5420 DANIELS STREET STE A, CHINO CA 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198
RS -9 Stainless Steel Full-System
CAUTION: The muffler packing on this system MUST be replaced every
6-8 hours of use, or after each moto. Failure to follow recommended
muffler re-packing interval can cause muffler damage and may void the
warranty.
NOTE: IN THE STATE OF CALIFORNIA, IT IS ILLEGAL TO MODIFY THE EMISSION CONTROL SYSTEM, WHICH INCLUDES THE CARBURETORS OF ANY
1
RESEARCH&DEVELOPMENT OF AMERICA, INC.
www.yoshimura-rd.com
ENDURO SERIES
Qualified Manufacturer Declared "Replacement Part "
Kawasaki
2011~2023 KLX140(R)
2011~2023 KLX140(R)L
2017~2023 KLX140G/RF
24140AH320
Enduro Series systems are:
• Equipped with USFS-approved spark arrestor.
• CARB/EPA tail-pipe emissions compliant.
• All applications are marked with appropriate EPA noise labels.
• Have not been tested for EPA new vehicle noise compliance.
(AL/CF)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yoshimura ENDURO 24140AH320
Summary of Contents for Yoshimura ENDURO 24140AH320
- Page 1 RESEARCH&DEVELOPMENT OF AMERICA, INC. 5420 DANIELS STREET STE A, CHINO CA 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198 www.yoshimura-rd.com ENDURO SERIES Qualified Manufacturer Declared “Replacement Part ” Kawasaki 2011~2023 KLX140(R) 2011~2023 KLX140(R)L 2017~2023 KLX140G/RF 24140AH320 (AL/CF)
- Page 2 RACE-SPX-1 6x8mm Flange Button Head Screw RC116HSB 8x20mm Flange Hex Bolt M8X20H ** Spring Puller Tool ST-200 ** Spark Arrester Kit SA-15-K ** Yoshimura Vinyl Sticker 17029 Note: Spark arrester must be installed for USFS compliance. **Not shown in diagram...
- Page 3 Do not torque at this precautionary measures to avoid time. injury. 2. Install (No. 2) 24140-144, Yoshimura tailpipe inlet WARNING: Always properly support vehicle with over (No. 1) 24140-101, Yoshimura header outlet a stand and/or lift when servicing or as shown in Fig B.
- Page 4 The color of the exhaust will change once the system has gone through a heat cycle of 15 9. Install (No. 4) 24140-HS, Yoshimura heatsheild minutes or more. Color will vary depending on onto (No. 1) 24140-101, Yoshimura header lean/rich conditions.
- Page 5 RS9-RING-1125 5mm x 14mm Button Head Screw M5X14BHS 5mm Lock Nut 5MMLN-U Yoshimura Exhaust USFS Spark Arrestor Label 17086 Tools Needed: 4mm Allen Key • 8mm Deep Socket • Wire Brush • Pair of Gloves • Safety Glasses Using a 4mm allen key and 8mm deep socket, remove the bolt and nut that secures the aluminum ring and spark arrestor to the muffler (see Parts Diagram).
- Page 6 Dear Yoshimura Customer, Congratulations and thank you for purchasing a Yoshimura Exhaust System. Over six decades of experience in research and development, state of the art machinery, materials and craftsmanship of the highest quality all come together in a product of exceptional quality and performance—in other words, this is the best thing you can put on your bike.
- Page 7 When you are performing periodic maintenance on your vehicle (like a tire change, or an oil change) you can remove your Yoshimura muffler from the vehicle and weigh it again.
- Page 8 (found on header and tail-pipe components). 6. Also, feel free to ask through online e-mail at sales@yoshimura-rd.com, or fax your question/problems to (909) 591- 2198. To obtain technical information directly from Yoshimura, call (909) 628-4722.
