Pi Touch Display Kit
User Guide
November 2021
Revision 014
SPTM20XP Strato Pi Mini Touch Display Kit with Raspberry Pi 3 Model B+
SPTB30XP Strato Pi Base Touch Display Kit with Raspberry Pi 3 Model B+
SPTB30X42 Strato Pi Base Touch Display Kit with Raspberry Pi 4 Model B 2GB
SPTB30X44 Strato Pi Base Touch Display Kit with Raspberry Pi 4 Model B 4GB
SPTB30X48 Strato Pi Base Touch Display Kit with Raspberry Pi 4 Model B 8GB
SPTU30XP Strato Pi UPS Touch Display Kit with Raspberry Pi 3 Model B+
SPTU30X42 Strato Pi UPS Touch Display Kit with Raspberry Pi 4 Model B 2GB
SPTU30X44 Strato Pi UPS Touch Display Kit with Raspberry Pi 4 Model B 4GB
SPTU30X48 Strato Pi UPS Touch Display Kit with Raspberry Pi 4 Model B 8GB
SPTC12XP Strato Pi CAN Touch Display Kit with Raspberry Pi 3 Model B+
SPTC12X42 Strato Pi CAN Touch Display Kit with Raspberry Pi 4 Model B 2GB
SPTC12X44 Strato Pi CAN Touch Display Kit with Raspberry Pi 4 Model B 4GB
SPTC12X48 Strato Pi CAN Touch Display Kit with Raspberry Pi 4 Model B 8GB
IPTB20RP Iono Pi Touch Display Kit with Raspberry Pi 3 Model B+
IPTB20R42 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 2GB
IPTB20R44 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 4GB
IPTB20R48 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 8GB
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sferalabs Iono Pi
Summary of Contents for Sferalabs Iono Pi
- Page 1 SPTC12X48 Strato Pi CAN Touch Display Kit with Raspberry Pi 4 Model B 8GB IPTB20RP Iono Pi Touch Display Kit with Raspberry Pi 3 Model B+ IPTB20R42 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 2GB IPTB20R44 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 4GB IPTB20R48 Iono Pi Touch Display Kit with Raspberry Pi 4 Model B 8GB ...
-
Page 2: Table Of Contents
Safety information Qualified personnel Hazard levels Safety instructions General safety instructions Battery and external rechargeable battery Introduction Kit Components Features Usage and connections Hardware installation microSD installation Power supply Wiring and GPIO operations Replacing the RTC backup battery Software installation Technical specifications Dimensions Disposal... - Page 3 The product information on the web site or materials is subject to change without notice. Please download and read the Terms and Conditions document available at: http://www.sferalabs.cc Strato, Iono and Sfera Labs are trademarks of Sfera Labs S.r.l. Other brands and names may be claimed as the property of others.
-
Page 4: Safety Information
Safety information Carefully and fully read this user guide before installation and retain it for future reference. Qualified personnel The product described in this manual must be operated only by personnel qualified for the specific task and installation environment, in accordance with all relevant documentation and safety instructions. -
Page 5: Safety Instructions
Safety instructions General safety instructions Protect the unit against moisture, dirt and any kind of damage during transport, storage and operation. Do not operate the unit outside the specified technical data. Never open the housing. If not otherwise specified, install in closed housing (e.g. distribution cabinet). - Page 6 WARNING Improper handling of lithium and lead-acid batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. Replace the RTC lithium battery before it is completely discharged. The lithium battery must be replaced only with an identical battery.
-
Page 7: Introduction
Raspberry Pi computer board, the Raspberry Pi 7” Touch Display and the Strato Pi board (Mini, Base, UPS or CAN version) or the Iono Pi board, enclosed in a rugged, high-quality aluminium and steel chassis, that can be installed in-wall with its optional back-box mount. -
Page 8: Kit Components
• Raspberry Pi version 3 model B+ or Raspberry Pi version 4 model B • Raspberry Pi Touch Display • Strato Pi board (SPBM20X, SPBB30X, SPBU30X or SPBC12X) or Iono Pi board (IPBB20R) • Optional SPBF10X Strato Pi Fan active cooling temperature controlled high performance •... -
Page 9: Features
Features With Strato Pi Mini board: ✓ 9-28Vdc power supply, with surge and reverse polarity protection, and 1.1A resettable fuse ✓ real time clock with replaceable CR1025 back-up battery (not included) ✓ embedded Microchip ATECC608A secure element chip ✓ on-board buzzer, connected to an I/O pin of the Raspberry Pi board, for acoustic feedback ✓... - Page 10 ✓ on-board buzzer, connected to a GPIO pin of the Raspberry Pi board, for acoustic feedback ✓ hardware watchdog implemented in the Strato Pi board, fully independent from the Raspberry Pi, controlled via the GPIO pins of the Raspberry Pi board ✓...
- Page 11 With Iono Pi board: ✓ 9÷28Vdc power supply, with surge and reverse polarity protection, and 2.2A resettable fuse ✓ 4 power relay outputs rated for 6A at 250V ✓ 2 analog voltage inputs 0÷30V ✓ 2 analog voltage inputs 0÷3V on internal pin-headers ✓...
-
Page 12: Usage And Connections
Usage and connections Hardware installation The Pi Touch Display Kit is shipped fully assembled. You will only have to access the Raspberry Pi board to install your microSD card, and connect the power and other optional cables. Two M4 threaded holes in the back of the display panel are available to screw the display directly to a panel board. -
Page 13: Power Supply
Strato Pi or Iono Pi board: ✓ With Strato Pi CAN board: DC nominal voltage range 12V to 65V; ✓ With Strato Pi Mini, Base or UPS or Iono Pi board: DC nominal voltage range 12V to 28V. -
Page 14: Software Installation
Software installation Refer to the software installation section of the Strato Pi or Iono Pi user guide for detailed software installation and troubleshooting instructions. The display and touch sensor unit used in Strato Pi Touch Display is the original 7” touch display developed by the Raspberry Pi Foundation. -
Page 15: Technical Specifications
-20…+70 °C Relative humidity 5% to 90% noncondensing Protection degree IP20 Fan noise (with SPBF10X fan option) 23.6 dBA Refer to the user guide of the installed Strato Pi or Iono Pi board for the relative technical specifications. User Guide... -
Page 16: Dimensions
Dimensions User Guide... -
Page 17: Disposal
Disposal Waste Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This marking on the product, accessories or literature indicates that the product should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. -
Page 18: Conformity Information
The Pi Touch Display Mechanical Kit (XPTM10X) and the Wall Mount Back Box (XPTB10X) comply with the essential requirements of the 2011/65/EU and 2015/863/EU (RoHS) directives and harmonised standard. The declaration of conformity is available at: https://www.sferalabs.cc Refer to the documentation of the additional components for the relative conformity information.
