Asus TS500-E8-PS4 V2 User Manual

Asus TS500-E8-PS4 V2 User Manual

5u rackmount server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TS500-E8-PS4 V2
5U Rackmount Server
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Asus TS500-E8-PS4 V2

Summary of Contents for Asus TS500-E8-PS4 V2

  • Page 1 TS500-E8-PS4 V2 5U Rackmount Server User Guide...
  • Page 2 ASUSTeK COMPUTER INC. (“ASUS”). ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no...

  • Page 3: Table Of Contents

    Contents Safety information ....................viii About this guide ......................ix Chapter 1: Product Introduction System package contents ................. 1-2 Serial number label ..................1-3 System specifications ................1-4 Front panel features ................... 1-6 Rear panel features ..................1-7 Internal features ..................1-8 LED information ..................
  • Page 4 2.6.4 Removing the backplane............2-20 Expansion cards ..................2-21 2.7.1 Installing an expansion card............2-21 2.7.2 Installing an ASUS PIKE II card ..........2-22 2.7.3 Installing an M.2 card ..............2-24 Cable connections ................... 2-25 2.8.1 Motherboard connections............2-25 2.8.2 SATA/SAS backplane cabling ...........
  • Page 5 Contents Chapter 5: BIOS Setup Managing and updating your BIOS ............5-2 5.1.1 ASUS CrashFree BIOS 3 utility........... 5-2 5.1.2 ASUS EZ Flash Utility ..............5-3 5.1.3 BUPDATER utility ............... 5-4 BIOS setup program .................. 5-6 5.2.1 BIOS menu screen ..............5-7 5.2.2...
  • Page 6 Contents IntelRCSetup menu .................. 5-24 5.5.1 Processor Configuration............5-25 5.5.2 Advanced Power Management Configuration......5-27 5.5.3 Common RefCode Configuration ..........5-28 5.5.4 QPI Configuration..............5-29 5.5.5 Memory Configuration ............... 5-30 5.5.6 IIO Configuration ............... 5-33 5.5.7 PCH Configuration ..............5-34 5.5.8 Miscellaneous Configuration .............
  • Page 7 I210 Gigabit Adapters driver ........7-19 VGA driver installation ................7-22 ® Intel Rapid Storage Technology enterprise 4.0 installation ....7-24 Appendix Z10PA-D8 block diagram ..................A-2 Notices ........................A-3 REACH ....................A-4 ASUS Recycling/Takeback Services ............A-4 Australia statement notice ................A-4 ASUS contact information ..................A-5...

  • Page 8: Safety Information

    Safety information Electrical Safety • Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged. • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

  • Page 9: About This Guide

    About this guide Audience This user guide is intended for system integrators, and experienced users with at least basic knowledge of configuring a server. Contents This guide contains the following parts: Chapter 1: Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.
  • Page 10 Refer to the following sources for additional information, and for product and software updates. ASUS Server Web-based Management (ASWM) user guide This manual tells how to set up and use the proprietary ASUS server management utility. ASUS websites The ASUS websites worldwide provide updated information for all ASUS hardware and...

  • Page 11: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product Introduction This chapter describes the motherboard features and the new technologies it supports.

  • Page 12: System Package Contents

    System package contents Check your system package for the following items. Model Name TS500-E8-PS4 V2 Chassis ASUS T50A Pedestal 5U Rackmount Chassis Motherboard ASUS Z10PA-D8 Server Board 1 x 500W 80PLUS Bronze Single Power Supply 4 x hot-swap HDD trays...

  • Page 13: Serial Number Label

    Serial number label Before requesting support from the ASUS Technical Support team, you must take note of the product’s serial number containing 12 characters such as xxS0xxxxxxxx shown as the figure below. With the correct serial number of the product, ASUS Technical Support team members can then offer a quicker and satisfying solution to your problems.

  • Page 14: System Specifications

    System specifications The ASUS TS500-E8-PS4 V2 is a 5U barebone server system featuring the ASUS Z10PA-D8 ® ® ® Server Board. The server supports Intel LGA2011-3 Intel Xeon E5-2600 Processor v3 plus other latest technologies through the chipsets onboard. Model Name...
  • Page 15 Enterprise Linux ® SuSE Linux Enterprise Server OS Support CentOS Ubuntu VMware Citrix XenServer Please find the latest OS support from www.asus.com. (Subject to change without any notice) Software ASWM Enterprise Management Out of Band Solution ASMB8-iKVM for KVM-over-Internet Remote...

  • Page 16: Front Panel Features

    Front panel features Message LED LAN1 LED HDD access LED LAN2 LED Locate LED Power LED (Reserved) Optical drive (optional) Empty 5.25-inch bays Security lock Power button Reset button 4-bay HDD cage Headset port* Mic In port* 4-bay HDD cage (Optional Set) USB 2.0 ports USB 3.0 ports...

  • Page 17: Rear Panel Features

    Chassis lock PS/2 mouse/keyboard port USB 2.0 ports VGA port 120mm x 38mm system fan Gigabit LAN ports LAN port* USB 3.0 ports Chassis intrusion switch Expansion slots * This port is for the ASUS ASMB8-iKVM controller only. ASUS TS500-E8-PS4 V2...

  • Page 18: Internal Features

    Internal features The barebone server includes the basic components as shown. 500W Power Supply 120mm x 38mm system fan ASUS Z10PA-D8 Server Board Chassis intrusion switch Expansion card locks Optical drive (optional) 2 x 5.25-inch drive bays 4-bay HDD module (first set)

  • Page 19: Led Information

    Green/Red Blinking HDD rebuilding using the RAID card No LAN connection LAN LEDs Blinking LAN accessing LAN connection is present Locate LED Locates a specific server The Power, HDD Access, LAN and Message LEDs are visible even if the system front bezel is closed. ASUS TS500-E8-PS4 V2...

  • Page 20: Rear Panel Leds

    1.7.2 Rear panel LEDs ACT/LINK LED ACT/LINK LED SPEED LED SPEED LED ACT/LINK LED SPEED LED ACT/LINK LED SPEED LED Status Description Status Description No link 10 Mbps connection GREEN Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection Chapter 1: Product Introduction 1-10...

  • Page 21: Chapter 2: Hardware Information

    Chapter 2: Hardware Information Hardware Information This chapter lists the hardware setup procedures that you have to perform when installing or removing system components.

  • Page 22: Chassis Cover

    Chassis cover 2.1.1 Removing the side cover • Ensure that you unplug the power cord before removing the side cover. • Take extra care when removing the side cover. Keep your fingers from components inside the chassis that can cause injury, such as the CPU fan, rear fan, and other sharp-edged parts. To remove the side cover: Remove the two screws that secure the side cover. Slide the side cover for about half an inch toward the rear until it is disengaged from the chassis.

  • Page 23: Reinstalling The Side Cover

    Match and insert the lower sliding edge of the side cover to the corresponding chassis edge. Slide the side cover toward the front panel until it snaps in place. Secure the side cover with the two screws you removed earlier. ASUS TS500-E8-PS4 V2...

  • Page 24: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) ® The motherboard comes with a surface mount LGA 2011-3 Socket designed for the Intel Xeon E5-2600 v3 processor family. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA 2011-3 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. 2.2.1 Installing the CPU To install a CPU: Locate the CPU socket on the motherboard. Chapter 2: Hardware Information...
  • Page 25 Before installing the CPU, ensure that the socket box is facing toward you and the triangle mark is on the top-right position. Triangle mark Press the left load lever down with your thumb (A), move it to the right until it is released from the retention tab (B) then gently lift the load lever (C). To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU. Load lever ASUS TS500-E8-PS4 V2...
  • Page 26 Press the right load lever with your thumb (D), move it to the left until it is released from the retention tab (E) then gently lift the load lever (F). Push the left load lever to slightly lift the load plate (G). Do not insert the load lever into the Edge of the load plate retention tab. Hold the edge then gently lift the load plate (H). Load plate Chapter 2: Hardware Information...
  • Page 27 Get the CPU. Triangle mark Align and position the CPU over the socket ensuring that the triangle mark on the CPU matches the triangle mark on the socket box. Install the CPU into the slot. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the CPU pins on the socket. Gently push the load plate just enough to let it sit on top of the CPU. Do not force to close the load plate as it may damage the CPU. ASUS TS500-E8-PS4 V2...
  • Page 28 10. Push down the right load lever (I) ensuring that the edge of the load plate is fixed and tucked securely under the lever (J) then insert the right load lever under the retention tab (K). The PnP cap pops out of the load plate when the right load lever is inserted into the retention tab. Keep the PnP cap. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the PnP cap on the LGA 2011-3 socket. PnP cap 11. Push down the left load lever (L) then Retention tab insert it under the retention tab (M). Chapter 2: Hardware Information...
  • Page 29 12. Apply some Thermal Interface Material to the exposed area of the CPU that the heatsink will be in contact with. • Ensure that the Thermal Interface Material is spread in an even thin layer. • Some heatsinks come with pre-applied Thermal Interface Material. If so, skip this step. The Thermal Interface Material is toxic and inedible. DO NOT eat it. If it gets into your eyes or touches your skin, wash it off immediately, and seek professional medical help. 13. Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1 / CPU_FAN2. DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector. ASUS TS500-E8-PS4 V2...

