TRENDnet TE100-S28plus Specifications

TE100-S28plus

FEATURES

•
Compliant with 10Base-T, IEEE802.3 and 100Base-TX, IEEE802.3µ standards
• Two ports for 10/100Mbps support, eight ports for 10Mbps support
• Built-in address self-learning technology
• EIA-19" Rack Mountable
• Store-and-Forward Ethernet packet switching provides low latency and high data
integrity
• All ports support full-duplex/half-duplex operation
• Comprehensive LED indicators to facilitate monitoring and troubleshooting
5-years warranty
TREND SPEC'S
Standard:
Protocol:
Speed:
Cabling:
LED's:
Power:
Dimensions: 411 x 203 x 44 mm / 16.18" x 17.99" x 1.73" (L x W x H)
Weight:
Operating:
Storage:
Humidity:
Certification: FCC, UL, CSA, CE
The TE100-S28+ switching hub provides a cost-effective,
high-bandwidth solution for delivering wire-speed to eight
10Mbps and two 10/100Mbps Ethernet ports and allows
easy integration of 10-BaseT and 100Base-TX Ethernet
workgroups into one network. All ports are full-duplex,
which allows maximum network performance. A built-in
automatic address learning function allows for a safer
and more flexible network.
forward switching provides low latency and high data
integrity.
IEEE 802.3µ, 100Base-TX, and IEEE 802.3 10Base-T
CSMA/CD
10Mbps for 10Base-T/100Mbps for 100Base-TX
CAT 3, 4, 5 UTP/STP for 10Base-T/CAT 5 UTP/STP for 100Base-TX
62.5/125 micron multimode fiber (2km)
Per Hub: Power
Per 10/100Mbps port:
Per 10Mbps port:
Internal Power Supply, (100 - 240V, 50/60Hz)
2.98 Kg / 6.56 lb.
0° to 50° C / 32° to 122° F
-20° to 80° C / -4° to 176° F
10% to 90% (non-condensing)
10-Port (2 x 10/100Mbps, 8 x 10Mbps)
Fast Ethernet Switching Hub
Link, Activity, 100Mbps, Full-Duplex
Link, Activity, Full-Duplex
Additionally, store-and-
