Hearth & Home GO30MTCH Installation Instructions Manual

Grand oak match light gas log sets
Hide thumbs Also See for GO30MTCH:

Advertisement

Quick Links

Models:
GO24MTCH,GO30MTCH
Grand Oak Match Light
Gas Log Sets
Check with your local building code agency before you begin installation to ensure compliance with local codes, including
the need for permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need
clarification of any of the instructions contained here, contact the Technical Services Dept., Hearth & Home Technologies
Inc., www.hearthnhome.com.
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
Hearth & Home Technologies • Grand Oak Match Light Gas Log Sets • 4004-322 Rev E • 01/2022
tm
tm
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Leave this manual with
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
Keep children away.
CAREFULLY SUPERVISE children in same room as
appliance.
Alert children and adults to hazards of high
temperatures.
Do NOT operate with protective barriers removed.
Keep clothing, furniture, draperies and other
combustibles away.
In the Commonwealth of Massachusetts:
This appliance must be installed by a licensed plumber
or gas fitter.
The chimney flue damper, when used with gas logs, will
be welded open or completely removed.
A CO detector shall be installed in the room where the
appliance is installed.
Installation
Instructions
Installation and service of this
appliance should be performed by
qualified personnel. Hearth & Home
Technologies suggests NFI certified
or factory-trained professionals,
o r t e c h n i c i a n s
s u p e r v i s e d b y
an NFI certified
professional.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO30MTCH and is the answer not in the manual?

Questions and answers

Summary of Contents for Hearth & Home GO30MTCH

  • Page 1 Installation Instructions Installation and service of this Models: appliance should be performed by GO24MTCH,GO30MTCH qualified personnel. Hearth & Home Technologies suggests NFI certified Grand Oak Match Light or factory-trained professionals, Gas Log Sets o r t e c h n i c i a n s...
  • Page 2: Homeowner Reference Information

    Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. Congratulations Congratulations on selecting a Hearth & Home Technologies The information contained in this owner’s manual, unless gas log set—an elegant and clean alternative to burning noted otherwise, applies to all models and gas control wood.
  • Page 3: Design And Installation Considerations

    GO24MTCH-HK obstructed (front grilles and vent caps). • Before installing into a solid fuel burning fireplace, the GO30MTCH-HK chimney and firebox should be inspected and cleaned to remove soot, creosote, ashes, paint, bird nests etc. • Annual examination of the chimney must be performed B.
  • Page 4: Appliance Certification

    • This appliance must have a screen in place while the WARNING appliance is in operation and, unless other provisions for combustion air are provided, the screen shall have an Fire Risk opening for introduction of combustion air. Explosion Risk •...
  • Page 5: Negative Pressure

    Table 3 for Minimum Fireplace Dimensions Log Set Front Depth Height Rear Natural Opening Width GO24MTCH-HK 32” 20” 18” 21” 73,000 GO30MTCH-HK 38” 20” 18” 27” 80,000 Hearth & Home Technologies • Grand Oak Match Light Gas Log Sets • 4004-322 Rev E • 01/2022...
  • Page 6: Inspect The Appliance And Components

    H. Inspect the Appliance and Components Note: For best results, do not pack down the rock wool. • Remove the contents from the carton labeled “Burner”. The placement of rock wool can have an effect on flame Attached to the burner are tags identifying the manufacturer pattern and may need to be adjusted to achieve a desired name, serial number, model number (including gas log appearance.
  • Page 7: Inspect The Venting System

    J. Damper Stop Installation Instructions Included in the burner assembly box is a damper stop clamp Fire Risk which attaches to the damper as shown (Figure 6). Install Explosion Risk the clamp to the damper ensuring that the minimum require- Personal Injury Risk ments (Tables 1 and 2) are achieved.
  • Page 8: Service Parts

    GO24 Service Parts Beginning Manufacturing Date: May 2018 Grand Oak 24” Gas Log Set Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 9 GO24MTCH-HK Service Parts Beginning Manufacturing Date: May 2018 Grand Oak 24” Matchlight Hearth Kit Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 10 GO30 Service Parts Beginning Manufacturing Date: May 2018 Grand Oak 30” Gas Log Set Ending Manufacturing Date: Active SRV721B SRV721A SRV720 SRV726 SRV722 SRV724 SRV723 SRV740 SRV743 SRV728 SRV742 SRV727 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 11 GO30MTCH-HK Service Parts Beginning Manufacturing Date: May 2018 Grand Oak 30” Matchlight Hearth Kit Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 12 P. Lighting Instructions- Match Light WARNING Asphyxiation Risk Gas-burning appliances produce smoke and carbon monoxide gas during operation. • The damper must be open • The chimney must draw properly These fumes can be harmful if not vented properly. Hearth & Home Technologies • Grand Oak Match Light Gas Log Sets • 4004-322 Rev E • 01/2022...
  • Page 13: Cleaning And Maintenance Instructions

    Q. Cleaning and Maintenance Instructions Your appliance is designed to be virtually maintenance free, although periodic visual inspection and cleaning is required. Always remember: Follow the instructions below for the correct procedures. An • Do not place any combustible material near the annual examination and cleaning the venting system by a appliance.
  • Page 14 R. Fequently Asked Questions Can I close the glass doors on my fireplace when using my gas logs? No. The gas log sets are designed for use in fireplaces with all fireplace doors fully opened. Operating your log set with the doors closed will cause overheating, premature failure of valve systems, and will void the warranty of your log set.
  • Page 15: Warranty Coverage

    Hearth & Home Technologies LLC LIMITED LIFETIME WARRANTY Hearth & Home Technologies LLC (“HHT”) extends the following warranty for HHT gas, wood, pellet and electric hearth appliances (each a “Product” and collectively, the “Product(s)”) and certain component parts set forth in the table below (“Component Part(s)”) that are purchased from a HHT authorized dealer or distributor.
  • Page 16: Warranty Conditions

    WARRANTY CONDITIONS: • Because HHT cannot control the quality of any Products sold by unauthorized sellers, this Warranty only covers Products that are purchased through an HHT authorized dealer or distributor unless otherwise prohibited by law; a list of HHT authorized dealers is available on the HHT branded websites.
  • Page 17: Contact Information

    S. Contact Information Please contact your Hearth & Home Technologies dealer with any questions or concerns. For the number of your nearest Hearth & Home Technologies dealer, please call 1-800-927-6841 or 1-888-427-3973. - NOTES - CAUTION DO NOT DISCARD THIS MANUAL Read, understand Leave this manual with •...