  • Page 30: Installing The Cpu Heatsink

    2.2.2 Installing the CPU heatsink To install the CPU heatsink: Place the CPU heatsink and fan on top of the installed CPU, ensuring that the four screws match the holes on the support plate. Twist each of the four screws with a Phillips (cross) screwdriver just enough to attach the CPU heatsink and fan to the motherboard. When the four screws are attached, tighten them one by one to completely secure the CPU heatsink and fan. Do not forget to connect the CPU heatsink and fan connector. Hardware monitoring errors can occur if you fail to plug this connector. Tighten the four heatsink screws in a diagonal sequence. Chapter 2: Hardware Information 2-10...

  • Page 31: System Memory

    System memory 2.3.1 Overview The motherboard comes with eight (8) Double Data Rate 4 (DDR4) Dual Inline Memory Modules (DIMM) sockets. The figure illustrates the location of the DDR4 DIMM sockets: ASUS TS500-E8-PS4 V2 2-11...

  • Page 32: Memory Configurations

    2.3.2 Memory Configurations You may install 4 GB, 8 GB, 16 GB, and 32 GB RDIMMs or 32 GB and 64 GB LR-DIMMs into the DIMM sockets using the memory configurations in this section. • Refer to ASUS Server AVL for the updated list of compatible DIMMs. • When installing DIMMs, always start from slot A1 (CPU1) and E1 (CPU2). • Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor. Single CPU configuration You can refer to the following recommended memory population for a single CPU configuration. Single CPU configuration (must be installed on CPU1) DIMM 1 DIMM √...

  • Page 33: Installing A Dimm On A Single Clip Dimm Socket

    Hold the DIMM at both ends then insert the DIMM into the socket. Apply force to both ends of the DIMM simultaneously until the retaining clip clicks into place and the DIMM is seated securely in place. Locked Retaining Clip Always insert the DIMM into the socket VERTICALLY to prevent DIMM notch damage. • To install two or more DIMMs, refer to the user guide bundled with the motherboard package. • Refer to the user guide for qualified vendor lists of the memory modules. 2.3.4 Removing a DIMM from a single clip DIMM socket Press the retaining clip outward to unlock the DIMM. Remove the DIMM from the socket. Support the DIMM lightly with your fingers when pressing the retaining clips. The DIMM might get damaged when it flips out with extra force. ASUS TS500-E8-PS4 V2 2-13...

  • Page 34: Front Panel Assembly

    Front panel assembly Before you can install a 5.25-inch drive, you should first remove the front panel assembly (front bezel and front panel cover). 2.4.1 Removing the front panel assembly To remove the front panel assembly: Locate the three hooked tabs on the chassis side rail. Shift the hooked tabs and take off the front bezel. 2.4.2 Reinstalling the front panel assembly To reinstall the front panel assembly: Hook the other side of the front panel assembly to the chassis. Swing the front panel assembly and snap it back into place. Chapter 2: Hardware Information 2-14...

  • Page 35: Inch Drives

    You must remove the front panel assembly before installing a 5.25-inch drive. 2.5.1 Installing a 5.25-inch drive Unscrew and remove the metal cover of the bay where you want to install the 5.25-inch drive. Insert the drive into the bay and slide the bay lock to the right until it clicks in place. Connect the SATA cable to the SATA connector on the back of the drive. Connect the 4-pin power connector from the power supply to the power connector on the back of the drive. ASUS TS500-E8-PS4 V2 2-15...

  • Page 36: Sata/Sas Hard Disk Drives

    SATA/SAS hard disk drives The hard disk drive module, including externally removable trays for mounting either SATA or SAS hard disk drives, allows you to access the drive trays by simply opening the front bezel. An HDD module cage comes with a SATA or SAS backplane. Take note of the type of HDD module cage you purchase before buying hard disks. 2.6.1 Removing the HDD module cage Disconnect all the cables from the SATA/SAS backplane on the HDD module cage. Level the HDD module cage latch counterclockwise. The HDD module cage will be pushed out of the chassis. Remove the HDD module cage. Chapter 2: Hardware Information 2-16...

  • Page 37: Installing The Hdd Module Cage

    2.6.2 Installing the HDD module cage Examine the chassis and ensure the bay space is free of wires and other obstructions. Level the HDD module cage latch counterclockwise. Insert the HDD module cage into the bay. When the HDD module cage is completely inserted, the cage latch will be pushed back clockwise. Lock the cage latch properly. Connect the appropriate cables to the SATA/SAS backplane on the HDD module cage. ASUS TS500-E8-PS4 V2 2-17...

  • Page 38: Installing A Hot-Swap Sata/Sas Hard Disk Drive

    2.6.3 Installing a hot-swap SATA/SAS hard disk drive Release a drive tray by pushing the spring lock to the right, and then pull the tray lever outward. The drive tray ejects slightly after you pull out the lever. Firmly hold the tray lever and pull the drive tray out of the bay. Take note of the drive tray holes. Each side has three holes to fit different types of hard disk drives. Use two screws on each side to secure the hard disk drive. Chapter 2: Hardware Information 2-18...
  • Page 39 Carefully insert the drive tray and push it all the way to the depth of the bay until just a small fraction of the tray edge protrudes. When installed, the SATA/SAS connector on the drive connects to the SATA/SAS interface on the backplane. Push the tray lever until it clicks, and secures the drive tray in place. The drive tray is correctly placed when its front edge aligns with the bay edge. Repeat steps 1 to 6 if you wish to install a second SATA/SAS drive. ASUS TS500-E8-PS4 V2 2-19...

  • Page 40: Removing The Backplane

    2.6.4 Removing the backplane DO NOT remove the backplane unless necessary! Remove all hot-swap HDD trays from the chassis. Disconnect all cables from the SATA/ SAS backplane. Loosen the four screws on the backplane. Firmly hold the backplane, and turn it in the direction of the arrow. Remove the backplane from the module. Chapter 2: Hardware Information 2-20...

  • Page 41: Expansion Cards

    Remove the side chassis cover. Lay the system on its side on a flat, stable surface. Push down the expansion card lock latch (A) and lift up the expansion card lock (B). Remove the metal slot cover (C) opposite the slot where you wish to install an expansion card. Align the card’s golden fingers with the slot, and then press firmly until the card is completely seated on the slot. Push the expansion card lock back to its original position. A light click indicates that the card is locked in place. When installing a graphics card on a PCIex16 slot, the PCIe slot right beside it does not function. ASUS TS500-E8-PS4 V2 2-21...

  • Page 42: Installing An Asus Pike Ii Card

    2.7.2 Installing an ASUS PIKE II card You can install an ASUS PIKE II card on the provided PCI-E slot onboard. To install an ASUS PIKE II card: Remove the default cable from the motherboard and the backplane. Remove the screw on the metal cover and then remove the metal cover. Put them aside for future use. Chapter 2: Hardware Information 2-22...
  • Page 43 Prepare your ASUS PIKE II card. Insert the expansion card into the PCI-E slot. Ensure that the golden fingers are totally inserted into the slot. Connect the mini-SAS HD cable to the ASUS PIKE II card. connect to ASUS PIKE II connector 1 ASUS TS500-E8-PS4 V2 2-23...

  • Page 44: Installing An M.2 Card

    Connect connector 1 on the ASUS PIKE II card to connector 1 on the backplane using the mini-SAS HD cable. connector 1 2.7.3 Installing an M.2 card To install an M.2 card: Locate the M.2 card connector on the motherboard. Remove the screw from the motherboard. Prepare the M.2 card. Align and insert the M.2 card into the M.2 connector on the motherboard. Secure the M.2 card to the motherboard using the screw removed in step 2. Chapter 2: Hardware Information...

