PERFORMANCE EXHAUST SYSTEM
APPLICATION
MAKE
Kawasaki
PRODUCT
1418040220
1418040520
1418040550
1418040720
This product is designed for use in closed course racing and is not intended for highway use.
In the state of California, it is illegal to modify the emission control system, which includes the fuel injection system of any vehicle.
You must know how to remove and replace your stock exhaust in order to install this product otherwise have it installed by a professional
mechanic. Keep all stock parts from your existing system as some components may be necessary to install your new Yoshimura exhaust
depending on the application.
Read through all instructions before beginning installation. Exhaust system can be extremely hot. Let motorcycle cool down before beginning
installation. Always wear hand and eye protection and take precautionary measures to avoid injury.
3
4
5
No.
Part #
1
14180-415
2
14180-419
3
CRR77116W
SRR77116W
SRR77116W-SS
TRR77116W
4
HT SHLDR77
MODEL
ZX10R
R77 Stainless Steel 3/4 Exhaust System with Carbon Fiber Sleeve; Carbon Fiber Endcap
R77 Stainless Steel 3/4 Exhaust System with Stainless Steel Sleeve; Carbon Fiber Endcap
R77 Stainless Steel 3/4 Exhaust System with Stainless Steel Sleeve; Stainless Steel Endcap
R77 Stainless Steel 3/4 Exhaust System with Titanium Sleeve; Carbon Fiber Endcap
S
7
Description
Qty
Yoshimura Midpipe
1
Yoshimura Tailpipe
1
Yoshimura Muffler
1
CF Sleeve; CF Endcap
SS Sleeve; CF Endcap
SS Sleeve; SS Endcap
Ti Sleeve; CF Endcap
Muffler Clamp
1
Heat Shield
5420 Daniels Street Chino, CA 91710 Tel (800) 634-9166 Fax (909) 591-2198
1418040(220,520,550,720).doc
7
2
7
5
1121-MPCL
1121-MPCLX
6
10MMFNUT
7
RACE-SPS-1
8
20067
**
INS-03-K
INS-04-K
**
17029
**
ST-200
www.yoshimura-rd.com
6
S
8
S
1
S = Stock
Muffler Clamp
CF Sleeve Clamp
SS/Ti Sleeve Clamp
10mm Flanged Nut
Medium Spring
Exhaust Clamp
SS EC Low Vol. Insert Kit
CF EC Low Vol. Insert Kit
Yoshimura Sticker Sht.
Spring Puller Tool
Page 1 of 2
1
1
4
1
1
1
1
