TRENDnet TE100-S24plus Specifications

TE100-S24plus
24-port 10/100Mbps NWay Switch (Rack Mount)
TRENDnet's TE100-S24plus is a high performance, auto-
sensing 24-port NWay rack-mountable Fast Ethernet Switch.
It is designed to eliminate unnecessary traffic and relieve
congestion on critical network paths. With 10/100Mbps NWay
technology, the TE100-S24plus automatically negotiates
between 10Base-T and 100Base-TX network speeds, as well
as half and full duplex modes. The TE100-S24plus also has a
module bay for optional multimode SC type fiber module that
allows connection to another fiber device up to 2Km away (in
full-duplex mode). The auto MDI-II/MDI-X detection on each
port automatically detects and corrects for crossover
connection and allows direct switch-to-switch or switch-to-
hub connection for your networking needs.
FEATURES
24 10/100Mbps NWay Auto MDI-II/MDI-X ports
Integrate address Look-Up Engine, supports up to 4K
absolute MAC address
768KB internal RAM for frame buffering
Full/half duplex transfer mode for each port
Wire-speed filtering/forwarding rates
IEEE 802.3x flow control for full-duplex mode
Back pressure flow control for half-duplex mode
Store-and-forward switching method
Extensive front-panel diagnostic LEDs
One module bay for optional one-port 100Base-FX
multimode SC type fiber connection
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Performance:
Top performance at an affordable
price.
Expandability:
Current Ethernet workgroups are able
to upgrade to Fast Ethernet by
changing adapters and hubs without
changing switches.
Flexibility:
All ports automatically negotiate
10/100Mbps network speed, half/full-
duplex mode, and MDI-II/MDI-X
connector type.
Expandability:
Optional 100Base-FX multimode SC
type module links to other fiber device
up to 2Km in full-duplex mode.
Cost Effectiveness:
Provide 10/100Mbps of Fast Ethernet
at an affordable rate.
TE100-S24plus (11-17-2002)
