19-03783-90
20-03797-10
19-03962-90
19-03963-90
33 ft-lbs / 44 Nm
19-03901-90
1
Install bracket to truck Torque nuts to
59 ft-lbs / 80Nm
3
aMP reSearCH TeCH SuPPOrT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 aM - 5:00 PM PST
Designed and manufactured by aMP research
7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other uS and Worldwide patents pending. Made in uSa © 2009 aMP research
Three-year limited warranty. Professional installation is recommended.
www.amp-research.com
Chevy Silverado / GMC Sierra
1500
11-03639-90
19-03948-90
19-03961-90
18mm
. Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221;
®
/2
2014
19-03901-90
19-03900-90
19-03377-90
remove factory nuts
2
Insert threaded bracket (19-03963-90) into bum-
per and assemble bracket (19-03961-90) with
supplied bolt. Use slotted end of bracket at
bolt.
4
ParT NuMber:
aMP 75314-01a
Torque wrench
18mm
13mm
T25
18mm
13mm
IM75300 rev 0.7.3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMP Research BedStep 75314-01a
Summary of Contents for AMP Research BedStep 75314-01a
- Page 1 Designed and manufactured by aMP research . Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221; ® 7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other uS and Worldwide patents pending. Made in uSa © 2009 aMP research Three-year limited warranty. Professional installation is recommended. www.amp-research.com...
- Page 2 Install bracket (19-03962-90) to upper bed panel. Slotted side will mount on bed panel. See im- age for bracket orientation. use provided bolts and nuts to mount and torque bolts to 16 ft-lbs / 22Nm 13mm Install step pad. Offset pad to rearward position Torque 3 PT screws to 5 ft-lbs /6Nm Note: Overtightening screws may damage step pad.
- Page 3 LIMI T ED WARRANTY AMP RESEARCH warrants product to be free from defects in material and workmanship, for terms speci ed below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replace- ment of any item found by the factory to be defective within the time period speci ed.