  • Page 45: Cable Connections

    Cable connections • The bundled system cables are pre-connected before shipment. You do not need to disconnect these cables unless you will remove pre-installed components to install additional devices. • Refer to Chapter 4 for detailed information on the connectors. 2.8.1 Motherboard connections Standard cables connected to the motherboard 24-pin ATX power connector (from power supply to motherboard) 8-pin 12V power connector (from power supply to motherboard) System fan connector (from system fan to motherboard) SATA connector (system default: from motherboard to SATA/SAS backplane) SSATA connector (system default: from motherboard to SATA/SAS backplane) USB 3.0 connector (from motherboard to front I/O board) USB 2.0 connector (from motherboard to front I/O board) System auxiliary panel connector (from motherboard to front I/O board) System panel connector (from motherboard to front I/O board) ASUS TS500-E8-PS4 V2 2-25...

  • Page 46: Sata/Sas Backplane Cabling

    2.8.2 SATA/SAS backplane cabling The system comes with a pre-installed SATA/SAS backplane. The SATA/SAS backplane has four 22-pin SATA/SAS connectors to support Serial ATA hard disk drives and SAS hard disk drives. The backplane design incorporates a hot-swap feature to allow easy connection or removal of SATA/SAS hard disks. The LEDs on the backplane connect to the front panel LEDs to indicate HDD status. See section 1.7 LED information for details. Front side The front side of the SATA/SAS backplane faces the front panel when installed. This side includes four SATA/SAS connectors for the hot-swap drive trays. HDD1 HDD2 Drive status LEDs HDD3 HDD4 Each SATA/SAS connector is labeled (HDD1, HDD1 HDD2, HDD3, HDD4) so you can easily determine their counterpart connectors at the back side of the backplane. Refer to the table for reference. HDD Device Front side connector Back side connector HDD 1 HDD1 CON1 HDD 2 HDD2 CON2...
  • Page 47 Back side The back side of the SATA/SAS backplane faces the rear panel when installed. This side includes the power connectors and SATA/SAS interfaces for the motherboard Serial ATA connectors or the SAS card. PWR1 MSAS_HD1 BPSMB1 Connectors Description Connects to SATA SGPIO1 connector on the motherboard or MSAS_HD1 SATA/SAS connectors on the ASUS PIKE II card BPSMB1 Connects to AUX_PANEL1 connector on the motherboard PWR1 Connects to 4-pin plug of the power supply ASUS TS500-E8-PS4 V2 2-27...

  • Page 48: Removable Components

    Removable components You may need to remove previously installed system components when installing or removing system devices, or when you need to replace defective components. This section tells how to remove the following components: System fans (front and rear) HDD cage kit (Optional) Chassis footpads 2.9.1 System fan To remove the front system fan: Remove the side cover.

  • Page 49: Upgrading Hdd Cage Kit (Optional)

    Insert the HDD module cage into the bay. When the HDD module cage is completely inserted, the cage latch will be pushed back clockwise. Lock the cage latch properly. Connect one of the power cables from the PSU to the power connector on the backplane. Remove the cable from the BPSMB1 connector of the upper backplane. Connect the cable removed in step 7 to the bundled 2-in-1 BPSMB cable. 2-in-1 BPSMB cable Connect the other end of the 2-in-1 BPSMB cable to the BPSMB1 connectors on the upper and lower backplane. ASUS TS500-E8-PS4 V2 2-29...
  • Page 50 To connect the backplane to the motherboard: Connect the mini-SAS HD cable to the lower backplane. Locate the cables labeled P0 and P1 on the other end of the mini- SAS HD cable from the lower backplane. Connect P0 and P1 cables to the motherboard. P4 cable from upper backplane Locate the two cables labeled P4 on the other end of the mini-SAS HD cables from both the upper and lower backplanes. Connect the bundled 2-in-1 SGPIO cable to the P4 cables. 2-in-1 SGPIO cable P4 cable from lower backplane Chapter 2: Hardware Information 2-30...
  • Page 51 To connect the backplane to ASUS PIKE II card (optional) on the motherboard: Connect the mini-SAS HD cable to the lower backplane. Connect the mini-SAS HD cable to the ASUS PIKE II card. ASUS TS500-E8-PS4 V2 2-31...

  • Page 52: Chassis Footpads

    2.9.3 Chassis footpads The barebone server system is shipped with four footpads attached to the bottom of the chassis for stability. You need to remove these footpads if you wish to install the system to a rack. Refer to Chapter 3: Installation Options of this user guide, and to the “Rackmount Kit” user guide for instructions. To remove the footpads: Lay the system chassis on its side. Remove the footpad by rotating it counterclockwise with a Phillips (cross) screwdriver. Repeat step 1 and 2 to remove the other three footpads. Chapter 2: Hardware Information 2-32...

  • Page 53: Chapter 3: Installation Options

    Chapter 3: Installation Options Installation Options This chapter describes how to install the optional components and devices into the barebone server.

  • Page 54: Preparing The System For Rack Mounting

    Preparing the system for rack mounting • The items required for the optional configurations described in this chapter are not included in the standard barebone system package. These items are purchased separately. • We recommend that you allot at least 1U space above the server system to ensure optimal thermal performance. 3.1.1 Removing the footpads Refer to section 2.9.3 Chassis footpads for instructions on removing the footpads. 3.1.2 Removing the top cover Unscrew and slide the top cover toward...

  • Page 55: Attaching The Inner Rail To The Server

    Repeat the previous steps to secure the other inner rail to the bottom of the chassis with screws. Use three screws to secure the side hooks to both rails. ASUS TS500-E8-PS4 V2...

  • Page 56: Attaching The Rails To The Rack

    Attaching the rails to the rack To attach the rails to the rack: Select one unit of space (1U) on the rack where you wish to install the server. 1U space Drive in two screws on the rack rails. Align the front end holes of a rack rail pair to the 1U space.

  • Page 57: Mounting The Server To The Rack

    Mounting the server to the rack To mount the server to the rack: Align the server rails with the rack rails. Press the lock on side of the rail and slide the server into the rack. Push the server all the way into the rack. When the server is fully slided into the rack, secure both sides using screws. ASUS TS500-E8-PS4 V2...
  • Page 58 Chapter 3: Installation Options...

  • Page 59: Chapter 4: Motherboard Information

    Chapter 4: Motherboard Information Motherboard Information This chapter includes the motherboard layout and brief descriptions of the jumpers and internal connectors.

  • Page 60: Motherboard Layout

    Motherboard layout Z10PA-D8 Chapter 4: Motherboard Information...
  • Page 61 Z10PA-D8C ASUS TS500-E8-PS4 V2...
  • Page 62 Layout contents Slots/Sockets Page 1. CPU sockets 2. DDR4 sockets 2-11 Jumpers Page 1. Clear RTC RAM (3-pin CLRTC1) 2. VGA controller setting (3-pin VGA_SW1) 3. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4. ME firmware force recovery setting (3-pin ME_RCVR1) 5. DDR4 thermal event setting (3-pin DIMMTRIP1) 6. RAID configuration utility selection (3-pin RAID_SEL1) 7. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) Internal connectors Page 1. S erial ATA 6.0 Gbps connectors (7-pin SATA1-6 [Light Blue];...

  • Page 63: Jumpers

    CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS which include system setup information such as system passwords. To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Move the jumper cap from the default pins 1–2 to pins 2–3. Keep the cap on pins 2–3 for about 5 to 10 seconds, then move the cap back to pins 1–2. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. DO NOT remove the cap on CLRTC jumper default position except when clearing the RTC RAM. Removing the cap will cause system boot failure! If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery. ASUS TS500-E8-PS4 V2...

  • Page 64: Vga Controller Setting (3-Pin Vga_Sw1)

    VGA controller setting (3-pin VGA_SW1) This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature. LAN controller setting (3-pin LAN_SW1, LAN_SW2) These jumpers allow you to enable or disable the onboard LAN_SW1 or LAN_SW2. Set to pins 1–2 to activate the Gigabit LAN feature. Chapter 4: Motherboard Information...

  • Page 65: Me Firmware Force Recovery Setting (3-Pin Me_Rcvr1)

    ME firmware force recovery setting (3-pin ME_RCVR1) ® This jumper allows you to force Intel Management Engine (ME) boot from recovery mode when ME becomes corrupted. DDR4 thermal event setting (3-pin DIMMTRIP1) This jumper allows you to enable or disable DDR4 DIMM thermal sensing event pin. ASUS TS500-E8-PS4 V2...

