Summary of Contents for CFM TF140-EC
- Page 1 READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Safety Instructions
Ducted fans must always be vented to the outdoors. TF140-EC fan is suitable for installation over a shower or tub when connected to a GFCI (Ground Fault Circuit Interrupter) protected branch circuit. This unit must be grounded. - Page 3 TF140-EC TRANQUIL BATHROOM FANS MODEL: TF140-EC The delivery set includes: • Housing • Mounting hardware • Duct assembly • Blower assembly • Grille • Power box knobs TwO wAYS TO CONNECT DUCTwORK TO A UNIT *NOT INCLUDED WITH FAN Insulation* (place around and over fan housing) Power cable*...
-
Page 4: Fan Installation
FAN INSTALLATION WARNING Disconnect and lock out power supply before performing any installation work. Working on or near energized equipment could result in death or serious injury. STEP 1. INSTALL HOUSING Hanger Hanger bars span up to 24 inches and can be used on all types of framing. -
Page 5: Wiring Diagram
DIAGRAM MODEL: TF140-EC BROWN SWITCH I BLACK SWITCH II BLACK WHITE WHITE LINE GROUND GROUND UNIT JUNCTION BOX Note: Switch I and switch II are supplied by others. Run 120V AC house wiring to the location of the fan. Use only UL-approved connectors (not... -
Page 6: Fan Controls
The Power Box, located inside the fan housing, has four separate adjustments: a. Toggle Switch positions determine the maximum Toggle Switch airflow rate (factory set to 110 cfm). To select the Position desired airflow (80, 110 or 140 cfm), set toggle switch 1 &... -
Page 7: Fan Operation
After that, the fan will switch to the pre-set low airflow rate (if above 30 cfm) or stop (if OFF or below 30 cfm). -
Page 8: Troubleshooting
Vacuum the interior of the unit. Reconnect the grille to the fan. Turn power supply on. ACCEPTANCE CERTIFICATE The TF140-EC fan has been duly certified as serviceable. Manufactured on (date): Date of sale: Sold by: (name of trading enterprise, stamp of store)
