TEW-PS3 F.A.Q.
Q: Why doesn't PS-Admin utility detect my print server?
A:
If you are using Windows XP you will have to disable the built in firewall. But for all operating
systems you have to disable any other form of firewall software such as Norton Internet Security,
Black Ice, and ZoneAlarm.
Make sure that you have "Client Services for Netware" installed, it should automatically install
IPX/SPX. If not please do so.
Note: Windows XP Home edition does not have the capability to install Client Services for
Netware.
Make sure the dip switch is switched over to Ad-Hoc mode on the back of the print server, unplug
the electrical power for 15 seconds then plug the power back in.
Q: How do I change the IP address of my print server?
A:
Step 1.
Open up the PS-Admin Utility and click on "TCP IP Protocol".

Advertisement

loading
Need help?

Need help?

Do you have a question about the TEW-PS3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet TEW-PS3

Summary of Contents for TRENDnet TEW-PS3

  • Page 1 TEW-PS3 F.A.Q. Q: Why doesn't PS-Admin utility detect my print server? If you are using Windows XP you will have to disable the built in firewall. But for all operating systems you have to disable any other form of firewall software such as Norton Internet Security, Black Ice, and ZoneAlarm.
  • Page 2 TEW-PS3 F.A.Q. Step 2. Change IP Address: In this dialog box, you can Manually Assign. When completed, click “OK”. Q: How do I find the Port Name of the Print Server? Step 1. Click on “Server Device”.
  • Page 3 TEW-PS3 F.A.Q. Step 2. Click on the port that you have your printer plugged into. Step 3. Write down the Port Name for future reference. Q: How do I setup my wireless settings? Step 1. Click on “Server Device”.
  • Page 4 TEW-PS3 F.A.Q. Step 2. Click on the “Wireless” button. Step 3. Input the ESS-ID and channel of your wireless access point or router. If you are using Encryption on your wireless network, you will be required to input the WEP key. For 64 bit hex you will be required to input 10 characters and for 128 bit WEP, you will be required to input 26 characters.
  • Page 5 TEW-PS3 F.A.Q. Step 2 Highlight Client and click on Add. Step 3. Click on Have Disk > Browse. Browse to the location of the extracted LPR Client. Step 4. Click OK 3 times.
  • Page 6 TEW-PS3 F.A.Q. Step 5. From the list highlight LPR for TCP/IP and click on Properties. Step 6. Click on Add Port.
  • Page 7 TEW-PS3 F.A.Q. In the top field type in the IP address of your print server. In the bottom field type in the port name of your print server, the Port Name is the PS-xxxxxx-P1, x being the actual number listed in the Port Name box.
  • Page 8 TEW-PS3 F.A.Q. Step 3. Select Network Printer and click on Next. Step 4. Click on the Browse button and browse to the print server.
  • Page 9 TEW-PS3 F.A.Q. Step 5. Highlight the Print Server and click on OK to return to the Add Printer Wizard. Step 6. Click on Next. If you are unable to do this you can manually enter the Print Server by using two backlashes, the IP address, one backlash and the port name of you printer.
  • Page 10 TEW-PS3 F.A.Q. Step 9. Once the drivers been installed, click Finish to complete the installation. You may be prompted for your Windows CD. If you are prompted for the CD, browse to the Win98 f older on the Windows CD and click on OK Step 10.
  • Page 11 TEW-PS3 F.A.Q. Step 4. Enter the IP address of the router (192.168.0.1). Leave the port name with the default name. Click Next. Step 5. You will get a message saying that additional port information required. Step 6. Select Custom and then click Settings.
  • Page 12 TEW-PS3 F.A.Q. Step 7. Set Protocol to LPR. Step 8. For the LPR Settings for the TEW-PS1U the Queue Name will be PS-xxxxxx-P1, X being the actual number listed in the Port Name box. It is case sensitive! Step 9.
  • Page 13 TRENDnet print servers do not support embedded driver codes. TRENDnet print servers, whether in Gateways or Stand Alone, are plain TCP/IP print servers.
  • Page 14 TEW-PS3 F.A.Q. Step 2. Click on the port that you have your printer plugged into. Step 3. Change the Speed using the drop down menu.