  • Page 66: Raid Configuration Utility Selection (3-Pin Raid_Sel1)

    RAID configuration utility selection (3-pin RAID_SEL1) This jumper allows you to select the RAID configuration utility to use when you create disk arrays. Place the jumper caps over pins 1–2 to use the third party software LSI MegaRAID software RAID Configuration Utility; otherwise, place the jumper caps to ® pins 2–3 to use the Intel Rapid Storage Technology enterprise SATA Option ROM Utility. The RAID configuration utility selection is available to Z10PA-D8 SKU only. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) This jumper allows you to select PSU PMBus version. Set to pins 1–2 for PMBus, set to pins 2–3 for others. Chapter 4: Motherboard Information...

  • Page 67: Internal Connectors

    Serial ATA 6.0 Gbps connectors (7-pin SATA1-6 [Light Blue]; 7-pin SSATA1-3 [Gray], SSATA4 [Light Gray]) ® Supported by the Intel 612 Series chipset, this connector is for the Serial ATA signal cables for Serial ATA hard disk drives that allows up to 6 Gbps of data transfer rate. If you install Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 10, or RAID 5 configuration. • The actual data transfer rate depends on the speed of Serial ATA hard disks installed. • The SSATA4 [Light Gray] will be automatically turned off if the M.2 connector (NGFF) is occupied. ASUS TS500-E8-PS4 V2...

  • Page 68: Ngff) Connector (Ngff1)

    M.2 (NGFF) connector (NGFF1) This connector allows you to install an M.2 device. This connector supports type 2242 devices on both PCI-E and SATA interface. The M.2 (NGFF) device is purchased separately. Power Supply SMBus connector (5-pin PSUSMB1) This connector allows you to connect SMBus (System Management Bus) to the PSU (power supply unit) to read PSU information. Devices communicate with an SMBus host and/or other SMBus devices using the SMBus interface. Power supply is required to meet PMBus specification and customized BMC FW may be needed. Please contact ASUS if your need further support. This connector functions only when you install the ASUS ASMB8. 4-10 Chapter 4: Motherboard Information...

  • Page 69: Usb 2.0 Connector (10-1 Pin Usb34)

    USB 2.0 connector (10-1 pin USB34) These connectors are for USB 2.0 ports. Connect the USB module cables to connectors USB34. These USB connectors comply with USB 2.0 specification that supports up to 480 Mb/s connection speed. USB 3.0 connector (20-1 pin USB3_34) This connector allows you to connect a USB 3.0 module for additional USB 3.0 front or rear panel ports. With an installed USB 3.0 module, you can enjoy all the benefits of USB 3.0 including faster data transfer speeds of up to 5Gbps, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. ASUS TS500-E8-PS4 V2 4-11...

  • Page 70: Cpu, Front, And Rear Fan Connectors

    CPU, front, and rear fan connectors (4-pin CPU_FAN1-2, FRNT_FAN1-4, REAR_FAN1-2) The fan connectors support cooling fans. Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. • These are not jumpers! DO NOT place jumper caps on the fan connectors! • All fans feature the ASUS Smart Fan technology. 4-12 Chapter 4: Motherboard Information...

  • Page 71: Serial Port Connector (10-1 Pin Com1)

    Serial port connector (10-1 pin COM1) This connector is for the serial COM port. Connect the serial port module cable to one of these connectors, then install the module to a slot opening at the back of the system chassis. Trusted Platform Module connector (20-1 pin TPM1) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. ASUS TS500-E8-PS4 V2 4-13...

  • Page 72: Atx Power Connectors (24-Pin Eatxpwr1, 8-Pin Eatx12V1-2)

    EATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1-2) These connectors are for the SSI or ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • DO NOT forget to connect the 24+8-pin power plugs when using 85W or below CPU; otherwise, the system will not boot up. • DO NOT forget to connect the 24+8+8-pin power plugs when using 105W or above CPU; otherwise, the system will not boot up. • Use of a PSU with a higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • Ensure that your power supply unit (PSU) can provide at least the minimum power required by your system. Minimum requirement of ATX power supply 1) 500W 2) All+12V output > 20A. 4-14 Chapter 4: Motherboard Information...

  • Page 73: System Panel Connector (20-1 Pin Panel1)

    Hard disk drive activity LED (2-pin HDD LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HD LED lights up or flashes when data is read from or written to the HDD. Power button/soft-off button (2-pin PWRSW) This connector is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the BIOS settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF. Reset button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. ASUS TS500-E8-PS4 V2 4-15...

  • Page 74: Auxiliary Panel Connector (20-2 Pin Aux_Panel1)

    Auxiliary panel connector (20-2 pin AUX_PANEL1) This connector is for additional front panel features including front panel SMB, locator LED and switch, and LAN LEDs. Front panel SMB (10-2 pin FPSMB) These connectors are for the front panel SMBus cable. LAN activity LED (2-pin LAN1_LINKACTLED, LAN2_LINKACTLED) These connectors are for Gigabit LAN activity LEDs on the front panel. Locator LED (2-pin LOCATORLED1, LOCATORLED2) These connectors are for the locator LED1 and LED2 on the front panel. Connect the Locator LED cables to these 2-pin connectors. The LEDs will light up when the Locator button is pressed.

  • Page 75: Hard Disk Activity Led Connector (4-Pin Hdled1)

    Hard disk activity LED connector (4-pin HDLED1) This LED connector is for the storage add-on card cable connected to the SATA or SAS add-on card. The read or write activities of any device connected to the SATA or SAS add-on card causes the front panel LED to light up. Chassis Intrusion (2-pin INTRUSION1) These leads are for the intrusion detection feature for chassis with intrusion sensor or microswitch. When you remove any chassis component, the sensor triggers and sends a high level signal to these leads to record a chassis intrusion event. The default setting is short CHASSIS# and GND pin by jumper cap to disable the function. ASUS TS500-E8-PS4 V2 4-17...

  • Page 76: Onboard Leds

    Standby Power LED (SB_PWR1) The motherboard comes with a standby power LED. The green LED lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. Baseboard Management Controller LED (BMC_LED1) The green heartbeat LED blinks per second to indicate that the ASMB8 is working normally. • The heartbeat LED functions only when you install the ASUS ASMB8. • The Baseboard Management Controller is available to Z10PA-D8 SKU only. 4-18 Chapter 4: Motherboard Information...

  • Page 77: Cpu Warning Led (Err_Cpu1-2)

    CPU Warning LED (ERR_CPU1-2) The CPU warning LEDs light up to indicate failure on either CPU1, CPU2, or both. CATT LED (CATTERR_LED1) The CATT LED indicates that the system has experienced a fatal or catastrophic error and cannot continue to operate. ASUS TS500-E8-PS4 V2 4-19...

  • Page 78: Q-Code Leds (Led1)

    Q-Code LEDs (LED1) The Q-Code LED provides a 2-digit display that shows the status of your system. Refer to the Q-Code table of this user guide for more information about the 2-digit codes. 4-20 Chapter 4: Motherboard Information...
  • Page 79 Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. Done MRC Progress Other config. After RC end Progress Memory already installed. Progress CPU Init. Progress CPU Init. Progress CPU Init. Progress DXE Initial Program Load(IPL) (continued on the next page) ASUS TS500-E8-PS4 V2 4-21...
  • Page 80 Q-Code table Action PHASE POST CODE TYPE DESCRIPTION Progress DXE Core Started Progress DXE NVRAM Init. Progress SB run-time init. Progress DXE CPU Init Progress NB Init. DXE(Driver Progress NB Init. Execution Progress NB Init. Environment) phase Progress SB Init. Progress SB Init. Progress SB Init. Progress ACPI Init. Progress CSM Init. Progress BDS started Progress Connect device event Progress PCI Bus Enumeration.

  • Page 81: Chapter 5: Bios Setup

    Chapter 5: BIOS Setup BIOS Setup This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

  • Page 82: Managing And Updating Your Bios

    5.1.1 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using a USB flash drive that contains the updated BIOS file.

  • Page 83: Asus Ez Flash Utility

    5.1.2 ASUS EZ Flash Utility The ASUS EZ Flash Utility feature allows you to update the BIOS without having to use a DOS-based utility. Before you start using this utility, download the latest BIOS from the ASUS website at www.asus.com.

