TRENDnet TE100-S22 Specifications

TE100-S22

FEATURES

• Compliant with IEEE 802.3 10Base-T, IEEE 802.3µ 100Base-TX standard
• Supports two RJ-45 10/100Mbps auto-sensing ports
• 10/100Mbps auto-negotiation and auto-sensing on all ports
• Full/half duplex operation for each port
• Store-and-forward packet switching
• Built-in address self-learning mechanism
• Built-in 120 KB packet buffer per port
• MDI-X/MDI selection switch, no cross-over cable required
5-years warranty
TREND SPEC'S
Protocol:
Speed:
Cabling:
LED's:
Power:
Dimensions:
Weight:
Operating:
Storage:
Humidity:
Certification:
TRENDnet 2-Port 10/100Mbps NWay
Auto-sensing Switching Hub
The TE100-S22 is a trend that won't go out of
style that can easily link 10Mbps and 100Mbps network
segments.
allows you to connect as many hubs as needed to
overcome Fast Ethernet Class II limitation. With its plug
and play capabilities, the TE100-S22 is easy to install. In
addition, the TE100-S22 is equipped with a variety of
LED's for easy viewing and troubleshooting.
CSMA/CD
10Mbps (half duplex) / 20Mbps (full duplex) for 10Base-T
100Mbps (half duplex) / 200Mbps (full duplex) for
100Base-TX
CAT 3, 4, 5 UTP/STP for 10Base-T
CAT 5 UTP/STP for 100Base-TX
Power, Link, Transmit, Receive and 10/100Mbps status
External Power Supply, 600mA, 12V
201 x 122 x 30 mm / 7.9" x 4.8" x 1.2" (L x W x H)
685 g / 1.5 lb
0° to 50° C
-20° C to 80° C
10% - 90% (non-condensing)
FCC Class A, UL, CSA, CE
The TE100-S22 is a switching hub that
