TRENDnet TE100-S24WS Specifications

TE100-S24WS
24-port 10/100Mbps Web-Based Smart Switch
TRENDnet's TE100-S24WS 24-port 10/100Mbps Web-
Based Smart Switch is the ideal Switch for network
segmenting. It has 24 10/100Mbps Auto-Sensing and Auto-
MDIX ports for easy installation. The Switch also has a
module slot that accepts optional single- or multi-mode
100Based-FX fiber module for connection up to 15Km.
TE100-S24WS supports web browser configuration; Network
Administrator can use web browser to configure port speed,
port-based VLAN and QoS, and also monitor each port's
status. TRENDnet's TEW100-S24WS is powerful and easy-
to-use in reducing unnecessary broadcast traffic and enhance
network security.
FEATURES
24 10/100Mbps Auto-negotiation, Auto-MDIX Fast Ethernet
Ports
1 module slot for optional multi-mode (2Km) or single-mode
(15Km) 100Base-FX SC fiber module
Full/Half-Duplex transfer mode for each port
Full wire-speed Non-Blocking reception and transmission
Store and Forward switching method
768K bytes RAM data buffer and 4K entries MAC address table
Extensive diagnostic LED's on the front panel
IEEE 802.3x flow control for full-duplex mode; Back Pressure
flow control for half-duplex mode
Easy configuration via Web browser
Proprietary Windows Based Management/Monitoring Utility
(similar to SNMP Trap)
Port-Based VLAN (25 groups) and Port-Based IEEE 802.1p
QoS (High/Normal)
Port Setting function, users can set each port's availability,
speed, duplex mode, and flow control
Standard 19" Rack-mount design
5-Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Easy Installation:
Each RJ-45 port auto-senses
connection speed, duplex type and MDI-
X media type. Connect to 10 or
100Mbps network devices with straight
through or crossover cable.
Expandability:
Expand the connection up to 15Km with
optional single-mode SC-Type fiber
module.
Flexibility:
Easy configuration and management
through Web Browser.
Performance:
Non-blocking high performance with
internal Switch Controller.
Cost-Effectiveness:
Provides Fast Ethernet Switch with
management functions at an affordable
price.
TE100-S24WS (08-25-2003)
