NIXON THE BASE TIDE - Watch Manual

Watch Overview

Pushers Overview - Part 1

Pushers Overview - Part 2

WATER RESISTANCY RATINGS AND WATCH CARE

CASE RATING RAIN,
SPLASHES,
ETC.
SHALLOW SWIMMING,
SUBMERSION*
SURFING,
SNORKELING,
SPEAR FISHING*
30 METER
50 METER
100-200 METER
A FEW OF OUR WATCHES ARE GEARED TOWARDS PURE STYLE AND ARE NOT DESIGNED FOR SURE OR SWIM. THIS IS INDICATED BY THE "NO WATER" ICON.

*RINSE WATCH WITH SOAP AND WATER AFTER EXPOSURE TO SALT WATER OR SAND.

Replace the battery at least every two years. Dead or low batteries left in a watch may leak and destroy the movement of your watch. If you have a water resistant watch, know that the water resistancy is attained using rubber or plastic seals which will deteriorate under normal conditions and reduce the water resistancy of your watch. These seals should be checked by an authorized jeweler at least every two years to ensure the rated water resistancy. Do not expose your watch to extreme temperatures (over 60ºC or 140ºF, under -10ºC or 14ºF). No hot tubs or saunas. Sorry, but do you really need to know the time when you're tubbing?
Avoid extreme shocks.

TIME MODE

TIME MODE FEATURES

  • hours, minutes and seconds display in 12 or 24 hour format
  • month and date display or tide graph

To set the time on your watch:

  • Press PUSHER B (MODE) until you are in Time Mode
  • Press and hold PUSHER B to enter Time Mode setting state (seconds will begin to blink)
  • Press PUSHER C to increment the value
  • Press and hold PUSHER C to quickly increment the value
  • Press PUSHER D to decrement the value
  • Press and hold PUSHER D to quickly decrement the value
  • Press PUSHER B to advance through second, hour, minute, year, month, date, 12/24hr
  • Press and hold PUSHER B to confirm and exit setting state
  • To switch between TIDE or DATE display on the Home Screen, press PUSHER C
  • To peek the next tide event, press and hold PUSHER D
  • To toggle hourly / button chime on or off, press PUSHER D
  • Press PUSHER B to advance to TIDE MODE

TIDE MODE

TIDE MODE
features current, future, and past tide events, based on Basic Tide calculation

  • Display will automatically show next tide event
  • Press PUSHER C to advance to next tide event (after "TOMORROW" it will show the date)
  • Press PUSHER D to scroll to previous tide event (before "TODAY" it will show the date)

To set the TIDE:

  • Using a trusted tide data source, determine the time of the next high tide. This is the time you will set your watch to in the next steps.
  • Press and hold PUSHER B to enter Tide Setting State (hours will begin to blink)
  • Press PUSHER C to increment the value
  • Press and hold PUSHER C to quickly increment the value
  • Press PUSHER D to decrement the value
  • Press and hold PUSHER D to quickly decrement the value
  • Press PUSHER B to advance to minutes, and then seconds
  • Press and hold PUSHER B to confirm and exit setting state
    NOTE: Basic Tide is intended to give approximate tide event times. It should not be used for critical navigation purposes. For most accurate data, tide function should be reset periodically by following the steps above.
  • Press PUSHER B to advance to CHRONOGRAPH MODE

CHRONOGRAPH MODE

CHRONOGRAPH MODE features

  • Hundredth seconds resolution

To operate the Chronograph:

  • Press PUSHER C to start Chronograph run state
  • In run state, press PUSHER C to stop the Chronograph
  • Once stopped, press and hold PUSHER D to reset
  • Press PUSHER B to advance to TIMER MODE

TIMER MODE

TIMER MODE features

  • 7 preset timer options
  • 1 customizable option

To set the TIMER:

  • Press PUSHER D to cycle through the preset options, or select custom

If CUSTOM is selected (display will read: TIMER CU):

  • Press and hold PUSHER B to enter Timer

Mode setting state

  • Press PUSHER C to increment the value
  • Press and hold PUSHER C to quickly increment the value
  • Press PUSHER D to decrement the value
  • Press and hold PUSHER D to quickly decrement the value
  • Press PUSHER B to advance from minutes to seconds
  • Press and hold PUSHER B to confirm and exit setting state

To operate the TIMER:

  • Press PUSHER C to start the timer
  • Press PUSHER C to stop the timer
  • Press and hold PUSHER D to restart the timer
  • Press any pusher to stop the alarm once time has expired
  • Press PUSHER B to advance to TIME MODE

www.nixon.com