  • Page 84: Bupdater Utility

    Updating the BIOS file To update the BIOS file using the BUPDATER utility: Visit the ASUS website at www.asus.com and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable USB flash disk drive. Copy the BUPDATER utility (BUPDATER.exe) from the ASUS support website at www.asus.com/support to the bootable USB flash disk drive you created earlier.
  • Page 85 The utility verifies the file, then starts updating the BIOS file. ASUS Tek. EzFlash Utility Current Platform New Platform Platform : Z10PA-08 Platform : Z10PA-08 Version : 0301 Version : 0301 Build date: 05/13/2014 Build date: 05/13/2014 Start Programming Flash.

  • Page 86: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. Chapter 5: BIOS Setup...

  • Page 87: Bios Menu Screen

    Tool For configuring options for special functions Exit For selecting the exit options To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. ASUS TS500-E8-PS4 V2...

  • Page 88: Menu Items

    5.2.3 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Event Logs, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items.

  • Page 89: Main Menu

    5.3.1 System Date [Day xx/xx/xxxx] Allows you to set the system date. 5.3.2 System Time [xx:xx:xx] Allows you to set the system time. ASUS TS500-E8-PS4 V2...

  • Page 90: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 5-10 Chapter 5: BIOS Setup...

  • Page 91: Acpi Settings

    Configuration options: [Disabled] [Enabled] This option may be not effective with some OS. 5.4.2 Smart Settings SMART Self Test [Disabled] Allows you to run SMART Self Test on all HDDs during POST. Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-11...

  • Page 92: Nct6779D Super Io Configuration

    5.4.3 NCT6779D Super IO Configuration Serial Port 1 / Serial Port 2 Configuration Allows you to set the parameters of Serial Port 1/ Serial Port 2. Serial Port [Enabled] Allows you to enable or disable Serial Port. Configuration options: [Disabled] [Enabled] Change Settings [Auto] Allows you to choose the setting for Super IO device.

  • Page 93: Intel Lan I210 Io Configuration

    Configuration options: [Disabled] [Enabled] The following items appear only when Intel LAN I210 LAN1 / LAN2 Enable is set to [Enabled]. LAN1/ LAN2 Option ROM Support [Enabled] Allows you to load the Intel LAN ROM. Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-13...

  • Page 94: Serial Port Console Redirection

    5.4.5 Serial Port Console Redirection COM1/COM2 Console Redirection [Enabled] Allows you to enable or disable the console redirection feature. Configuration options: [Disabled] [Enabled] The following item appears only when you set Console Redirection to [Enabled]. Console Redirection Settings This item becomes configurable only when you enable the Console Redirection item. The settings specify how the host computer and the remote computer (which the user is using) will exchange data.
  • Page 95 With this mode enabled only text will be sent. This is to capture Terminal data. Configuration options: [Disabled] [Enabled] Legacy OS Redirection Resolution [80x24] This allows you to set the number of rows and columns supported on the Legacy OS. Configuration options: [80x24] [80x25] ASUS TS500-E8-PS4 V2 5-15...
  • Page 96 Putty Keypad [VT100] This allows you to select the FunctionKey and Keypad on Putty. Configuration options: [VT100] [LINUX] [XTERMR6] [SCO] [ESCN] [VT400] Redirection After BIOS POST [Bootloader] This setting allows you to specify if Bootloader is selected than Legacy console redirection.

  • Page 97: Apm

    Enables the PCIE devices to generate a wake event. Power On By RTC [Disabled] [Disabled] Disables RTC to generate a wake event. [Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and Hour/Minute/ Second will become user-configurable with set values. ASUS TS500-E8-PS4 V2 5-17...

  • Page 98: Pci Subsystem Settings

    5.4.7 PCI Subsystem Settings Allows you to configure PCI, PCI-X, and PCI Express Settings. Load RT32 Image [Enabled] Allows you to enable or disable RT32 Image Loading. Configuration options: [Disabled] [Enabled] Above 4G Decoding [Disabled] Allows you to enable or disable 64-bit capable devices to be decoded in above 4G address space.

  • Page 99: Network Stack Configuration

    Enables or disables the Ipv6 PXE Boot Support. If disabled, Ipv6 PXE boot option will not be created. Configuration options: [Disabled] [Enabled] PXE boot wait time [0] Wait time to press ESC key to abort the PXE boot. Media detect time [0] Wait time (in seconds) to detect media. ASUS TS500-E8-PS4 V2 5-19...

  • Page 100: Csm Configuration

    5.4.9 CSM Configuration CSM Support [Enabled] This option allows you to enable or disable CSM Support. Configuration options: [Disabled] [Enabled] GateA20 Active [Upon Request] This allows you to set the GA20 option. Configuration options: [Upon Request] [Always] Option ROM Messages [Force BIOS] This allows you to set the display mode for option ROM.

  • Page 101: Trusted Computing

    5.4.10 Trusted Computing Configuration Security Device Support [Disabled] Allows you to enable or disable the BIOS support for security device. Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-21...

  • Page 102: Usb Configuration

    5.4.11 USB Configuration Legacy USB Support [Enabled] Allows you to enable or disable Legacy USB device support. Configuration options: [Enabled] [Disabled] [Auto] XHCI Hand-off [Enabled] This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. Configuration options: [Disabled] [Enabled] EHCI Hand-off [Disabled] This is a workaround for OSes without EHCI hand-off support.

  • Page 103: Iscsi Configuration

    Configuration options: [Auto] [Manual] Mass Storage Devices Generic 8.07 [Auto] Allows you to select the mass storage device emulation type. Configuration options: [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] 5.4.12 iSCSI Configuration Allows you to configure the iSCSi parameters. ASUS TS500-E8-PS4 V2 5-23...

  • Page 104: Intelrcsetup Menu

    IntelRCSetup menu The IntelRCSetup menu items allow you to change the processor and chipset settings. 5-24 Chapter 5: BIOS Setup...

  • Page 105: Processor Configuration

    Configuration options: [Disabled] [Enabled] Enable Intel TXT Support [Disabled] Forces the XD feature log to always return 0 when disabled. Configuration options: [Disabled] [Enabled] VMX [Enabled] Enables the Vanderpool Technology. Takes effect after reboot. Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-25...
  • Page 106 Enable SMX [Disabled] Enables the Safer Mode Extensions. Configuration options: [Disabled] [Enabled] Hardware Prefetcher [Enabled] This item allows you to turn on/off the mid level cache(L2) streamer prefetcher. Configuration options: [Disabled] [Enabled] Adjacent Cache Prefetch [Enabled] This item allows you to turn on/off prefetching of adjacent cache lines. Configuration options: [Disabled] [Enabled] DCU Streamer Prefetcher [Enabled] This item allows you to enable or disable prefetcher of next L1 data line.

  • Page 107: Advanced Power Management Configuration

    Allows your system to select from BIOS or operating system to choose enable energy performance bias tuning. Configuration options: [Disabled] [Enabled] Energy Performance Bias setting [Balanced Performance] Allows you to set the Energy Performance Bias which overrides the OS setting. Configuration options: [Performance] [Balanced Performance] [Balanced Power] [Power] ASUS TS500-E8-PS4 V2 5-27...

  • Page 108: Common Refcode Configuration

    Power/Performance Switch [Enabled] Allows you to switch between Power or Performance. Configuration options: [Disabled] [Enabled] Workload Configuration [Balanced] Optimization for the workload characterization. Configuration options: [Balanced] [I/O sensitive] Averaging Time Window [23] This is used to control the effective window of the average for CO and PO time. PO TotalTimeThreshold Low [35] The HW switching mechanism disables the performance setting (0) when the total PO time is less than this threshold.

  • Page 109: Qpi Configuration

    This item allows you for selecting the QPI link frequency. Configuration options: [Auto] [6.4 GT/s] [8.0 GT/s] [9.6 GT/s] QPI Link0p Enable [Enable] Configuration options: [Disable] [Enable] QPI Link1 Enable [Enable] Configuration options: [Disable] [Enable] QPI Status ASUS TS500-E8-PS4 V2 5-29...

