Assembly Instructions
ASHLYN BOOKSHELF
SKU-516570
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST COST PLUS WORLD MARKET STORE.
IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL
CENTER TOLL FREE AT 877- 967-5362 FOR ASSISTANCE
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for World Market ASHLYN 516570
Summary of Contents for World Market ASHLYN 516570
- Page 1 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL...
-
Page 2: Component List
Component List Label Description Top Panel Vertical Panel Middle Panel Bottom Panel Wood Rail Feet Page 2... -
Page 3: Hardware List
Hardware List Description Label Cam-bolts Cam-locks Allen Bolts M6*1-1/2” Round head wood screw M3*1-1/2” Wood dowel Ø8*1-5/8” Page 3... -
Page 4: Tool List
Tool List Label Description Cam lock wrench Allen wrench Page 4... -
Page 5: Assembly Preparation
Assembly Preparation Before Beginning: Unpack all hardware bags and components to ensure you have all parts- Read instructions, cover to cover- Have 2 adults on hand for assembly- Do not assemble on flooring or carpet- Assemble on a clean non-marring surface (packing foam)- Save all packaging until finished- In case of missing parts, please contact your nearest Cost Plus World Market store or call our customer service call center at call 1-877-967-5362. - Page 6 Note: Upon opening thoroughly clean all wood surfaces to remove dust and dirt that may have settled onto finish during shipment. in order to prevent damage during assembly, please assemble this item with at least two people. Note: Turn the cam-bolt screws until they are tight, the shoulder should be against the surface of the part.
-
Page 7: Assembly Steps
Assembly Steps Step1: (H-1) Cam-bolts x6 (H-2) Cam-locks x6 (H-5) Dowels x6 Assemble the Vertical Panel(B). Place Top panel(A) upside down on padded non-marring surface. Insert 6x Dowels(H-5) and rotate 6x cam-bolts(H-1) into the holes in the Top panel(A). Place 6x cam-bolts(H-1) into the holes in the Vertical Panel(B) and attach using 6x cam-locks(H-2). Page 7... - Page 8 Step2: (H-3) Allen bolts x6 (H-5) Dowels x6 Assemble the Middle Panel(C). Insert 6x Dowels(H-5) in the Vertical Panel(B). Rotate 6x Allen bolts(H-3) into the holes in the Middle Panel(C) by Allen wrench. Step3: (H-1) Cam-bolts x2 (H-2) Cam-locks x2 (H-5) Dowels x6 Assemble the Vertical Panel(B).
- Page 9 Step4: (H-3) Allen bolts x6 (H-5) Dowels x6 Assemble the Bottom Panel(D). Insert 6x Dowels(H-5) in the Vertical Panel(B). Rotate 6x Allen bolts(H-3) into the holes in the Bottom Panel(D) by Allen wrench. Step5: (H-4) Screws x4 (H-5) Dowels x2 Assemble the Wood Rail(E).
- Page 10 Step6: Assemble the Feet(F). Rotate 4x Feet(F) into the holes in the Bottom panel(D). Step7: Upright the bookshelf. Adjustable levelers on foot.The bookshelf is now ready for use. Page 10...
-
Page 11: Care And Maintenance
Care & Maintenance Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. Do not place furniture in direct sunlight. Do not place furniture near heating or cooling vents. Do not write on furniture without a padded barrier to protect the surface. Do not place furniture outside.
