Assembly Instructions
ASHLYN BOOKSHELF
SKU 516570
Thank you for your purchase. If you have any questions pertaining to the assembly of this
furniture piece, please contact the nearest World Market store. If you are not near a store,
please call our customer service call center toll free at 877-967-5362 for assistance.
ALL PRODUCTS SOLD AT WORLD MARKET ARE NOT
FOR COMMERCIAL USE AND ARE INTENDED FOR
RESIDENTIAL USE ONLY.
PAGE 1
2023.07.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASHLYN 516570 and is the answer not in the manual?

Questions and answers

Summary of Contents for World Market ASHLYN 516570

  • Page 1 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
  • Page 2: Component List

    Component List LABEL PICTURE DESCRIPTION Top Panel Vertical Panel Middle Panel Bottom Panel Wood Rail Feet PAGE 2...
  • Page 3: Hardware List

    Hardware List LABEL PICTURE DESCRIPTION Cam-bolts Cam locks Allen bolts M6*1-1/2” Round head wood screw M3*1-1/2” Wood dowel Ø8*1-5/8” PAGE 3...
  • Page 4: Tool List

    Tool List LABEL PICTURE DESCRIPTION Cam lock wrench Allen wrench Ø4 PAGE 4...
  • Page 5: Assembly Preparation

    Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at call 1-877-967-5362.
  • Page 6 NOTE: Upon opening thoroughly clean all wood surfaces to remove dust and dirt that may have settled onto finish during shipment. In order to prevent damage during assembly, please assemble this item with at least two people. NOTE: Turn the cam-bolt screws until they are tight, the shoulder should be against the surface of the part.
  • Page 7: Assembly Steps

    Assembly Steps Step 1 (H-1) Cam bolts x6 (H-2) Cam locks x6 (H-5) Dowels x6 • Assemble the Vertical Panel (B). • Place Top panel (A) upside down on padded non-marring surface. • Insert 6x Dowels (H-5) and rotate 6x Cam-Bolts (H-1) into the holes in the Top panel(A). •...
  • Page 8 Step 2 (H-3) Allen bolts x6 (H-5) Dowels x6 • Assemble the Middle Panel (C). • Insert 6x Dowels (H-5) in the Vertical Panel (B). • Rotate 6x Allen bolts (H-3) into the holes in the Middle Panel (C) by Allen wrench. Step 3 (H-1) Cam bolts x6 (H-2) Cam locks x6...
  • Page 9 Step 4 (H-3) Allen bolts x6 (H-5) Dowels x6 • Assemble the Bottom Panel (D). • Insert 6x Dowels (H-5) in the Vertical Panel (B). • Rotate 6x Allen bolts (H-3) into the holes in the Bottom Panel (D) by Allen wrench. Step 5 (H-4) Screws x4 (H-5) Dowels x2...
  • Page 10 Step 6 • Assemble the Feet (F). • Rotate 4x Feet (F) into the holes in the Bottom panel(D). Step 7 Rotate 4x Feet(F) into the holes in the Bottom panel(D). Warning label position • The bookshelf is now ready for use. PAGE 10...
  • Page 11 Anti-Tip Measures WARNING Furniture tip overs can result in death or serious injuries. To reduce the likelihood of tip over, this product should be used with the enclosed Anti-Tip Kit. This Anti-Tip Kit is only a deterrent. It is not a substitute for proper adult supervision. Manufacturer and retailer assume no liability for improper installation or excess loads placed on screws, brackets, or straps.
  • Page 12: Care And Maintenance

    Place heaviest items in the lowest drawers. Not intended for clothing storage use. All products sold at World Market are not for commercial use and are intended for residential use only. Care & Maintenance DO NOT put hot items directly on furniture surface.
  • Page 13 Customer Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or par�al credit, in the sole discre�on of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
