XWEn - watchdog enable mode (*)

Set the watchdog enable mode.
Command Description
XWED Watchdog is normally disabled (factory default)
XWEA Watchdog is always enabled
XWE? Return current watchdog enable mode

XWHnnnnn - watchdog heartbeat timeout (*)

Set the watchdog heartbeat timeout.
If the watchdog heartbeat timeout is not persisted (see the "Permanently saving the
current configuration" paragraph), it is reverted to the saved value when the next power-
cycle occurs.
This allows, for example, to have a long timeout by default, that is reset to a much shorted
value when the application that handles the heartbeat signal has started.
When the watchdog is always enabled (XWEA command), the factory default or user
defined configuration of the watchdog heartbeat timeout will be forced to 60 seconds if set
to a lower value.
Command Description
XWHnnnnn Set the watchdog heartbeat timeout, in seconds (factory default
is 60, XWH00060). Min: 1; Max: 99999
XWH? Return current watchdog heartbeat timeout

XWWnnnnn - watchdog forced shutdown timeout (*)

Set the watchdog forced shutdown timeout.
Command Description
XWWnnnnn Forced shutdown delay from the moment the timeout is expired
and the shutdown cycle has not been enabled, in seconds
(factory default is 60, XWW00060). Min: 1; Max: 99999
XWW? Return current watchdog forced shutdown timeout