  • Page 110: Memory Configuration

    5.5.5 Memory Configuration Enforce POR [Auto] Allows you to enforce POR restrictions for DDR4 frequency adn voltage programming. Configuration options: [Auto] [Enforce POR] [Disabled] [Enforce Stretch Goals] Memory Frequency [Auto] Allows you to select the memory frequency setting. Configuration options: [Auto] [1333] [1600] [1866] [2133] Halt on mem Training Error [Enabled] Allows you to enable or disable halt on mem Training Error.
  • Page 111 Configuration options: [Auto] [Driven] [Tri-State] [Pulled Low] Pulled High] MDLL Off [Auto] Allows you to shutdown MDLL during SR when enabled. Configuration options: [Auto] [Disabled] [Enabled] MEMHOT Throttling Mode [Input-only] Allows you to shutdown MDLL during SR when enabled. Configuration options: [Disabled] [Input-only] [Output-only] ASUS TS500-E8-PS4 V2 5-31...
  • Page 112 Mem Electrical Throttling [Disabled] Allows you to configure Memory Electical throttling. Configuration options: [Disabled] [Enabled] [Auto] Memory Map Channel Interleaving [Auto] Select different channel interleaving setting. Configuration options: [Auto] [1-way Interleave] [2-way Interleave] [3-way Interleave] [4-way Interleave] Rank Interleaving [Auto] Select different rank interleaving setting.

  • Page 113: Iio Configuration

    Use special table for TX_EQ and vendor specific cards. Configuration options: [Disabled] [Enabled] PCI-E ASPM Support (Global) [L1 Only] This option enables or disables the ASPM support for all downstream devices. Configuration options: [Disabled] [L1 Only] ASUS TS500-E8-PS4 V2 5-33...

  • Page 114: Pch Configuration

    5.5.7 PCH Configuration PCH Devices DeepSx Power Policies [Disabled] Allows you to configure the DeepSx Mode configuration. Configuration options: [Disabled] [Enabled in S5] [Enabled in S4 and S5] PCI Express Configuration PCH DMI ASPM [Enabled] Allows you to configure the PCH DMI ASPM. Configuration options: [Disabled] [Enabled] PCI Express Root Port 1 to Port 8 Allows you to configure the PCI Express Root port settings.
  • Page 115 Allows you to enable or disable the Suport Aggressive Link Power (SALP) Management. Configuration options: [Disabled] [Enabled] SATA Port 1 – 4 Port 1 / Port 2 / Port 3 / Port 4 Allows you to enable or disable the SATA port. Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-35...
  • Page 116 PCH SATA Configuration SATA Controller [Enabled] Allows you to enable or disable the SATA Controller. Configuration options: [Disabled] [Enabled] Configure SATA as [AHCI] Allows you to identify the SATA port connected to Solid State Drive or Hard Disk Drive. Configuration options: [IDE] [AHCI] [RAID] Support Aggressive Link Power Management [Enabled] Allows you to enable or disable the Suport Aggressive Link Power (SALP) Management.
  • Page 117 USB Port #1 / #2 / #3 / #4 / #5 / #6 / #7 / #8 [Enabled] Configuration options: [Disabled] [Enabled] USB 3.0 Port #1 / #2 / #3 / #4 [Enabled] Configuration options: [Disabled] [Enabled] ASUS TS500-E8-PS4 V2 5-37...

  • Page 118: Miscellaneous Configuration

    Platform Thermal Configuration PCH Thermal Device [Auto] Allows you to enable or disable the PCH Thermal Device (D31:F6). Configuration options: [Auto] [Disabled] [Enabled] Alert Enable Lock [Disabled] Allows you to lock all Alert Enable settings. Configuration options: [Disabled] [Enabled] 5.5.8 Miscellaneous Configuration Active Video [Offboard Device] Allows you to select the video type.

  • Page 119: Runtime Error Logging Support

    This item allows you to start a BIOS timer which can only be shut off by Intel Management Software after the OS loads. Configuration options: [Disabled] [Enabled] The following items is configurable only when the OS Watchdog Timer is set to [Enabled]. ASUS TS500-E8-PS4 V2 5-39...
  • Page 120 OS Wtd Timer Timeout [10 minutes] Allows you to configure the length fo the OS Boot Watchdog Timer. Configuration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes] OS Wtd Timer Policy [Reset] This item allows you to configure how the system should respond if the OS Boot Watch Timer expires.
  • Page 121 BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Configuration options: [Previous State] [Static] [DynamicBmcDhcp] [DynamicBmcNonDhcp] View System Event Log This item allows you to view the system event log records. ASUS TS500-E8-PS4 V2 5-41...
  • Page 122 IPv6 BMC Network Configuration This item allows you to configure the parameter settings of IPv6 BMC network. IPv6 Display Full Field [Enable] Displays the full or brief IPv6 Field. Configuration options: [Disable] [Enable] IPv6 Display Full Formula [Enable] Displays the full or brief IPv6 Formula. Configuration options: [Disable] [Enable] IPv6 Display Letter Case [Upper Case] Displays the uppercase or lowercase letters of the alphabet.
  • Page 123 Allows you to enter IPv6 BMC LAN DNS Settings. IPv6 BMC LAN Link IP Address Allows you to enter IPv6 BMC LAN Link IP address. IPv6 BMC LAN Link IP Prefix Length Allows you to input IPv6 BMC Lan Link IP Prefix Length. ASUS TS500-E8-PS4 V2 5-43...

  • Page 124: Event Logs Menu

    Event Logs menu The Event Logs menu items allow you to change the event log settings and view the system event logs. 5.7.1 Change Smbios Event Log Settings Press <Enter> to change the Smbios Event Log configuration. All values changed here do not take effect until computer is restarted. Enabling/Disabling Options Smbios Event Log [Enabled] Change this to enable or disable all features of Smbios Event Logging during boot.

  • Page 125: View Smbios Event Log

    Convert OEM Codes [Disabled] Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may be translated). Configuration options: [Disabled] [Enabled] 5.7.2 View Smbios Event Log Press <Enter> to view all smbios event logs. ASUS TS500-E8-PS4 V2 5-45...

  • Page 126: Monitor Menu

    CPU FAN1&2 FRNT FAN1 mode [Generic Mode] Allows you to configure the ASUS Smart Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode] [Manual Mode] Duty % [50] This item appears only when CPU FAN1&2 FRNT FAN1 mode is set to [Manual Mode].

  • Page 127: Security Menu

    From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted. To clear the administrator password, follow the same steps as in changing an administrator password, but press <Enter> when prompted to create/confirm the password. ASUS TS500-E8-PS4 V2 5-47...
  • Page 128 User Password To set a user password: Select the User Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change a user password: Select the User Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>.
  • Page 129 No. Platform Key (PK) / Key Exchange Key (KEK) / Authorized Signatures (DB) / Authorized TimeStamps (DBT) / Forbidden Signatures (DBX) Configuration options: [Delete] [Set New] [Append] ASUS TS500-E8-PS4 V2 5-49...

  • Page 130: Boot Menu

    5.10 Boot menu The Boot menu items allow you to change the system boot options. Setup Prompt Timeout [xx] Use the <+> and <-> keys to adjust the number of seconds to wait for setup activation key. Bootup NumLock State [On] Allows you to select the power-on state for the NumLock.

  • Page 131: Tool Menu

    The Tool menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu. ASUS EZ Flash Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>. Refer to the ASUS EZ Flash Utility section for details. ASUS TS500-E8-PS4 V2...

  • Page 132: Exit Menu

    5.12 Exit menu The Exit menu items allow you to save or discard your changes to the BIOS items. Pressing <Esc> does not immediately exit this menu. Select one of the options from this menu or <F10> from the legend bar to exit. Save Changes &...
  • Page 133 Click an item to start booting from the selected device. Launch EFI Shell from filesystem device Attempts to launch EFI Shell application (shellx64.efi) from one of the available filesystem devices. ASUS TS500-E8-PS4 V2 5-53...
  • Page 134 5-54 Chapter 5: BIOS Setup...

  • Page 135: Chapter 6: Raid Configuration

    Chapter 6: RAID Configuration RAID Configuration This chapter provides instructions for setting up, creating, and configuring RAID sets using the available utilities.

  • Page 136: Setting Up Raid

    Setting up RAID The motherboard supports the following SATA RAID solutions: • LSI MegaRAID software RAID Configuration Utility with RAID 0, RAID 1, and RAID 10 support (for both Linux and Windows OS). ® • Intel Rapid Storage Technology enterprise Option ROM Utility with RAID 0, RAID 1, RAID 10, and RAID 5 support (for Windows OS only).

  • Page 137: Installing Hard Disk Drives

    Rapid Storage Technology if you installed Serial ATA hard disk drives on the Serial ATA connectors supported by the Intel® C612 chipset. Refer to the succeeding section for details on how to use the RAID configuration utility. ASUS TS500-E8-PS4 V2...

