Magnescale DS50NR5 Instruction Manual

45 Suzukawa, Isehara-shi, Kanagawa 259-1146, Japan
DS50NR5 / DS50PR5 / DS100NR5 / DS100PR5
2-A02-934-1B
Digital Gauge
DS50NR5 / DS50PR5 /
DS100NR5 / DS100PR5
Instruction Manual
Read all the instructions in the manual carefully before use and strictly follow them.
Keep the manual for future references.
Trademarks
Microsoft Windows is the registered trademark of Microsoft Corporation.
Intel® Core
Other system names, product and service names described in the instruction manual are trademarks or registered trademarks of their corresponding manufacturers.
Specifi cations
Communication Interface
Resolution
Measuring range
Accuracy (at 20°C)
Measuring force
(at 20°C)
Reference point
Maximum response speed
Vibration resistance
(10 to 2000 Hz)
Impact resistance (11 ms)
Protective structure
Operating temperature
Storage temperature
Power supply voltage
Power consumption
Diameter of stem
Mass *
Feeler
Cable length
Accessories
System requirement
*1 Th e mass indicated is the total mass excluding the cable and interpolation box.
2020.9
Printed in Japan
©2020 Magnescale Co., Ltd.
TM
i3 is the registered trademark of Intel Corporation.
DS50NR5
50 mm
4 μm p-p
Upward –
Horizontal 0.9±0.4 N
Downward 1.3±0.5 N
One location (at 1 mm position of spindle movement)
IP50
1 Approx. 360 g
Provided with a carbide ball tip DZ-122 (Mount screw M2.5)
CPU : Intel Core i3 or higher recommended
RAM : 1 GB or higher recommended
OS : Windows7, Windows10 (32bit/64bit of each edition)
DS50PR5 DS100NR5 DS100PR5
USB2.0FS
0.5 μm
100 mm
5 μm p-p
–
6.2 N or less 1.8±0.65 N 9.3 N or less
2.7±0.55 N
250 m/min
150 m/s 2
2
1500 m/s
IP64 IP50 IP64
0°C to +50°C
–20°C to +60°C
DC +5 V ±5%
1.2 W or less
φ20 0
mm
– 0.013
Approx. 630 g
Measuring unit⇔Interpolation box : 2 m
Interpolation box⇔USB : 0.5 m
Instruction Manual
