Targus ACH76US Quick Start Manual

Introduction
Congratulations on your purchase of the Targus Travel USB 2.0 4-Port Hub with Notebook Light, swivel connector, and retractable design. The travel
hub provides lighting to the Notebook, which can be turned off when the retractable light is placed back into the recessed position. The hub also
includes a clip on the back to attach it to the top of a notebook screen.
Features
Expand your capabilities – Simultaneously connect 4 USB devices such as mice, digital cameras, and flash drives to your notebook.
•
Built-in notebook light - Swivels 180 degrees to provide maximum keyboard illumination.
•
Built-in clip - Attaches hub to the back of the notebook.
•
To use the Travel USB 2.0 4-port Hub with Notebook Light
1. Insert the USB hub into a free USB port, ideally located on the side of your notebook.
NOTE:IF YOU DO NOT HAVE USB PORT ON THE SIDE OF YOUR NOTEBOOK, YOU CAN USE THE USB EXTENSION CABLE PROVIDED TO EXTEND THE CONNECTION FROM THE
BACK OF YOUR NOTEBOOK TO THE SIDE OR TOP OF YOUR NOTEBOOK AND USE THE CLIP ON THE BACK OF THE HUB TO ATTACH TO YOUR NOTEBOOK (PLEASE NOTE DUE
TO VARIATIONS IN NOTEBOOK THICKNESS, THE STABILITY OF HUB MAY BE AFFECTED).
2. Pivot the notebook light to the proper angle for maximum keyboard illumination.
3. You may now connect other USB devices to the hub.
Features and specifications subject to change without notice. Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. All rights reserved. All trademarks and registered trademarks are the properties of their respective owners. © 2006, Targus Group International,
Inc. and Targus, Inc., Anaheim, CA 92806 USA.
USB Extension Cable (included)
Notebook (not included)
Travel USB 2.0
4-port Hub
with Notebook Light
180°
90° forward
90°
backward
270°
180°
90° forward
90°
backward
Plug-in USB device(s)
270°

Quick Start

To USB
Extension Cable
ACH76US / 410-0786-001A
