ASSEMBLY INSTRUCTIONS:
1. Bolt handles to each end of the housing using the two M8 handle bolts for each handle.
RECONFIGURING DRAWERS:
1. Drawers of the same height and width can be
rearranged.
WARNING! To prevent serious injury or death
from tipping, all drawers must be reinstalled
before use. Do not use if partially assembled.
WARNING! To prevent serious injury from
electric shock, disconnect power cord from
trolley before reconfiguring drawers.
2. Remove the drawers you want to move.
To do this, please follow the below steps:
a. Slide the drawer out until it stops and empty
all of its contents.
b. There will be a small lever at the end of each
drawer slider. Push up on the right lever
and down on the left lever.
c. While holding the levers, slide the drawer out
completely and place on a flat stable surface.
Drawer Slider
3. After removing the drawers, check where the
slides are positioned on them. All sliders on each
drawer must be fully supported by drawer sliders.
4. Reposition drawer sliders as needed to properly
support the drawer as explained in the
following steps.
5. Install the drawers according to the following
instructions:
a. Select a properly sized drawer to install.
b. Confirm that all drawer sliders are properly
c. Slide all drawer sliders out fully.
d. Confirm that ball bearing racks are at the front
e. Carefully partially slide the drawer in and check
NOTICE: Do not force the drawer.
If the drawer does not slide in easily, the sliders are
likely misaligned or not installed correctly.
f. Slide the drawer in completely.
g. Slide it back out to make sure the sliders keep
h. Slide the drawer closed.
Lever
aligned with the sliders on the trolley.
of each slide.
again that all sliders are engaging properly.
it from coming disengaged.