  • Page 138: Lsi Software Raid Configuration Utility (Z10Pa-D8 Only)

    LSI Software RAID Configuration Utility (Z10PA-D8 only) The LSI MegaRAID software RAID configuration utility allows you to create RAID 0, RAID 1, or RAID 10 set(s) from SATA hard disk drives connected to the SATA connectors supported by the motherboard southbridge chip. To enter the LSI MegaRAID software RAID configuration utility: Turn on the system after installing all the SATA hard disk drives.

  • Page 139: Creating A Raid Set

    Configure View/Add Configuration Initialize Clear Configuration Objects Select Boot Drive Rebuild Check Consistency Defines Physical Arrays. An Array Will Automatically Become A VD Use Cursor Keys to Navigate Between Items And Press Enter To Select An Option ASUS TS500-E8-PS4 V2...
  • Page 140 The ARRAY SELECTION MENU displays the available drives connected to the SATA ports. Use the up/down arrow keys to select the drives you want to include in the RAID set, and then press <Space>. When selected, the drive indicator changes from READY to ONLIN A[X]-[Y], where X is the array number, and Y is the drive number.
  • Page 141 RAID 0 READY Units= MB RAID 1 Size = 152146MB = OFF = On Accept SPAN = NO Choose RAID Level For This VD Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option ASUS TS500-E8-PS4 V2...
  • Page 142 Select Units from the Virtual Drive sub-menu, and then press <Enter>. Select the units for virtual drive size from the menu, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Virtual Drive(s) Configured Easy Configuration - ARRAY SELECTION MENU RAID Size...
  • Page 143 Initialize Select Boot Drive Objects Virtual Drive(s) Configured Rebuild Check Consistency RAID Size #Stripes StripSz Status 148.580GB 64KB ONLINE Select Yes Or No Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option ASUS TS500-E8-PS4 V2...
  • Page 144 Using New Configuration When a RAID set already exists, using the New Configuration command erases the existing RAID configuration data. If you do not want to delete the existing RAID set, use the View/Add Configuration command to view or create another RAID configuration. To create a RAID set using the New Configuration option: From the Management Menu, select Configure >...

  • Page 145: Adding Or Viewing A Raid Configuration

    The information of the selected hard disk drive is displayed at the bottom of the screen. Follow step 3 to 12 of section 6.2.1 Creating a RAID set: Using Easy Configuration to add a new RAID set. ASUS TS500-E8-PS4 V2 6-11...

  • Page 146: Initializing The Virtual Drives

    6.2.3 Initializing the virtual drives After creating the RAID set(s), you must initialize the virtual drives. You may initialize the virtual drives of a RAID set(s) using the Initialize or Objects command on the Management Menu. Using the Initialize command To initialize the virtual drive using the Initialize command: From the Management Menu, select Initialize, and then press <Enter>.
  • Page 147 Size #Stripes StripSz Status Management Menu Configure Init of VD Is In Process 148.580GB 64KB ONLINE Initialize VD 0 Initialization Complete. Press Esc.. Objects Rebuild Check Consistency 100% Completed Virtual Drives Virtual Drive 0 SPACE-(De)Select, F10-Initialize ASUS TS500-E8-PS4 V2 6-13...
  • Page 148 Using the Objects command To initialize the virtual drives using the Objects command: From the Management Menu, select Objects > Virtual Drive, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Objects Management Menu Adapter Configure Virtual Drive...
  • Page 149 Init Will Destroy Data On Selected VD(s) Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option A progress bar appears on screen. If desired, press <Esc> to abort initialization. When initialization is completed, press <Esc>. ASUS TS500-E8-PS4 V2 6-15...

  • Page 150: Rebuilding Failed Drives

    6.2.4 Rebuilding failed drives You can manually rebuild failed hard disk drives using the Rebuild command in the Management Menu. To rebuild a failed hard disk drive: From the Management Menu, select Rebuild, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Management Menu...
  • Page 151 FAIL A00-01 Rebuilding of Drive Will Take A Few Minutes. Start Rebuilding Drive (Y/N)? Check Consistency Port # 1 DISK 77247MB HDS72808PLA380 PF20A60A SPACE-(De)Select,F10-Start Rebuild,F2-Drive Information,F3-View Virtual Drives When rebuild is complete, press any key to continue. ASUS TS500-E8-PS4 V2 6-17...

  • Page 152: Checking The Drives For Data Consistency

    6.2.5 Checking the drives for data consistency You can check and verify the accuracy of data redundancy in the selected virtual drive. The utility can automatically detect and correct any differences in data redundancy depending on the selected option in the Objects > Adapter menu. The Check Consistency command is available only for virtual drives included in a RAID 1 or RAID 10 set.
  • Page 153 • Continue - Continues the consistency check. • Abort - Aborts the consistency check. When you restart checking, it continues from zero percent. When checking is complete, press any key to continue. ASUS TS500-E8-PS4 V2 6-19...
  • Page 154 Using the Objects command To check data consistency using the Objects command: From the Management Menu, select Objects, and then select Virtual Drive from the sub-menu. Use the arrow keys to select the virtual drive you want to check, and then press <Enter>.

  • Page 155: Deleting A Raid Configuration

    Objects Select Boot Drive Rebuild Check Consistency Clear Existing Configuration Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option The utility clears all the current array(s). Press any key to continue. ASUS TS500-E8-PS4 V2 6-21...

  • Page 156: Selecting The Boot Drive From A Raid Set

    6.2.7 Selecting the boot drive from a RAID set You must have created a new RAID configuration before you can select the boot drive from a RAID set. See section 6.2.1 Creating a RAID set: Using New Configuration for details. To select the boot drive from a RAID set: From the Management Menu, select Configure >...

  • Page 157: Enabling Writecache

    Disk WC = On Check Consistency Read Ahead = On Disk Write Cache Setting of VD Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option When finished, press any key to continue. ASUS TS500-E8-PS4 V2 6-23...

  • Page 158: Intel ® Rapid Storage Technology Enterprise

    ® Intel Rapid Storage Technology enterprise SATA/SSATA Option ROM Utility The Intel Rapid Storage Technology enterprise SATA/SSATA Option ROM utility allows you ® to create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 159: Creating A Raid Set

    ]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done Use the up/down arrow keys to move the selection bar then press <Space> to select a disk. A small triangle before the Port number marks the selected drive. Press <Enter> when you are done. ASUS TS500-E8-PS4 V2 6-25...
  • Page 160 Use the up/down arrow keys to select the stripe size for the RAID array (for RAID 0, 10 and 5 only) then press <Enter>. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB...

  • Page 161: Deleting A Raid Set

    <N> to return to the DELETE VOLUME menu. DELETE VOLUME VERIFICATION ALL DATA IN THE VOLUME WILL BE LOST! (This does not apply to Recovery volumes) Are you sure you want to delete volume “Volume0”? (Y/N): ASUS TS500-E8-PS4 V2 6-27...

  • Page 162: Resetting Disks To Non-Raid

    6.3.3 Resetting disks to Non-RAID Take caution before you reset a RAID volume hard disk drive to non-RAID. Resetting a RAID volume hard disk drive deletes all internal RAID structure on the drive. To reset a RAID set: From the utility main menu, select 3. Reset Disks to Non-RAID and press <Enter>. Press the up/down arrow keys to select the drive(s) or disks of the RAID set you want to reset, then press <Space>.

  • Page 163: Exiting The Intel ® Rapid Storage Technology Enterprise Sata/Ssata Option Rom Utility

    Select the port of destination disk for rebuilding (ESC to exit): Port Drive Model Serial # Size XXXXXXXXXXX XXXXXXXX XXX.GB ]-Previous/Next [ENTER]-Select [ESC]-Exit Select a destination disk with the same size as the original hard disk. ASUS TS500-E8-PS4 V2 6-29...
  • Page 164 The utility immediately starts rebuilding after the disk is selected. When done, the status of the degraded RAID volume is changed to “Rebuild”. Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.6.0.1023 Copyright(C) 2003-12 Intel Corporation. All Rights Reserved. MAIN MENU 1.

  • Page 165: Setting The Boot Array In The Bios Setup Utility

    Use up/down arrow keys to select the boot priority and press <Enter>. See the Boot menu section of Chapter 5 for more details. From the Exit menu, select Save Changes & Exit, then press <Enter>. When the confirmation window appears, select Yes, then press <Enter>. ASUS TS500-E8-PS4 V2 6-31...

