- Page 1 VESTEL DISWASHER USER MANUAL BMJ – L501 X DISHWASHER...
- Page 2 Dear Customers, With an aim to provide products with quality higher than your expectations, VESTEL, offers you a new dishwasher produced at modern facilities with great care after applying diligent quality control processes. Before starting to use your dishwasher, please read this user’s manual completely. For product installation, please refer to the nearest VESTEL service center among the ones listed in authorized service centers manual.
-
Page 3: Table Of Contents
CONTENTS Getting familiar with your machine ………………………………………………………. Technical specifications ……………………………………………………………… • Conformity with the standards and Test data ………………………………………... • Safety information and Recommendations………………………........ Recycling ..………………………................• Safety information ………………………………………………………………………. • Recommendations …...…………………………………………………………………. • Items not suitable for dishwashing ……………………………………………………. •... - Page 4 Loading your dishwasher .…………………………………………………………………….. Dish rack …………………………………………………………………………………… • Alternative basket loads …………………………………………………......• Standard loading and Test data …………………………………………………………... • Programme descriptions .……………………………………………………………………... Programme items …………………………………………………………………………... • Switching on the machine and selecting a programme……………....... Switching on the machine………………………………………………………………….. • Programme follow-up………………………………………………………………………..
- Page 5 Worktop Rating plate Upper basket with racks Control Panel Detergent and rinse-aid dispenser Upper spray arm Lower basket Cutlery basket Lower spray arm Salt dispenser Filters Upper basket track latch...
-
Page 6: Getting Familiar With Your Machine
GETTING FAMILIAR WITH YOUR MACHINE 1.) Power On/Off Button 6.) Wash Dry / End-of-cycle indicator When the Power On/Off button is pressed, the lamp on the Y ou can m on itor the program m e status with the he lp of ‘wash/dry ’ an d ‘end ’ Start/Pause button starts lighting. -
Page 7: Technical Specifications
Technical specifications Capacity ………………………… 12 place settings Height …………………………… 845 mm Height (without worktop) ………. 815 mm Width …………………………….. 596 mm Depth ……………………………. 598 mm Net Weight ……………………... 46 kg 220-240 V, 50 Hz Electricity input ……………..2200 W Total Power …………………….. 2000 W Heating Power ………………….. -
Page 8: Recommendations
Only original spare parts should be used with the machine. • Before installing, be sure that the machine is unplugged. • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. •... -
Page 9: Items Not Suitable For Dishwashing
Place such hollow items as bowls, glasses and pots into the machine in such a way that they will • face down. You are recommended not to load into your machine any dishes different or more than indicated. • Items not suitable for dishwashing: Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials;... -
Page 10: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine, if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long-unused water inlet hose to your machine, run water through it for a while before making the connection. -
Page 11: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. - Page 12 To remove the worktop, remove the screws that hold the worktop which are located at the rear of the machine; then push the front panel 1 cm from the front side towards the rear and lift it. Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or...
-
Page 13: Prior To Using The Machine
Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... -
Page 14: Testing Strip
Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available). - Page 15 Adjust the water softener according to how hard your tap water is. Move the programme selector knob to the 0 (Reset) position while your machine is not in operation. After resetting your machine, press the Start/Pause button and keep it pressed down. Meanwhile, energise the machine by pressing the Power On/Off button.
-
Page 16: Detergent Usage
Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel, and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. -
Page 17: Filling With Rinse Aid And Making The Setting
When the conditions of use of such products and the machine settings are appropriate, • they ensure savings in salt and/or rinse aid consumption. Contact the detergent manufacturers if you are not obtaining good wash results (if your • dishes stay calcareous and wet) after having used 2 in 1 or 3 in 1 detergents. The scope of warranty for your machine does not cover any complaints caused by the use of these types of detergents. -
Page 18: Loading Your Dishwasher
LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. There are two separate baskets for you to load your dishes into your machine. You can load into the lower basket such round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. -
Page 19: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket Faulty loads... -
Page 20: Standard Loading And Test Data
Standard loading and test data Capacity: Upper and lower baskets: 12 place settings. The upper basket should be adjusted to high position. Cups should be placed on to the dish rack pins. Detergent / Rinse aid 5+25 cm , in accordance with EN50242-DIN 44990 IEC 436 (international norms) / Rinse aid dosage adjustment: 4 Programme test Economic 50°... -
Page 21: Programme Descriptions
PROGRAMME DESCRIPTIONS Programme items Reference Programme No Programme names Quick 30 min. Super 50 min. Intensive Hygiene Economic Temperatures 65°C 70°C 40°C 65°C 50°C soups, sauces, soups, sauces, Dishes with dense coffee, milk, coffee, milk, tea, pasta, pasta, tea, cold meats, cold meats, dirt waiting for a Type of food waste... -
Page 22: Switching On The Machine And Selecting A Programme
SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine Press the Power On/Off key. Select the program suiting your dishes via the Program Selection button. Once the Power On/Off key Start the program pressing is pressed, the lamp Power the Power Start/Pause key. -
Page 23: Changing A Programme With Resetting
Changing a programme with resetting If you would like to cancel a program while a washing program is resumed Press once the Power Turn the Program Start/Pause key. Selection Button to Reset The program will have been The machine will discharge the cancelled once the drying lamp water in it for nearly 30 sec. -
Page 24: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 25: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. -
Page 26: Failure Codes And What To Do In Case Of Failure
FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR CONTROL DESCRIPTION Wash/Dry Start/Pause • Make sure the water input tap is totally open and that Inadequate water there is no water cut. supply • Close the water input tap, separate the water input hose from the tap and clean the filter at the connection end of the hose. - Page 27 If water is left inside the machine at the end of the programme The water drain hose is clogged or twisted. • The filters are clogged. • The programme is not finished yet. • If the machine stops during a wash operation Power failure.
-
Page 28: Practical And Useful Information
PRACTICAL AND USEFUL INFORMATION Whenever you will not be operating your machine Unplug the machine and then turn the water off. • Leave the door slightly ajar in order to prevent the formation of unpleasant smells. • Keep the machine interior clean. •... - Page 29 THE PRODUCT FICHE (Spect) Supplier's trade mark VESTEL Supplier's model BMJ-L501 X Capacity of dishwasher 12 The energy efficiency class A + Annual energy consumption in kWh per year (AE ) ( 280 Cycle ) * Energy consumption (E ) (kWh per cycle) 0,95 Offmode power consumption (W) (P ) 0,05 Lefton mode power consumption (W) (P ) 0,50 Annual water consumption in litres per year (AW ) ( 280 Cycle ) ** 3360 Drying efficiency class *** A Standard programme name **** Eco 50 ˚C Programme time for standard cycle ( min) Noise dB(A) 52 * Energy consumption kwh per year, based on 280 standard cleaning cycles using cold water fill and the consumption of low power modes.
- Page 30 The lifetime of your product (the period during which the spare parts will be provided for its proper functioning) evaluated and announced by the Ministry of Customs and Trade is 10 years Producer Company: Vestel Beyaz Eşya Sanayi ve Ticaret A.Ş. Organize Sanayi Bölgesi 45030 Manisa - Türkiye Phone: 44 44 123 Fax: (0212) 321 17 90...
