4.

Laser Safety

The scanCONTROL 30xx sensors operate with a semiconductor laser with a
wavelength of 658 nm resp. 660 nm (visible/red). Operation of the laser is indicated
visually by the LED on the sensor, see operating instructions Chap. 3. When operating
the scanCONTROL 30xx sensors, the relevant regulations according to IEC 60825, Part
1 of 05/2014 and the applicable accident prevention regulations must be followed. The
laser warning labels for Germany have already been attached. For other non German
speaking countries, an IEC standard label is included in delivery and the versions valid
for the user's country must be attached before the device is put into operation for the
first time.
i
If both warning labels are covered over when the unit is installed, the user must
ensure that supplementary labels are applied.
Laser Class 2M
The sensors fall within laser class 2M (IIM). The laser is operated on a pulsed mode,
the maximum optical power is ≤ 10 mW, ≤ 12 mW resp. ≤ 26 mW. Attach the following
warning labels to the cover of the sensor housing.
Fig. 1 LLT30xx-25, LLT30xx-50, LLT30xx-100 Fig. 2 LLT30xx-200
Fig. 3 LLT30xx-430, LLT30xx-600
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
scanCONTROL 3000 / 3002
Laser radiation. Close your eyes or immediately turn away if the
laser beam hits the eye. Irritation or injury of the eyes possible.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P 10 mW, P 10 mW; E 6 mW/cm²;
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
L A S E R R A D I AT I O N
Do not stare into beam or expose
users of telescope optics
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P ≤ 26 mW; P ≤ 26 mW; E ≤ 6 mW/cm²;
0 p
λ = 660 nm; F = 0...25 kHz; t = 7 µs...∞
Only for USA
i
Mark the laser area recognizable
and everlasting.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P 12 mW, P 12 mW; E 6 mW/cm²;
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
