Operation

Ensure that the protective film is removed from the base plate before use!
Commissioning
+
Adjust the motor speed using the rotary knob (D)

The value selected will be shown on the display (F)
Stirring
+
Set the start point for the mixing function by pressing the rotary knob (D)
i
Heating
i
i
Connecting
external
thermometers
(direct temper-
i
ature control in
the medi a)
i
062010
RCT basic safety control
+
Move device switch (A) to the OFF position
+
Insert the mains power cable into the power socket (K)
+
Move device switch (A) to the ON position

The unit will be set to factory setting mode A (see "Operating modes")

The displayed value will flash until the desired motor speed is reached
+
Set the safe temperature limit (see "Setting the safe temperature limit for RCT and HCT")
+
Adjust the set-point temperature using the rotary knob (C)

The value selected will be shown on the display (E)
+
Set the temperature control mode (see "Setting the temperature control mode for RCT and HCT")
+
Set the start point for the heating function by pressing the rotary knob (C)
The set-point and actual temperatures will be shown alternately on the display (E)

When the heating is switched on, the LED "Heating plate" (G) and the LED "Set-point value" (I) will be lit
The maximum temperature that can be set for the heating plate is 310 °C

During mixing and standby operation, the display (E) will show
+
Move device switch (A) to the OFF position
+
Detach contact plug (L)
+
Attach a DIN 12878 (Class 2) compliant safety contact thermometer or a PT 1000 temperature sensor
to the socket (L)
+
Move device switch (A) to the ON position
Temperature sensor PT 1000
Contact thermometer ETS-D5
HCT basic safety control
if the base plate temperature is above 50 °C
Hot

The actual temperature for the temperature sensor shown on
display (E) will correspond to the temperature of the media.
The LED "external temperature sensor" (H) will be lit

Follow the operating instructions for the contact thermometer
The LED "decimal point for the temperature display" (J) will be lit

When a contact thermometer is connected, the display (E)
will only show the set-point temperature that has been set
