Performance Specifications - Maple Systems IO-SHSC02 User Manual

Item
I/O Points
Number of Channels
Power consumption
Weight
Phase
Count Input
Level (фA,фB)
Signal
Types
Speed
Range
Mode
Count
Min. Count Pulse
Period (μS)
(Duty ratio 50%)
Compared range
Compared
Output
Comparison
Preset
External
Input
Enable Count
External
Output Compare
Output
Performance Specification
Model
IO-SHSC02
16 points
2 channels
90 mA
68.5g
1 Phase input/2 Phase input
5/12/24 V DC 2—5 mA
PNP Encoder (-Common)
200 kHz
32-bit signed binary values
(-2147483648—2147483647)
Up/Down Preset Counter + Ring Counter
32-bit signed binary values
Compared value < Present value
Compared value = Present value
Compared value > Present value
5/12/24 V DC 2—5 mA
TR (SINK Type) Output
12—24 V
