EVM User's Guide: TAA5242EVM-K TAD5242EVM-K TAC5142EVM-K
TAC5242EVM-K
TAx5x42EVM-K Hardware Control Evaluation Module
Description
The TAx5x42EVM-K evaluation module (EVM)
allows the user to test the capabilities of Texas
Instruments' TAC5242; a two-channel hardware
control high-performance Codec, TAC5142 a two-
channel hardware control Codec, TAA5242 a two-
channel hardware control high-performance ADC
or TAD5242 a two-channel hardware control high-
performance DAC. The evaluation module is paired
with the AC-MB, a flexible motherboard which
provides power, control and digital audio data to
the evaluation module. Other variants listed are also
supported where the user replaces the U1 unit with
the device of interest.
Get Started
1. Order the EVM from TAx5x1x product folder.
2. Download the latest TAx5x1x data sheet.
SLAU904 – OCTOBER 2023
Submit Document Feedback
Features
• High performance Mono/Stereo Codec with
dynamic range: 120 dB DAC and 115 dB ADC
• Standard performance Mono/Stereo Codec with
dynamic range: 106 dB DAC and 102 dB ADC
• On-board microphones provided for voice
recording testing
• Direct access to digital audio signals and control
interface for simple end-system integration
• USB connection to PC provides power, control,
and streaming audio data for easy evaluation
Applications
• AV receivers
• Video conference systems
• IP network camera
• Speakers
Copyright © 2023 Texas Instruments Incorporated
TAx5x42EVM-K Hardware Control Evaluation Module
Description
1
