ELECTRODE FP2333 IGNITION MODULE FP2334 ORIFICE HOLDER FP3573 LP REGULATOR HOSE FP3487 FOOT CAPS FC0759 FIREPAN/BURNER FP3615 ASSEMBLY PROPANE ORIFICE FP2122 NATURAL GAS ORIFICE FP2123 AIR SHUTTER FP1922...
Page 6 FIREPIT TABLE TOP FP3608 BURNER COVER FP3609 BACK FRAME FP3610 SIDE PANEL FP3611 DOOR FRAME FP3612 LP SUPPORT FRAME FP3613 MIDDLE SUPPORT FP3614...
Page 7: Installation
INSTALLATION 1. Carefully unpack all items from the box. Place the base in the final position. There must be a minimum of 24 in / 60.96 cm of clearance from the side of the table top to any combustible walls. 2.
Page 8 Figure 4 4. With the help of another person, carefully place the table top onto the firepit base. After making any necessary adjustments to the alignment of the table top and the assembled base, use four 1/4"x20 mm bolts and Ø20xØ6.5x2.0 mm washers as shown in Figure 5. Guide the bolts through the holes in the base brackets, into the predrilled holes in the table top.
Page 9 6. Pour ALL of the media (fire ice or lava rock, not included) into the burner pan. The burner MUST be completely covered to ensure the appliance functions properly and safely. Remove any lava rocks or fire ice on top of the ignition well. See figure 7. Figure 7 7 Slide the tank drawer out and place the LP tank in the drawer.
Page 10: Natural Gas Conversion
NATURAL GAS CONVERSION Natural gas conversion must be performed only by your natural gas provider or service company. 1. SHUT OFF THE GAS SUPPLY TO THE UNIT AND ANY NEARBY ELECTRICAL SOURCE OR APPLICANCES 2. Below the burner, carefully disconnect flex connector attached to the orifice holder (see step1). 3.
Page 11: Maintenance
Step5 10. Stick the conversion label on the rating plate as shown in Figure 10. Metal Rating Plate SerialNumber : ModelNumber : WT17IL  Numéro de série Numéro de modèle      For Outdoor Use Only. If Stored Indoors, Detach and Leave Cylinder Outdoors.
Page 12: Batteries
BATTERIES Make sure the control knob is in the "OFF" position. Unscrew the push button cap on the ignition module located on the control panel to access the battery compartment. The ignition module requires one Alkaline AA size battery (1.5V). The negative (-) end goes in first. See Figure 12.
Page 13: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Check that gas tank valve is open. Turn the control knob to “ON” and No propane gas at the burner push the control knob in. Make sure the tank has propane gas. Check that the AA battery is installed with the negative (-) end first and has Burner won’t light a charge.
Page 14: Warranty
ONE-YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in material and workmanship for the following parts from the date of purchase for the period of warranty as outlined below, but only when the unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: Limited 1 Year...
