SUMAKE
Specification:
Free Speed
Blade
Motor
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
2" Air Circular Saw
W/72T Saw Blade
ST-CT142
3,500 r/min
72T
0.5HP
13 CFM (370 L/min)
10-1/4" (260mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.87lb (1.3kg)
Noise and Vibration:
Vibration
EN ISO 28927-4
Sound Pressure Level
Load:
3.7 m/s²
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
No load: 83 dB(A)
Sound power level
environment
No load: 94 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-CT142-S-2102A-D5F
Remark
wear ear
protector at
hearing!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-CT142
Summary of Contents for Sumake ST-CT142
- Page 1 3/8” (10 mm) dB(A) due to Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 2.87lb (1.3kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-CT142-S-2102A-D5F...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 2" AIR CIRCULAR SAW W/72T SAW BLADE Model/ Serial No.： ST-CT142 to which this declaration applies, complies with these normative documents: ... - Page 3 There is no user serviceable part inside this tool. Sumake is a manufacturer and exporter of air mechanism, and may cause trouble. So, install an Please send the tool to a qualified personnel or our tools since established.
-
Page 4: Parts List
ST-CT142 2" AIR CIRCULAR SAW W/72T SAW BLADE PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty CT140-01 Pan Head Screw CT142-28 Internal Gear CT140-02 Washer CT140-29 Spacer CT140-03 Washer CT140-30 Ball Bearing CT140-04 Guide Plug CT140-31 Front End Plate... - Page 5 CUTTER(SAW) Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 other parts of the body. 2. While using the tool, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during extended tasks which may help avoid discomfort and fatigue. 3.
- Page 8 the hazard, the risk of injury and the avoidance action to take. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet. Also, every 3 to 4 hours of operation, oiling is necessary.
