Summary of Contents for Maple Systems MOD-SENT01
- Page 1 USER MANUAL MAPLE MODULAR PLC Ethernet Module MOD-SENT01 • - 1 -...
-
Page 2: Table Of Contents
Contents General Specifications......... 7 Performance Specifications ......8 Features .............9 Dimensions ..........10 Product Warranty ........11 - 2 -... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from MAPLE SYSTEMS Inc. is prohibited. Safety symbols are classified into two categories: “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for wiring of Ethernet Module ( Caution) If duplicate station numbers exist, communication does not operate normally. Be sure to use the designated standard cable. Otherwise a communication failure may occur. User must check whether the communication cable is properly connected before use it. Be sure to wire communication cables correctly.
-
Page 7: General Specifications
General Specifications Items Specification Standards Op. Temp. -10℃–60℃ St. Temp. -25℃–80℃ Op. Hum 5–95% RH, Not condensed St. Hum 5–95% RH, Not condensed In case of Intermittent Vibration Frequency Acceleration Amplitude Sweep 5 ≤ f < 9 Hz 3.5 mm 10 times in X, Y, Z 9 ≤... -
Page 8: Performance Specifications
Performance Specifications ▶ Module Specification Model MOD-SENT01 Interface 10BASE-T, 100BASE-TX Data Transmit Speed 10/100 Mbps Max. Distance 100 m (Node) Service Capacity UDP, TCP 12 Services Loader Yes (UDP) MODBUS TCP SIave MODBUS TCP Master Service User Protocol Yes (TCP, UDP) -
Page 9: Features
3) Unlimited cards are supported on one PLC Base. 4) Provides a MODBUS TCP Master for MODBUS protocol communications to other devices. 5) Supports high-speed PLC Link communication between MAPLE SYSTEMS PLCs and can communicate with a maximum of 64 stations. -
Page 10: Dimensions
Dimensions (Unit: mm) ► MOD-SENT01 - 10 -... -
Page 11: Product Warranty
Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - 11 -... - Page 12 808 134th St SW #120 Everett, WA 98204 Web: www.maplesystems.com - 12 -...
