RCT basic
safety control
RCT 基本型
(安全控制型)
A
B
M
G H I
Item Designation
A Main Switch
B Adjustable safety circuit
C Rotary knob, heater
D Rotary knob, motor
E LED display, heater
F LED display, motor
G LED, heating plate
H LED, external temperature sensor
I LED (set=set point value)
J LED, external temperature sensor
K Power socket
L Socket, contact thermometer
M Threaded hole for stand
062010
HCT basic
safety control
HCT 基本型
(安全控制型)
L K
M
F
D
J
C
E
G H I
Fig. 1
序号 名称
电源开关
A
安全温度设定螺丝
B
调温旋钮
C
调速旋钮
D
温度显示
E
转速显示
F
加热指示
G
外部温度计指示
H
设定指示
I
外部温度计指示
J
电源插口
K
温度计插口
L
支杆螺孔
M
A B K
L
C
J
E
Fig. 2
3
