RTS LKP-957 Installation Instructions Manual

Monitor keypanel

Advertisement

Quick Links

INSTALLATION INSTRUCTIONS

LKP-957
Monitor Keypanel
9330-7101-002 Rev A 3/94

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LKP-957 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RTS LKP-957

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS LKP-957 Monitor Keypanel ™ 9330-7101-002 Rev A 3/94...
  • Page 2: Table Of Contents

    MATRIX-TO-SPEAKER GAIN ..........2-1 LKP-957 Keypanel Installation...
  • Page 3: General

    They control the following functions: 1.3.1 DISPLAY TYPE SELECTION SW1-1 selects the keypanel display type: Open: Alpha-numeric displays Closed: LED displays (not applicable on the LKP-957) SW1-2 and 1-3 are not used, and the positions do not matter. 1.3.2 LOGICAL KEYPANEL NUMBER SW1-4 to SW1-7 select the logical keypanel number.
  • Page 4: Mounting The Keypanel And Expansion Panels

    Audio Input "+" Ground CONNECTOR DATA CONNECTOR KEYPANEL Figure 1-1. Keypanel to Matrix Interconnect Cables LKP-957 Keypanel Installation RJ-11 FRAME Connector Pin-out 1.5.2 OPTIONAL CONNECTIONS 1.5.2.1 HEADSET Connector Table 1-4 lists the HEADSET connector pin functions. RJ-11 USING THE RJ-11 CONNECTOR...
  • Page 5: Terminal Block Connections

    (See "System Menu, Force and Inhibit" in Section 3 of the CSedit Manual.) 1.6.1 POWER-UP SEQUENCE Plug in the ac power cord at the back of the LKP-957 keypanel. Turn on the power switch next to the power cord connector.
  • Page 6: General

    SECTION 2 LKP-957 KEYPANEL ELECTRICAL ADJUSTMENTS 2.1 GENERAL The following paragraphs describe the procedure to calibrate the input level to the factory standard of +8 dBu. If a different level is required, substitute that level for +8 dBu. Audio levels may be adjusted with the panel disconnected from the intercom system.