  • Page 166: Intel ® Rapid Storage Technology Enterprise (Windows)

    ® Intel Rapid Storage Technology enterprise (Windows) ® The Intel Rapid Storage Technology enterprise allows you to create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 167: Creating A Raid Set

    Click Next. • If you do not want to keep the data on one of the selected disks, select NO when prompted. • If you want to Enable volume write-back cache or Initialize volume, click Advanced. ASUS TS500-E8-PS4 V2 6-33...
  • Page 168 Confirm the volume creation, then click Create Volume to continue. This process could take a while depending on the number and size of the disks. You can continue using other applications during this time. Wait until the process is completed, then click OK when prompted. You still need to partition your new volume using Windows Disk Management before adding any data.

  • Page 169: Changing A Volume Type

    RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB We recommend a lower stripe size for server systems, and a higher stripe size for multimedia computer systems used mainly for audio and video editing. ASUS TS500-E8-PS4 V2 6-35...

  • Page 170: Deleting A Volume

    6.4.3 Deleting a volume Be cautious when deleting a volume. You will lose all data on the hard disk drives. Before you proceed, ensure that you back up all your important data from your hard drives. To delete a volume: From the utility main menu, select the volume (exp.

  • Page 171: Preferences

    Allows you to set to show the notification area icon and show system information, warning, or errors here. E-Mail Preferences Allow you to set to sent e-mail of the following events: • Storage system information • Storage system warnings • Storage system errors ASUS TS500-E8-PS4 V2 6-37...
  • Page 172 6-38 Chapter 6: RAID Configuration...

  • Page 173: Chapter 7: Driver Installation

    Chapter 7: Driver Installation Driver Installation This chapter provides the instructions for installing the necessary drivers for different system components in both ® ® Linux and Windows Operating Systems.

  • Page 174: Raid Driver Installation

    RAID driver installation After creating the RAID sets for your server system, you are now ready to install an operating system to the independent hard disk drive or bootable array. This part provides the instructions on how to install the RAID controller drivers during OS installation. 7.1.1 Creating a RAID driver disk The system does not include a floppy drive.

  • Page 175: Installing The Raid Controller Driver

    Boot the computer using the Windows Server 2008 R2 OS installation disc. Follow the ® screen instructions to start installing Windows Server 2008 R2. When prompted to choose a type of installation, click Custom (advanced). Click Load Driver. ASUS TS500-E8-PS4 V2...
  • Page 176 A message appears, reminding you to insert the installation media containing the driver of the RAID controller driver. If you have only one optical drive installed in your system, eject the Windows OS installation disc and replace with the motherboard Support DVD into the optical drive.
  • Page 177 Enterprise RAID driver disk to the USB floppy disk drive, select ® OK, then press <Enter>. Insert Driver Disk Insert your driver disk into /dev/fd0 and press “OK” to continue. Back The drivers for the RAID card are installed to the system. ASUS TS500-E8-PS4 V2...
  • Page 178 When asked if you will load additional RAID controller drivers, select No, then press <Enter>. More Driver Disks? Do you wish to load any more driver disks? Follow the onscreen instructions to finish the OS installation. When the installation is completed, DO NOT click Reboot. Press <Ctrl> + <Alt> + <F2>...
  • Page 179 Boot the system from the Red Hat OS installation CD. Press <Tab> to edit options. While booting from DVD, press <ESC> to give the third party driver. Enter the following command at the boot: Linux dd blacklist=isci blacklist=ahci nodmraid, then press <ENTER>. ASUS TS500-E8-PS4 V2...
  • Page 180 Select Yes using the <Tab> key when asked if you have the driver disk, then press <Enter>. Main Menu Do you have a driver disk? You have multiple devices which could serve as source for a driver disk. Choose one you like to use and select OK, then press <Enter>.
  • Page 181 The drivers for the RAID card are installed to the system. When asked if you will load additional RAID controller drivers, select No, then press <Enter>. More Driver Disks? Do you wish to load any more driver disks? Follow the onscreen instructions to finish the OS installation. ASUS TS500-E8-PS4 V2...
  • Page 182 Preparing the Linux Driver Ensure that there is another computer with a Linux-based OS to create the RAID driver. When creating the RAID driver, you may refer to the examples below which uses a 64bit SUSE Linux system to create a 64bit RAID driver for SUSE11 sp1. Copy the image file into the Linux system.
  • Page 183 To install the LSI MegaRAID controller driver when installing SUSE Linux Enterprise Server OS: Boot the system from the SUSE OS installation CD. Use the arrow keys to select Installation from the Boot Options menu. Press <F6>, then select Yes from the menu. Press <Enter>. ASUS TS500-E8-PS4 V2 7-11...
  • Page 184 Use the USB drive to provide the third-party driver during the OS installation. Type the command brokenmodules=ahci in Boot Options field, and press <Enter>. When below screen appears, select the USB floppy disk drive (sda) as the driver update medium. Select OK, then press <Enter>. Please choose the Driver Update medium.

  • Page 185: Management Applications And Utilities Installation

    The contents of the support DVD are subject to change at any time without notice. Visit the ASUS website (www.asus.com) for the latest updates on software and utilities.

  • Page 186: Drivers Menu Tab

    7.3.1 Drivers menu tab The Drivers Menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. 7.3.2 Utilities menu tab The Utilities menu displays the software applications and utilities that the motherboard supports. 7-14 Chapter 7: Driver Installation...

  • Page 187: Makedisk Menu Tab

    Press the arrow down button in the lower part of the menu to view more items. 7.3.4 Manual menu The Manual menu provides the link to the Broadcom NetXtreme II Network Adapter user guide. You need an internet browser installed in your OS to view the User Guide. ASUS TS500-E8-PS4 V2 7-15...

  • Page 188: Contact Information Menu

    7.3.5 Contact information menu The Contact menu displays the ASUS contact information, e-mail addresses, and useful links if you need more information or technical support for your motherboard. 7-16 Chapter 7: Driver Installation...

  • Page 189: Intel ® Chipset Device Software Installation

    ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click the item Intel Chipset Device Software from the menu. The Intel Chipset Device Software window appears. Click Next to start installation. ® ASUS TS500-E8-PS4 V2 7-17...
  • Page 190 Select Yes to accept the terms of the License Agreement and continue the process. Read the Readme File Information and press Next to continue the installation. Toggle Yes, I want to restart the computer now and click Finish to complete the setup process.

  • Page 191: Installing The Intel ® I210 Gigabit Adapters Driver

    ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click Intel I350-AM1/I350-AM2/I210/X540-BT2 Gigabit Adapters Driver in the ® Drivers menu of the main screen to start the installation. Click Install Drivers and Software option to begin installation. ASUS TS500-E8-PS4 V2 7-19...
  • Page 192 Click Next when the Intel(R) Network Connections Install Wizard window appears. Tick I accept the terms in the license agreement and click Next to continue. From the Setup Options window, click Next to start the installation. By default, Intel(R) PROSet for Windows Device Manager and Windows PowerShell Module are ticked.
  • Page 193 Click Install to start the installation. When the installation is done, press Finish to complete the installation. ASUS TS500-E8-PS4 V2 7-21...

  • Page 194: Vga Driver Installation

    VGA driver installation This section provides the instructions on how to install the ASPEED Video Graphics Adapter (VGA) driver. You need to manually install the ASPEED VGA driver on a Windows operating system. ® To install the ASPEED VGA driver: Restart the computer, and then log on with Administrator privileges.
  • Page 195 Click Install to proceed with the installation. Click Finish to complete the installation. ASUS TS500-E8-PS4 V2 7-23...

  • Page 196: Intel ® Rapid Storage Technology Enterprise 4.0 Installation

    ® Intel Rapid Storage Technology enterprise 4.0 installation ® This section provides the instructions on how to install the Intel Rapid Storage Technology enterprise 4.0 on the system. ® You need to manually install the Intel Rapid Storage Technology enterprise 4.0 utility on a ®...
  • Page 197 Read the Warning message and click Next to continue. Read the License Agreement and click Yes to continue. Read the Readme File Information and click Next to continue. ASUS TS500-E8-PS4 V2 7-25...
  • Page 198 After completing the installation, click Next to complete the setup process. Select Yes, I want to restart my computer now and click Finish to restart your computer before using the program. 7-26 Chapter 7: Driver Installation...

  • Page 199: Appendix
