Printed Matter No. 9836 8213 01
Valid from Serial No. A1110
2017-05-02
EBL55-RE (1.0-5.5 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8431017045
WARNING
EBL55-RE
Electric screwdriver
Product Instructions
Advertisement
Table of Contents
Related Manuals for Atlas Copco EBL55-RE
Summary of Contents for Atlas Copco EBL55-RE
- Page 1 Printed Matter No. 9836 8213 01 Electric screwdriver Valid from Serial No. A1110 Product Instructions 2017-05-02 EBL55-RE (1.0-5.5 Nm) 8431017045 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Torque range of the clutch springs ........ 7 Service .................. 8 Preventing ESD problems ............ 8 Maintenance instructions............ 8 Service recommendations .......... 8 Service instructions............ 8 Recycling .................. 9 Recycling instruction ............... 9 © Atlas Copco Industrial Technique AB - 9836 8213 01... -
Page 3: Product Information
• To avoid damage or destruction of tool parts, service the tool according to the recommended maintenance schedules and follow the correct instruc- tions. • Warranty repairs are only performed in Atlas Copco workshops or by Certi- fied Service Partners. Atlas Copco offers extended warranty and state of the art preventive mainte- nance through its ToolCover contracts. -
Page 4: Servaid
ServAid is available on DVD and on the website: https://servaid.atlascopco.com For further information contact your Atlas Copco sales representative or e-mail us at: servaid.support@se.atlascopco.com Website Log in to Atlas Copco: www.atlascopco.com. - Page 5 Torque range 8.8–48 in lb Motor voltage 20/ V d.c. Motor power 20 W Vibration standard ISO28927-2 Vibration uncertainty 1.0 m/s² Vibration value <2.5 m/s² Weight 0.8 kg Weight 1.8 lb © Atlas Copco Industrial Technique AB - 9836 8213 01...
-
Page 6: Operation
Adapt the torque setting to the operator's strength and posture and use a torque arm or reaction bar if the torque is too high. • Use dust extraction system or mouth protection mask in dusty environments. © Atlas Copco Industrial Technique AB - 9836 8213 01... -
Page 7: Testing Of Tightening Torque
Each clutch spring gives a certain torque range. Do not adjust the torque over the maximum recommendation as that might result in improper func- tion and faster wear of the clutch. © Atlas Copco Industrial Technique AB - 9836 8213 01... -
Page 8: Service
Service instructions Clean all parts and replace any defective or worn out parts during overhaul or maintenance. © Atlas Copco Industrial Technique AB - 9836 8213 01... -
Page 9: Recycling
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle the components in accordance with local legislation. Batteries shall be taken care of by your national battery recovery organization. © Atlas Copco Industrial Technique AB - 9836 8213 01... - Page 12 Original instructions Atlas Copco Industrial © Copyright 2017, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
