Dishwasher
Instruction Manual
Instruction
Instruction
Instruction
Manual
Manual
Manual
S-E0440

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-E0440 and is the answer not in the manual?

Questions and answers

Related Manuals for VESTEL S-E0440

Summary of Contents for VESTEL S-E0440

  • Page 1 Dishwasher Instruction Manual Instruction Manual Instruction Instruction Manual Manual S-E0440...

  • Page 2: Table Of Contents

    CONTENTS Technical specifications ……………………………………………………………… • Conformity with the standards and Test data ………………………………………... • Safety information and Recommendations………………………........ Recycling ..………………………................• Safety information ………………………………………………………………………. • Recommendations …...…………………………………………………………………. • Items not suitable for dishwashing ……………………………………………………. • Installing the machine ………………………………………………………………………. Positioning the machine ………………………………………………………………... •...
  • Page 3 Loading your dishwasher .…………………………………………………………………….. 21 Dish rack …………………………………………………………………………………… • Alternative basket loads …………………………………………………......23 • Programme descriptions .……………………………………………………………………... 25 Programme items …………………………………………………………………………... 25 • Programme Selection and Operating the Machine …..…………....... Operating the Machine …...……………………………………………………………….. • Programme Monitoring …………………………………………………………………….. 28 •...
  • Page 4 Worktop Rating plate Upper basket with racks Control Panel Worktop Rating plate Upper spray arm Detergent and rinse-aid dispenser Upper basket with racks Control Panel Lower basket Cutlery basket Upper spray arm Detergent and rinse-aid dispenser Lower spray arm Salt dispenser Lower basket Cutlery basket Filters...

  • Page 5: Technical Specifications

    Technical specifications Capacity 10 place settings Height 850 mm Height 820 mm (without worktop) Width 450 mm Depth 598 mm Net Weight 36 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W...

  • Page 6: Safety Information And Recommendations

    SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling.
  • Page 7 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
  • Page 8 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.

  • Page 9: Recommendations

    For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •...

  • Page 10: Items Not Suitable For Dishwashing

    Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers.

  • Page 11: Water Connections

    Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning.

  • Page 12: Water Inlet Hose

    Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection.

  • Page 13: Water Outlet Hose

    Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink.

  • Page 14: Electrical Connection

    Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur.

  • Page 15: Fitting The Machine Undercounter

    Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
  • Page 16 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm 825 mm 835 mm...

  • Page 17: Prior To Using The Machine

    Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •...

  • Page 18: Testing Strip

    Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available).
  • Page 19 In accordance with the level determined on the test strip, perform the water hardness adjust- ment of your appliance as specified below. When the machine is off, press the program button (2). • Press the On/Off button (1) to switch on the machine and press and hold the program •...

  • Page 20: Detergent Usage

    Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children.
  • Page 21 If such detergents are in the form of tablets, never put them into the interior section or the • cutlery basket of the dishwasher. Always put the tablets into the detergent compartment in the detergent dispenser. They produce good results for certain types of usage only. If you are using this type of •...

  • Page 22: Loading Your Dishwasher

    Level Brightener Dose Indicator Rinse-aid not dispensed r1 is shown on the display. 1 dose is dispensed r2 is shown on the display. 2 doses are dispensed r3 is shown on the display. 3 doses are dispensed r4 is shown on the display. 4 doses are dispensed r5 is shown on the display.
  • Page 23 Top basket height adjustment Top basket of your machine is in upper position. When it is in this position, you can place big items such as pans, etc. on lower basket. When you take top basket to lower position, you can place and wash big sized plates on the top basket.

  • Page 24: Alternative Basket Loads

    Alternat˜ve basket loads Lo wer Basket Top basket...
  • Page 25 Fa ulty loads   Important Note for Test Laboratories   For detailed information on performance tests, please contact following address:   "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.  ...
  • Page 26 Program Definition Program No Program No Pre-wash Rapid Wash 30 min. Delicate Wash Temperatures 40°C 40°C Food residue type Pre-wash program that Coffee, milk, tea, cold Coffee, milk, tea, cold helps you soften and meat, vegetables (not meat, vegetables (not remove the residues left for a long time) left for a long time)
  • Page 27 Program Definition Program No Reference 4 Program No Eco (Economical) mode Super 50 min. Intense Wash Temperatures 50°C 65°C 65°C Food residue type Coffee, milk, tea, cold Soups, sauces, Soups, sauces, meat, vegetables (not pastries, eggs, pilaf, pastries, eggs, pilaf, left for a long time) potatoes, oven potatoes, oven...

  • Page 28: Programme Selection And Operating The Machine

    Program Selection and Operating the Machine You can press the On/Off button (4) to switch on the machine. On/off lights will be on so long as the machine is on. Press the program button (5) to set the suitable program. Press the Start/Pause button (6) to start the program.

  • Page 29: Changing The Programme

    Changing the Program Cancelling the Program When you want to change the program while a When you want to cancel the program while a washing program is running on. washing cycle is running on. Press Start/Pause button. Press and hold the Start/ Pause button for 3 seconds.

  • Page 30: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine.

  • Page 31: Spray Arms

    Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left.

  • Page 32: Failure Codes And What To Do In Case Of Failure

    FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR DESCRIPTION CONTROL Make sure the water input tap is totally open and that there is no water cut. • Inadequate water supply Close the water input tap, separate the water input hose from the tap and clean the filter at •...
  • Page 33 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.

  • Page 34: Practical And Useful Information

    If the dishes won't dry up A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. • If there are rust stains on the dishes Stainless-steel quality of the dishes washed is insufficient. •...
  • Page 35 THE PRODUCT FICHE   V E S T E L Supplier's trade mark  S-EO440 Supplier's model  Capacity of dishwasher  10   The energy efficiency class  A++  Annual energy consumption in kWh per year (AE ) ( 280 Cycle )*  0,73 Energy consumption (E ) (kWh per cycle)  Off­mode power consumption (W) (P )  0,50 Left­on mode power consumption (W) (P )  1,00 Annual water consumption in litres per year (AW )  ( 280 Cycle ) ** 3080 Drying efficiency class *** Standard programme name ****   Programme time for standard cycle ( min)  Noise dB(A)  * Energy consumption kwh per year, based on 280 standard cleaning cycles using cold water fill and the consumption of low power modes.
