MCH CRAH
Air Handling Units
Pack Sheet
2023-7-31
This document includes the minimum legal and warranty
information only. Read the linked document and any other
relevant bulletins, safety warnings, and cautions before
dismounting, rigging, forking, moving, installing, using, or
maintaining the product.
QR code
Scan the QR code to view the product documentation for
the MCH CRAH air handling unit, or navigate to the link:
https://docs.jci.com/YORK/CRAH-All-Docs.
If you cannot locate these guides using the QR code or
the link, contact product technical support.
General safety guidelines
This equipment is a relatively complicated apparatus.
During rigging, installation, operation, maintenance, or
service, individuals may be exposed to certain compo-
nents or conditions including, but not limited to: heavy
objects, refrigerants, materials under pressure, rotat-
ing components, and both high and low voltage. Each
of these items has the potential, if misused or handled
improperly, to cause bodily injury or death. It is the
obligation and responsibility of rigging, installation, and
operating/service personnel to identify and recognize
these inherent hazards, protect themselves, and proceed
safely in completing their tasks. Failure to comply with
any of these requirements could result in serious damage
to the equipment and the property in which it is situated,
as well as severe personal injury or death to themselves
and people at the site.
This document is intended for use by owner-authorized
rigging, installation, and operating/service personnel. It
is expected that these individuals possess independent
training that will enable them to perform their assigned
tasks correctly and safely. It is essential that, prior to per-
forming any task on this equipment, this individual must
have read and understood the on-product labels, this
document, and any referenced materials. This individual
must also be familiar with and comply with all applicable
industry and governmental standards and regulations
pertaining to the task in question.
This equipment is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning the use of the appliance by a person respon-
Form number: CRAH102.20-Packsheet (723)
sible for their safety. Children should be supervised to
ensure that they do not play with the equipment.
Safety symbols
The following symbols are used in this document to alert
the reader to specific situations:
Danger - Indicates a hazardous situation
in which a person will experience serious
personal injury or death if the situation is not
avoided.
Warning - Indicates a hazardous situation in
which a person could experience serious
personal injury or death if the situation is not
avoided.
Caution - Indicates a hazardous situation in
which a person could experience minor or
moderate personal injury if the situation is
not avoided.
Notice - Addresses general practices or obser-
vations related to system function that are not
related to personal injury.
Safety and quality
Warranty
Johnson Controls warrants CRAH units in accordance
with the Limited Warranty Engineered Systems Equip-
ment procedure. Refer to the Standard Limited Warranty
Engineered Systems Equipment (Form 50.05-NM2) for
more information.
Johnson Controls warrants all equipment and materi-
als against defects in workmanship and materials for a
period of 18 months from the date of shipment or 12
months from the date of start-up, whichever comes first,
unless a labor or extended warranty has been purchased
as part of the contract.
The warranty is limited to parts only replacement and
shipping of any faulty part, or subassembly, which has
failed due to defects in workmanship and materials.
All claims must be supported by evidence that the failure
has occurred within the warranty period, and that the

Advertisement

loading

Summary of Contents for York MCH CRAH

  • Page 1 QR code Scan the QR code to view the product documentation for the MCH CRAH air handling unit, or navigate to the link: https://docs.jci.com/YORK/CRAH-All-Docs. Danger - Indicates a hazardous situation in which a person will experience serious personal injury or death if the situation is not avoided.
  • Page 2: Delivery And Storage

    Controls. For warranty purposes, the following conditions a tarp or similar protective covering. Any concealed must be satisfied: damage reported after 15 days compromises a claim • Only genuine YORK approved spare parts must be settlement. used. • Request inspections by telephone or in person, but •...
  • Page 3 • Maintain the storage temperature. See the transport and storage conditions in the following table. Table 1: Transport and storage conditions ° Maximum permissible ambient motor temperature (transport/storage) ° Minimum permissible ambient motor temperature (transport/storage) Maximum permissible storage duration or standstill period for frequency inverters, EC controllers, and EC motors Table 2: Actions required after storage Period without line supply...
  • Page 4: Installation

    Installation Using the forklift Each unit is designed with integrated 3 in. allowance for Electrical information either forklift rails or standard jack pallets. No additional effort or lifting lugs are required to load, unload, and in- stall the units. See Figure 1- Toe kick type base rail feature for moving units with forklift.
  • Page 5 Figure 3: Further considerations Correct lifting with a base rail Gallery and server-side clearances likely exceed out air in- let and outlet service side clearances. Always allow space to move equipment through these areas. Maximum system design water pressure: 130 psi. °...
  • Page 6 Installing the unit Upper segment assembly It is Johnson Controls intention that a shipping wrap- per is applied to unpainted indoor AHUs for protection against weather, road dirt, and other environmental factors during inland transit. Remove the wrapper at the You must remove the discharge screen from the top of the lower segment before installing time of delivery to allow for a thorough inspection, both...
  • Page 7 Ensure that the neoprene gasket is correctly Ensure that all of the electrical or control wires installed on the bottom tier. or tubes in both tiers are clear. Figure 7: Bottom tier Multiple single flat plate for top/bottom segment field assembly The top tier is shipped with the angled style of brackets for shipping purposes.
  • Page 8 Top segment signal wiring Figure 10: Top segment signal wiring Piped stacked segment connections Figure 11: Pairing the piping manifolds using the grylok fittings...
  • Page 9 CRAH unit sequence of operation For full details on unit shutdown and enable features, discharge air temperature control, and fan speed control, refer to page 32 of Form CRAH102.20-N1. Operating the HMI touchscreen CRAH unit operational information such as discharge air temperature, supply fan status, cooling valve output, and other information are displayed on the HMI Main screen.
